Laser Sight
Safety, Operation, Maintenance
& Parts Manual
LS for LT40 & LT70 Sawmills
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
Form #899

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Laser Sight and is the answer not in the manual?

Questions and answers

Related Manuals for Wood-mizer Laser Sight

Summary of Contents for Wood-mizer Laser Sight

  • Page 1 Laser Sight Safety, Operation, Maintenance & Parts Manual LS for LT40 & LT70 Sawmills Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. Form #899...

  • Page 2: Table Of Contents

    Table of Contents Section-Page SECTION 1 SAFETY SECTION 2 LASER INSTALLATION Laser Installation - LT40 ............... 2-1 Laser Installation - LT70 ............... 2-5 SECTION 3 SWITCH INSTALLATION 3.1. Switch Installation - LT40..............2-7 3.2. Switch Installation - LT70..............2-10 SECTION 4 LASER OPERATION Laser Operation - LT40 .................

  • Page 3: Safety

    Safety SECTION 1 SAFETY This symbol calls your attention to instructions concerning your personal safety. Be sure to observe and follow these instructions. This symbol accompanies a signal word. The word DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 4: Laser Installation

    Laser Installation Laser Installation - LT40 SECTION 2 LASER INSTALLATION Before installing the laser option, be aware that the laser beam can not be seen in direct sunlight. The laser option is best for indoor cutting applications. Laser Installation - LT40 1.
  • Page 5 Laser Installation Laser Installation - LT40 See Figure 2-2. FIG. 2-2 Route the wire from the laser assembly as shown: See Figure 2-3. Install one of the provided hose clamps to the laser assembly wire. Remove the  third slide pad nut from the bottom, install the hose clamp as shown and reinstall the slide pad nut.
  • Page 6 Laser Installation Laser Installation - LT40 FIG. 2-3 Reinstall the drive side pulley guard, keeping the lower part of the laser assembly wire outside the guard as shown. Make sure the wire routes inside the guard at the lower right hand corner.
  • Page 7 Laser Installation Laser Installation - LT40 washers and bolts to secure the EMT clamps in place as shown. FIG. 2-4 Laser Installation 97LS97doc062612...

  • Page 8: Laser Installation - Lt70

    Laser Installation Laser Installation - LT70 Laser Installation - LT70 1. Locate the four square mounting holes on the saw head near the bottom of the drive-side blade housing. Mount the laser/bracket assembly to the saw head using the four carriage head bolts, flat washers and lock nuts.
  • Page 9 Laser Installation Laser Installation - LT70 Reinstall the drive belt guard. FIG. 2-6 Laser Installation 97LS97doc062612...

  • Page 10: Switch Installation

    Switch Installation Switch Installation - LT40 SECTION 3 SWITCH INSTALLATION 3.1. Switch Installation - LT40 See Figure 3-1. LT40 AC Panel Here cut out the hole for switch FIG. 3-1 97LS97doc062612 Switch Installation...
  • Page 11 Switch Installation Switch Installation - LT40 See Figure 3-2. LT40 DC Panel Here cut out the hole for switch FIG. 3-2 5. Install the toggle switch, nylon washer, and rubber boot to the front panel as shown. Connect the quick connect terminal on the existing laser option wire (labeled #25) to ...
  • Page 12 Switch Installation Switch Installation - LT40 See Figure 3-3. FIG. 3-3 97LS97doc062612 Switch Installation...

  • Page 13: Switch Installation - Lt70

    Switch Installation Switch Installation - LT70 3.2. Switch Installation - LT70 1. Unbolt the front panel from the control box. Use the hole in the front panel as a template to cut out a hole in the decal for the laser option switch. NOTE: The cut hole will be slightly smaller than indicated by the dotted line on the decal.
  • Page 14 Switch Installation Switch Installation - LT70 See Figure 3-5. LT70 DC Panel Here cut out the hole for switch FIG. 3-5 2. install the toggle switch, nylon washer, and rubber boot to the front panel as shown. 3. DC Only: Connect the quick connect terminal on the existing laser option wire (labeled #25) to the bottom tab on the toggle switch.
  • Page 15 Switch Installation Switch Installation - LT70 AC Only: Connect the ring terminal on the fuse assembly to the ‘ACC’ post on the key switch. See Figure 3-6. FIG. 3-6 Switch Installation 97LS97doc062612 3-12...

  • Page 16: Laser Operation

    LASER OPERATION Laser Operation - LT40 SECTION 4 LASER OPERATION When properly installed, the laser option will guide you in making cuts. To turn on the laser, raise the laser toggle switch to the ON (1) position. To turn off the laser, lower the laser toggle switch to the OFF° ( 0 )position. Laser Operation - LT40 See Figure 4-1.
  • Page 17 LASER OPERATION Laser Operation - LT40 See Figure 4-2. LT70 DC Panel FIG. 4-2 LASER OPERATION 97LS97doc062612...

  • Page 18: Laser Operation - Lt70

    LASER OPERATION Laser Operation - LT70 Laser Operation - LT70 See Figure 4-3. LT70 AC Panel FIG. 4-1 97LS97doc062612 LASER OPERATION...
  • Page 19 LASER OPERATION Laser Operation - LT70 See Figure 4-4. LT70 DC Panel FIG. 4-2 LASER OPERATION 97LS97doc062612...

  • Page 20: Laser Alignment

    Laser Alignment Laser Alignment - LT40 SECTION 5 LASER ALIGNMENT Laser Alignment - LT40 1. Stationary sawmills should be setup on firm, level ground before proceeding with align- ment. Shim the feet so the weight of the sawmill is evenly supported. 2.
  • Page 21 Laser Alignment Laser Alignment - LT40 See Figure 5-2. If the laser beam is adjusted too low, it will show against the side of the cant. But, in order to see a beam that is adjusted too high, it may be necessary to extend the edge of the cant upward.

  • Page 22: Laser Alignment - Lt70

    Laser Alignment Laser Alignment - LT70 Laser Alignment - LT70 1. Stationary sawmills should be setup on firm, level ground before proceeding with align- ment. Shim the feet so the weight of the sawmill is evenly supported. 2. Make sure the sawmill is properly aligned (see the Alignment Section of your Sawmill Operator’s Manual.) 3.
  • Page 23 Laser Alignment Laser Alignment - LT70 See Figure 5-2. If the laser beam is adjusted too low, it will show against the side of the cant. But, in order to see a beam that is adjusted too high, it may be necessary to extend the edge of the cant upward.

  • Page 24: Replacement Parts

    Replacement Parts Laser Assembly LT40 SECTION 6 REPLACEMENT PARTS Laser Assembly LT40 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. LASER, CUTTING POINTER LT40 KIT 505712 BRACKET, LASER LT40 505163-1 COVER, LASER LT40 505162-1 LASER, Z5M18B-F-532-IG90 LINEAR, GREEN 501025 SCREW,M5x16-8.8 HEX SOCKET HEAD CAP ZINC F81000-25...

  • Page 25: Laser Assembly Lt70

    Replacement Parts Laser Assembly LT70 Laser Assembly LT70 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. LASER, CUTTING POINTER LT70 KIT 505713 505161-1 BRACKET, LASER LT70 BRACKET, LASER SMB18SF 503469 LASER, Z5M18B-F-532-IG90 LINEAR, GREEN 501025 WASHER, 8.4 FLAT,ZINC F81054-1 F81032-2 NUT,M8-8-B,HEX,NYLON LOCK ZINC...
