Summary of Contents for AUDAC WP225
- Page 1 User manual WP225 audac.eu...
- Page 2 This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ www.audac.eu. WP2xx - User manual...
-
Page 3: Table Of Contents
Table of contents Introduction Universal wall panel - Microphone, line & Bluetooth receiver � � � � � � � � � � � � � � � � � � � � � � � � � � � 05 Precautions Chapter 1 Overview front panel �... - Page 4 WP2xx - User manual...
-
Page 5: Introduction
& Android smartphones, tablets, PC, Laptops, Desktops, etc... The WP225 is available in 2 colours and is compatible with most standard EU style in-wall boxes for solid and hollow walls. With the Elegant ABS front panel with glass, it will blend into any environment. -
Page 6: Precautions
Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE NO NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED ON THE APPARATUS DO NOT PLACE THIS UNIT IN AN ENCLOSED ENVIRONMENT SUCH AS A BOOKSHELF OR CLOSET. -
Page 7: Overview Front Panel
Bluetooth pairing button with LED Pressing the bluetooth button will put the WP225 into pairing mode. This can be recognized by the blinking of the blue LED. If the wall panel is connected to a device the LED will be constantly lit. If the button is pushed again, the connection will be disconnected and the WP225 will go back into pairing mode. -
Page 8: Overview Rear Panel
Overview rear panel The rear of the WP225 contains an 8-pin Terminal Block connector, which is used to connect the wall panel to the twisted pair cabling. Below the 8-pin connector is a 6-pin connector. This input connector is a duplicate of the line and mic input but for permanent connections. -
Page 9: Quick Start Guide
Quick start guide This chapter guides you through the process for a basic setup where a WP225 should be connected to a system with wired network. Install your wall panel on the desired location by means of the optional available WB45S/FS (for solid walls) or WB45S/FG (for hollow walls) installation boxes. -
Page 10: Chapter 3 010
For connection to Wall Panels The 8-pin Euro-Terminal Block on the rear side of the WP225 should be connected to twisted pair cabling. The maximum cable distance between the input unit and the speaker system can reach up to 100 meter. To ensure a proper working of the system, all 8 conductors of the twisted pair cable have to be connected according to the table below. -
Page 11: Technical Specifications
Technical specifications Integrated Bluetooth receiver Inputs Type Version BT5.0 Frequency band 2.4 GHz Type Stereo unbalanced line Connector Front: 3.5mm jack Rear: 6-pin terminal block 3.81mm Impedance 7,7 kOhm Sensitivity -6 dBV / +26 dBV THD+N <0,2% Signal / Noise 72 dB Balanced microphone Type... - Page 12 Discover more on audac.eu...
