- Page 1 CL-FT1 Wiring Harness for Cargo Lighting 2020-2021 Ford Transit Van (Low Roof) INSTALLATION MANUAL...
-
Page 2: What's Included
Table of Contents Page 3 - Tools Required For Installing Additional Accessories Page 8 - Wiring Diagram WHAT’S INCLUDED: • Vehicle Specific Wire Harness (CL-FT1) • 6” Cable Ties (25) COMPATIBLE ACCESSORIES: • LED Dome Lamp (STL40489-2) • 1100mm Roof Bow Harness (P-HARRB1) •... -
Page 3: Tools Required
TOOLS REQUIRED: 1. Diagonal Cutters 2. Phillips #2 Drill Bit 3. Drill... - Page 4 STEP 1: Locate the OEM Cargo Lamp connection that is behind the vehicle’s first roof bow on the driver’s side of the vehicle. STEP 2: Unplug the OEM Cargo Lamp connectors and install the CL-FT1 harness between the two connectors.
- Page 5 STEP 3: Install the STL40489-2 lights onto the center of each roof bow; leave the light connector exposed • Peel the red adhesive liners off of the STL40489-2 and stick the light in place • Use the provided 3/4” screws to secure the light to the roof rib STEP 4: Connect the appropriate P-HARRBx roof bow harness to each installed STL40489-2 light.
- Page 6 STEP 5: Use the fir tree cable ties that are packaged with each P-HARRBx to secure the harness to the vehicle’s roof bow. Trim off excess cable tie material with diagonal cutters after harness is secure. STEP 6: Route all P-HARRBx roof bow harnesses alongside the OEM wire harnesses. •...
- Page 7 STEP 7: Plug all installed P-HARRBx harnesses into the mating connectors on the CL-FT1 harness. • Use the provided 6” cable ties to secure all harnesses • Trim off excess cable tie material with diagonal cutters STEP 8: Confirm all installed STL40489-2 lights are operational...
- Page 8 V V e e h h i i c c l l e e R R o o o o f f B B o o w w 1 1 R R o o o o f f B B o o w w 2 2 R R o o o o f f B B o o w w 3 3 R R o o o o f f B B o o w w 4 4 Transit - Low Roof 130"...
- Page 9 Phone – 866-766-2267 E-Mail – support@aampglobal.com EchoMaster is a Power Brand of AAMP Global EchoMaster.com...
