DreamPlug User Guide
Thank you for purchasing our DreamPlug - The Power to Innovate!
A. For Initial Use ..................................................................................................................................................... 2
B. DreamPlug Server appearance and connecting ports ................................................................................. 4
C. LED indication .................................................................................................................................................... 5
D. Connect to JTAG board .................................................................................................................................... 6
E. Tools and files you need to start debugging.................................................................................................. 7
F. Basic procedures for debugging ..................................................................................................................... 8
G. Wi-Fi / Bluetooth .............................................................................................................................................. 10
H. Download sites ................................................................................................................................................. 12
DreamPlug Content List
1
DreamPlug
2
Detachable AC-DC Power Supply Unit
3
Detachable DC-DC Power Cable
4
Detachable AC Slider
5
Detachable AC Power Cord Adaptor
6
AC power Cord
7
Protective Slide Cover for DreamPlug
8
Protective Slide Cover for Power Supply Unit
9
Ethernet Cable
10
Warranty Card
11
Quick Reference Guide
12
External JTAG Debug Module
Note 1: All files will be available download:
Note 2: JTAG debug module is sold separately. It's highly recommended for you to purchase this module to use in programming and debugging.
Contents
Package contents
Remark
1 unit
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
No
Optional item. Not included
https://www.globalscaletechnologies.com/t-downloads.aspx
DreamPlug User Guide -page 1 / 12

Advertisement

loading
Need help?

Need help?

Do you have a question about the DreamPlug and is the answer not in the manual?

Questions and answers

Related Manuals for GlobalScale DreamPlug

Summary of Contents for GlobalScale DreamPlug

  • Page 1: Table Of Contents

    DreamPlug User Guide –page 1 / 12 DreamPlug User Guide Thank you for purchasing our DreamPlug – The Power to Innovate! Contents A. For Initial Use ..............................2 B. DreamPlug Server appearance and connecting ports ................. 4 C. LED indication ..............................5 D.

  • Page 2: For Initial Use

    DreamPlug User Guide –page 2 / 12 A. For Initial Use 1. To be used as a Plug Computer: 2. To Be Used as a “Desk Top” Computer. Desktop – 1...
  • Page 3 DreamPlug User Guide –page 3 / 12 Desktop – 2 3. To Have the “DreamPlug” Wall Mounted.

  • Page 4: Dreamplug Server Appearance And Connecting Ports

    DreamPlug User Guide –page 4 / 12 B. DreamPlug Server appearance and connecting ports Ports description- DreamPlug Server Connection port Description Remark RJ45 #1 Gigabit Ethernet port 1 CAT5e or CAT6 cable RJ45 #2 Gigabit Ethernet port 2 CAT5e or CAT6 cable...

  • Page 5: Led Indication

    DreamPlug User Guide –page 5 / 12 C. LED indication LED indication table Color/ Pattern Description Power on LED Solid green Upon power on, this LED lights up WiFi AP mode Solid blue WiFi will go into AP mode as default after boot up...

  • Page 6: Connect To Jtag Board

    DreamPlug User Guide –page 6 / 12 D. Connect to JTAG board 1. Connect 4 pin UART cable 2. Connect 8 pin JTAG cable 3. Connect Mini USB cable here. The other end connects to computer’s USB port. This is the standard 20pin JTAG connector which has the same pin signals as 8 pin cable This DC 2.5V is for Dream Plug CPU...

  • Page 7: Tools And Files You Need To Start Debugging

    DreamPlug User Guide –page 7 / 12 E. Tools and files you need to start debugging 1. Prepare one PC with Fedora 9 (or Fedora 11) Linux operating system 2. Download and install the following tools and utilities File name...

  • Page 8: Basic Procedures For Debugging

    DreamPlug User Guide –page 8 / 12 F. Basic procedures for debugging 1. Connect cables as illustrated in section D. 2. Run terminal program on Linux PC. 3. Type in # minicom –o marvell 4. Power on the DreamPlug Server.
  • Page 9 DreamPlug User Guide –page 9 / 12 Now, you have the full control right of it.

  • Page 10: Wi-Fi / Bluetooth

    DreamPlug User Guide –page 10 / 12 G. Wi-Fi / Bluetooth DreamPlug Server has a built-in WiFi module which is compliance with 8.2.11 b/g standard and Bluetooth 2.1 + Enhanced data rate (EDR). The WiFi works as both client and AP mode but only one at a time.
  • Page 11 DreamPlug User Guide –page 11 / 12 6. Choose this one and click here to connect. 7. Connected 8. Open console terminal, type wlan.sh command to switch client mode.

  • Page 12: Download Sites

    DreamPlug User Guide –page 12 / 12 H. Download sites To download the files for Dreamuplug server, please visit: http://www.globalscaletechnologies.com/t-downloads.aspx Other useful resource links are: http://www.plugcomputer.org/ http://plugcomputer.org/plugwiki/index.php/GuruPlug...
