Summary of Contents for Kvik H560
- Page 1 H560 Check out easy mounting of your kitchen Front without integrated handle Front with integrated handle L01660 L01660 L00561 L00561 L03260 L03260 L03260 L03260 60 cm 60 cm 12-11-2019 2b...
- Page 2 H560 Check out easy mounting of your kitchen DH195,060,000 / 176 HS19260,000 / KVIK K12122 K71155 Shelf Base-top K10120 K10120,76 Side Side K11155,76 K12930,76 Base-top Shelf 2 pcs 2 pcs 2 pcs K13515 Back panel 1 pcs Drawer slide Left...
- Page 3 H560 FIG. Side Left Euro screw 6,3x11 mm 4 pcs Shelf support 14x12 mm 5 4 pcs K10120,76 Side K10120 Side Screw ph 3x16 mm 2 pcs Front list holder 25x10 mm 6 1 pcs Flush FIG. Side Right Euro screw...
- Page 4 H560 Screw flh FIG. Side Left 3,5x15 mm Screw flh 3 pcs 3,5x15 mm Euro screw 6,3x11 mm 4 pcs 2 pcs Screw flh 3,5x15 mm K10120,76 Side K10120 Side Euro screw Screw flh 6,3x11 mm 3,5x15 mm NB!!! Drawer slide Left 2 pcs FIG.
- Page 5 H560 FIG. K71155 Base-top K11155,76 Base-top K10120 Side K71155 Base-top K10120,76 Side K11155,76 Base-top FIG. Screw flh 3,5x45 mm 4 pcs K10120 Side K10120,76 Side 12-11-2019 2b...
- Page 6 H560 FIG. Screw flh 3,5x45 mm 4 pcs FIG. K12122 K12930,76 Shelf Shelf 12-11-2019 2b...
- Page 7 H560 FIG. Screw flh 3,5x45 mm 6 pcs K13515 Back panel FIG. Screw flh 3,5x15 mm 4 pcs Angle 46x43 mm 2 pcs L01660 Drawer front 12-11-2019 2b...
- Page 8 H560 FIG. L01660 Drawer front Euro screw Screw flh 6,3x11 mm 3,5x15 mm 2 pcs 2 pcs FIG. L00561 Front list Press 12-11-2019 2b...
- Page 9 H560 FIG. Adjustment L00561 Front list L00561 Front list 12-11-2019 2b...
