South Pacific Industrial VS1500 Owner's Installation & Operations Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Installation & Operation Manual
Please read this user manual carefully before using the product
Model: VS1500 & VS1500C
04/2011
South Pacific Industrial Pty Ltd. Australia
TEL: +61 (0)2 9659 2889 FAX: +61 (0)2 9634 5368
e-mail:info@southpacific.com.au
www.southpacific.com.au
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the VS1500 and is the answer not in the manual?

Questions and answers

Related Manuals for South Pacific Industrial VS1500

Summary of Contents for South Pacific Industrial VS1500

  • Page 1 Owner’s Installation & Operation Manual Please read this user manual carefully before using the product Model: VS1500 & VS1500C 04/2011 South Pacific Industrial Pty Ltd. Australia TEL: +61 (0)2 9659 2889 FAX: +61 (0)2 9634 5368 e-mail:info@southpacific.com.au www.southpacific.com.au...

  • Page 2: Table Of Contents

    CONTENTS FEATURES PACKAGE CONTENTS SPECIFICATIONS INSTALLATION OPERATION MAINTENANCE WARRANTY VIII IMPORTANT INFORMATION PARTS LIST FEATURES  Self tailing rope and chain stainless steel gypsy  Efficient spur gears which provide tremendous lifting capacity  Heavy duty DC motor with long life and high output torque ...

  • Page 3: Package Contents

    HARDWARES : Screw M10 × 100mm × 3 × 3 Flat Washer × 3 Split Washer × 3 SPECIFICATIONS VS1500/VS1500C Suit Boats Size 40ft ~ 60ft Handle Anchor Size 60 lb Comparable Model 1500W Model Input Voltage DC 12V or 24V Max.
  • Page 4 Gear Type / Efficiency Spur Gear/92%~97% Chain and Rope Size Please refer to the chart below Dimension 250Lx160Wx340(420)H mm 16.0kg(35lb) Weight: without Capstan 18.0kg(40lb) with Capstan It is very important to choose the correct type of rope and chain to ensure proper operation of the windlasses.

  • Page 5: Installation

    INSTALLATION TOOLS REQUIRED Drill Adjust spanner Jig saw File 2. PLANE a. First of all, a suitable bow roller must be installed to support the anchor, chain and rope. A bollard or snubbing device should be installed between the bow roller and windlass to tie the rope on while anchored or securing the anchor in the fully-raised position.
  • Page 6 d. Ensure there is a drain in the chain locker and always keep it clear to prevent the water level rising and make sure the chain locker is deep enough to store the rope and chain. If the anchor well is not deep enough the rope and chain will build very quickly and block the entrance.
  • Page 7 f. Mount control device at a suitable position either in the cabin or close to the operating area. g. Connect the windlass, control unit and power source using electric cable indicated below. Keep the power supply cable as short as possible. Too thin and/or too much length of electric cable will reduce the performance of the windlass or cause the circuit breaker to work incorrectly.
  • Page 8 If the winding direction is not as desired, please change over the wires from the windlass to the solenoid K-200. 4. ANCHOR ROPE AND CHAIN To splice the rope to the chain, please follow the steps below. Do not use a hook or shackle.
  • Page 9 STEP 1: Unravel the end of the rope for about 20cm and secure the end of the strands with tape. STEP 2: Pass three strands through the last link of the anchor chain. Untwist the rope to raise a strand just below the tie on the standing part of the rope and insert one strand under it, then pull the strand through.
  • Page 10 STEP 5: For the remained rounds of tucks, take each end over one strand and under the next one to the right, in the same order as before. STEP 6: To finish, pull the ends tight. Cut the excess off with a hot knife.
  • Page 11 3. Keep limbs, fingers, clothing and hair clear of the windlass and anchor to avoid possible personal injury during operation. 4. Tie the anchor rope firmly to the bollard when the anchor is cast and the boat is moored. Do not allow the windlass to take the force of a boat’s drag.

  • Page 12: Voperation

    NOTE: The windlass is designed to lift the anchor, rather than to drag the boat or for mooring. 6. If the anchor is stuck on the seabed or reef, detach it by the boat’s engine power before operating the windlass or else it may cause damage or overstrain the windlass.

  • Page 13: Maintenance

    11. The chain tunnel cover can be opened by lifting it up and turning it sideway. ★OPERATING SAFETY IS THE FIRST PRIORITY★ MAINTENANCE 1. The V Series windlasses come with a sealed grease lubricated gear box. There is no need for extra lubrication. 2.

  • Page 14: Warranty

    WARRANTY 1. The warranty is effective only under conditions of normal operation, maintenance and without modification of the product. 2. CLAIMS If the product needs servicing, please send it back (or bring it to us) with the proof of purchase and we will investigate the product free of charge before repairing.
  • Page 15 2. If a product is accepted for refunding, the manufacturer is not responsible for any renovation of the boat.

  • Page 16: Ix Parts List

    IX PARTS LIST: Parts No. Item: VS1500(C) R0354-R Capstan Nut R0354-L Gypsy Nut R0353 Washer M24x0.5 usu R0378 Capstan R0372 Capstan Socket R0369 Gypsy Cover R0360 Gypsy 10mm R0380 Gypsy 8mm R0351-40 Screw M8x40 sus R0028 Washer M8x1.0 R0357-8 Tension Arm 8mm...
  • Page 18 Thank you for choosing South Pacific products Purchase Date: Model: Supplier Name: Address: Phone: Fax:...
