H-9466
SMOKE DETECTOR,
10-YEAR LITHIUM BATTERY
TOOLS NEEDED
Pencil Hammer
NOTE: This smoke detector was designed to
be mounted on the ceiling or wall. It is not a
tabletop device.
CAUTION! Do not connect this unit to any other
detector or auxiliary device. It is a single-
station unit that cannot be linked to other
devices. Connecting anything else to this unit
may prevent it from working properly.
CAUTION! Do not install this unit over an
electrical junction box. Air currents around
junction boxes can prevent smoke from
reaching the sensing chamber and prevent the
unit from alarming. Only AC-powered units are
intended for installation over junction boxes.
Place the bracket on the wall or ceiling where
detector will be mounted.
1. If locking the battery compartment or locking the
smoke detector to the mounting bracket, please
read the "Locking Feature (Optional)" section.
2. Hold base firmly and twist the mounting bracket
counterclockwise to separate it from the unit.
(See Figure 1)
3. Hold the mounting bracket against the ceiling or
wall and trace around the inside of the mounting
slots. (See Figure 1)
PAGE 1 OF 9
1-800-295-5510
uline.com
Drill 3/16" Drill Bit
INSTALLATION
4. Use a pencil to make a mark inside each outline for
the drill holes.
5. Set the unit where it won't get covered with dust
when drilling the mounting holes.
6. Using a 3/16" drill bit, drill a hole through each pencil
mark.
7. Insert the plastic screw anchors (included) into the
holes. Tap the screw anchors gently with a hammer,
if necessary, until they are flush with the ceiling or
wall.
Pour le français, consulter les pages 7-9.
Flathead Screwdriver
Figure 1
Mounting Bracket
Para Español, vea páginas 4-6.
Mounting Slots
0721 IH-9466
