- Page 1 Notebook Travel Speaker User Manual...
-
Page 2: Table Of Contents
1. Introduction USB 2 / 2.1 Channel Speakers 2. System Requirement and Installation 3. User Interface and Function Control 4. Feature Overview of Xear 3D Sound Technology 5. Product Application 6. FAQ & Technical Support Table of Content... -
Page 3: Introduction Usb 2/2.1 Channel Speakers
1.Introduction USB 2/2.1 Channel Speakers This USB 2/2.1 channel Speakers is design for all kind of PC base products. It is USB 2.0 full speed compatible and utilizes USB bus power. No driver is needed for audio playback on all mainstream OSs; therefore this device provides a truly plug-and-play feature for external digital audio play back. -
Page 4: System Requirement And Installation
2.System Requirement and Installation This device must be applied on USB specification products. And user should to confirm that PC operation supports USB function, USB 1.1 or 2.0. No external driver installed： OS Support ：Win98SE, WinME, Win2000, WinXP, Mac OS 9.0 and 10.1 System recommended：use Intel At least 64 MB RAM (Win98SE) or 128MB RAM (WinME, Win2000 and WinXP) For good sound quality, please adjust your system’s H/W acceleration and Sample... - Page 5 Install Xear 3D sound audio driver： OS Support ：Win98SE, WinME, Win2000, WinXP System recommended：use Intel At least 64 MB RAM (Win98SE) or 128MB RAM (WinME, Win2000 and WinXP) Support Direct sound 3D Note: Windows OS has default USB driver support, but no support for HRTF 3D, EAX or Virtual 5.1 CH sound effect.
- Page 6 Xear 3D Sound Audio Driver Installation Step： Turn on PC system and connect USB speaker to PC system. Please follow up the set up procedure and click “Next ” button to continue installation.
- Page 7 You can Select install driver only or both driver and demo program then click “Next” to continue installation. If your System is WinXP, you may see a dialog box asking you about windows logo issue, please click “Continue Anyway” to complete installation. And set up program will continue install.
- Page 8 When set up program complete installation system will need to restart to initialize the driver. If your PC system has more than one USB port, you can just plug USB speaker to any USB port. If this connect is right that driver will detect device and show a task bar on the bottom right side of the screen to guiding you which port is correct.
- Page 9 Best Listening Environment Setting...
-
Page 10: User Interface And Function Control
3. User Interface and Function Control You can open “control panel” to find Xear 3D audio driver and enable it. Or, you can check the bottom right side of the screen to double click Xear 3D task bar button. - Page 11 Output Device Select Master Volume Control PS：Xear 3D supports loudness function which allows users to amplify the sound source. This special feature can make speaker sound louder beyond its limitation. AGC Function Select Click Speaker graphic to For technical support, to know about Hardware and Software information test speaker sound...
- Page 12 Environment Sound Effects SHIFTER ON/OFF Room Size 5.1 Virtual Speakers Total Volume Rotate Speakers 10 Band Equalizer Reset Virtual Speakers...
-
Page 13: Function Description
5.1 Virtual SPEAKER SHIFTER- Function Description Function The SPEAKER SHIFTER block provides an advanced, amazing and considerate feature- 5.1 Virtual matter what listening appliance you use and what application you are SPEAKER running. SHIFTER Block spatial limitation. You can enjoy multi-channel surround sound with even a pair of earphones or usual 2 speakers. - Page 14 # Function When SHIFTER is turned ON, though the Virtual Speakers will all be turned into blue, it doesn’t imply all virtual speaker will take effect anytime. It depends on the sound source format and the application program. The virtual speaker won’t take effect if that channel has no digital audio.
-
Page 15: Feature Overview Of Xear 3D Sound Technology
4.Feature Overview of Xear 3D Sound Technology The 1st Advantage of Xear 3D™ Sound Technology: Virtual 5.1CH Audio SPEAKER SHIFTER allows the users to obtain a 5.1CH virtual speaker environment no matter what output device they are using (2/2.1CH speakers). Moreover, the users are able to drag the virtual speakers to anywhere they want without moving the actual ones to accommodate their need. - Page 16 The 2nd Advantages of Xear 3D™ Sound Technology: Environment FX™ and 3D Positional Audio In the real world sounds travel directionally; furthermore, sounds would have myriad manifestations according to different factors of the environment: the room size, distance, reflecting materials, obstructing objects, etc. For example, same footsteps in different settings, say the cave and the sewer pipe, will generate distinctive effects to the ears.
-
Page 17: Product Application
5.Product Application The user manual is a guide for users to understand how to use the new generation USB Speaker with exclusive Xear 3D quickly take advantage of these great features to enjoy amazing sound effects even better than consumer electronics devices. Xear 3D™... -
Page 18: Faq & Technical Support
7. FAQ & Technical Support Q1：Why play CD without sound ? Most general case was digital CD playback function did not open. Because USB audio is digital signal, it is use different path to process CD music with traditional analog CD. You should open “Device Manager”, select “DVD/CD ROM drives”... - Page 19 and Audio Devices”, choice “Audio” page then switch “Default device” to USB Device or C-Media USB Device. Q3：When using software application program (Like: Media player, Winamp, PowerDVD, WinDVD….) to playback any media files, can I plug out USB audio device while playing? It is incorrect mode of operations, because while application programs were playing audio stream, windows system is stilling using audio device to process and deliver data real-time.
- Page 20 Do not plug out while application programs were playing media files. Please stop playback before plug out USB audio device. Q4：Xear 3D Sound technology provide amazing function In virtual 5.1 speaker shifter, how to using this function in different media format? Virtual 5.1 Speaker shifter can process 2CH, 4CH or 5.1CH audio format and make 2CH audio file like MP3, stereo wave to transfer in virtual 5.1 surround sound.
- Page 21 3. Click right key of mouse 4. Select “Configuration” or “Setup” 5. Choice “Audio” function setting page 6. Check “Audio Output”→If you can see or select speaker from 2 to 6 that mean this version was supported 5.1CH decoding capability. Otherwise, it is only supported 2CH decoding capability.
- Page 22 Trademarks C-Media, C-Media logo and Xear 3D are trademarks of C-Media Electronics Inc. EAX and A3D are trademarks of Creative Technology Ltd. Microsoft, DirectSound3D, Windows are trademarks of Microsoft Corporation. Other company and product names may be trademarks of the respective companies with which they are associated.
