Trane BAYVALV001 Installation Manual

Installation Guide
Service Valve Kit
Odyssey Split System Cooling and Heat Pump
6 to 25 Ton Units
B B A A Y Y V V A A L L V V 0 0 0 0 1 1 : Used with TTA0604*A, TTA0724*A, TTA0764*A,
TTA090**A, TTA1014*A, TTA120**A, TTA1014*C, TTA1204*C,
TWA0604*A, TWA0724*A, TWA0902*A, TWA1014*A,
TWA120**A
B B A A Y Y V V A A L L V V 0 0 0 0 2 2 : Used with TWA0764*A, TWA0904*A
B B A A Y Y V V A A L L V V 0 0 0 0 3 3 : Used with TTA0604*D, TTA0724*D, TTA0764*D,
TTA0904*D, TTA1014*D, TTA1204*D, TWA0604*D,
TWA0724*D, TWA0764*D, TWA0904*D, TWA1014*D,
TWA1204*D
B B A A Y Y V V A A L L V V 0 0 0 0 4 4 : Used with TTA1264*D, TTA1504*D
B B A A Y Y V V A A L L V V 0 0 0 0 5 5 : Used with TTA1564*D, TTA180**D, TTA2014*D,
TTA240**D
B B A A Y Y V V A A L L V V 0 0 0 0 6 6 : Used with TWA1564*D, TWA180**D,
TWA2014*D, TWA240**D
B B A A Y Y V V A A L L V V 0 0 0 0 7 7 : Used with TTA1564*C, TTA1804*C, TTA2014*C,
TTA2404*C
B B A A Y Y V V A A L L V V 0 0 0 0 8 8 : Used with TTA2514*C, TTA3004*C
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
June 2020
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
A A C C C C - - S S V V N N 2 2 1 1 3 3 B B - - E E N N
