- Page 1 Model #5LGZ1159-NN USE AND CARE GUIDE 12ft. x10ft. Cabin Style Garden House Questions, problems, missing parts? Before returning to the store, call Paci c Casual Customer Service 7.30 a.m. - 4.30 p.m., PST, Monday - Friday 888-445-7757 CustomerService@PacificCasual.com...
-
Page 2: Table Of Contents
Table of Contents Table of Contents............2 Care Instructions..............2 Safety Information............2 Pre-Assembly ............3 Warranty ..............2 Planning Assembly..............3 Hardware Included..............3 One Year Frame and Fabric Limited Warranty......2 ..............2 Package Contents ..............4 What Is Covered What Is Not Covered .............. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY It will take two people about 30 minutes to complete the assembly process. TOOLS REQUIRED (not included) Adjustable wrench HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x16) Bolt (M6x50) Bolt cap Hex wrench Ground stake Guy rope... -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Post Long midde roof tube Left long beam Vent hub Right long beam Corner bracket Left short beam Vent cover Right short beam Main canopy Corner roof tube Elephant foot Middle roof tube Post base... -
Page 5: Assembly
Assembly Attaching the post bases and the elephant feet □ Slide the bottom of one post (A) into one elephant foot (M). □ Attach one post base (N) to the bottom of each post (A) with four bolts (AA) using hex wrench (FF). Drop the elephant foot (M) to cover the post base (N). - Page 6 Assembly (continued) Assembling beams □ Connect one left long beam (B) into one right long beam (C) and secure them with two bolts (BB) and two nuts (DD) using hex wrench (FF) and adjustable wrench. □ Repeat this for the remaining long beams (B,C). □...
- Page 7 Assembly (continued) Setting up the main frame □ Insert one bracket (J) into the top of each post (A), making sure that the four holes are properly aligned. □ Please have a free standing ladder ready for ease of assembly. □...
- Page 8 Assembly (continued) Assembling the roof frame □ Snap four corner roof tubes (F) into the receivers F of the vent hub (I). □ Snap two middle roof tubes (G) into the receivers G of the vent hub (I). □ Snap two middle roof tubes (H) into the receivers H of the vent hub (I).
- Page 9 Assembly (continued) Attaching the roof frame □ With a person on the ladder inside the main frame, place the roof fame onto the main frame. □ Snap the bottom of corner roof tubes (F) into the brackets (J). IMPORTANT: Do not use bolts to x middle roof tubes (G) and (H) until the end of Step 6. Please contact 888-445-7757 for further assistance.
- Page 10 Assembly (continued) Attaching the main canopy and the vent cover □ Identify the long side and the short side of the main canopy (L), cover the roof frame with the main canopy (L). □ Fully extend each corner of the main canopy (L) to cover the four corners of the frame. □...
- Page 11 Assembly (continued) Anchoring the garden house □ Adjust the location of each post until all posts are standing comletely upright on level ground. Hammer two ground stakes (FF) through the holes on each post base (N) into soft ground. □ Measure out from post to the longest possible distance to best use the length of the guy rope (GG) and secure anchor (HH) to ground at 45 degress.
- Page 12 Questions, problems, missing parts? Before returning to the store, callPaci c Casual Customer Service 7.30 a.m. – 4.30 p.m., PST, Monday-Friday 888-445-7757 Retain this manual for future use.
