Summary of Contents for Kvik CU748
- Page 1 CU748 Check out easy mounting of your kitchen Sink cut out Front with integrated handle L01660,Cima L01680,Cima L03260,Cima L03280,Cima L03260,Cima L03280,Cima 60 cm 80 cm 17-09-2019 0a...
- Page 2 CU748 Check out easy mounting of your kitchen Sink cut out DU80,***,176 (Suspension list) (Back panel) 1 pcs (Base-top) (Side) 2 pcs 1 pcs 1 pcs (List back) 1 pcs Drawer slide Left Drawer slide left Drawer slide right Drawer slide right...
- Page 3 CU748 FIG. Side Left Screw flh 3,5x15 mm 4 pcs NB!!! (Side) Screw flh 3,5x15 mm Drawer slide Left 1 pcs FIG. Side Right Screw flh 3,5x15 mm 4 pcs NB!!! Screw flh 3,5x15 mm (Side) Drawer slide right 1 pcs...
- Page 4 CU748 FIG. Side Left (Side) Screw flh Euro screw 3,5x15 mm 6,3x11 mm 4 pcs 1 pcs Drawer slide left 1 pcs FIG. Side Right (Side) Screw flh Euro screw 3,5x15 mm 6,3x11 mm 4 pcs 1 pcs Drawer slide right...
- Page 5 CU748 FIG. Side Right Side Left (Side) (Side) Screw flh 3,5x15 mm 2 pcs BP01905 30,5x30,5 m/ 8 2 pcs FIG. (Suspension list) NB!!! (List back) BP21XXX Alu profil (Base-top) (Side) 17-09-2019 0a...
- Page 6 CU748 FIG. (Back panel) FIG. (Side) Screw flh 3,5x45 mm 2 pcs 17-09-2019 0a...
- Page 7 CU748 FIG. Screw flh Screw flh 3,5x45 mm 3,5x45 mm 3 pcs FIG. Euroscrew 4,2x9,5 4 pcs 17-09-2019 0a...
- Page 8 CU748 FIG. Screw flh Angle 3,5x15 mm 46x43 mm 4 pcs 2 pcs L01660 / L01680 Drawer front Cima FIG. L01660 / L01680 Drawer front Cima Screw flh 3,5x15 mm 4 pcs 17-09-2019 0a...
- Page 9 CU748 FIG. 17-09-2019 0a...
