AutoPatch Half-Y User's Reference Manual

Audio/ video distribution matrix
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
half-
User Reference Manual
CPU Version A0
Document Version
A0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Half-Y and is the answer not in the manual?

Questions and answers

Related Manuals for AutoPatch Half-Y

Summary of Contents for AutoPatch Half-Y

  • Page 1 half- User Reference Manual CPU Version A0 Document Version...
  • Page 2 Notices AutoPatch © 1996, all rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopy- ing, recording, or otherwise, without the prior written permission of AutoPatch. Copyright protec-...
  • Page 3 (2) years from the date of ship- ment shown on the sales invoice or warranty registration on file. With respect to any AutoPatch product found to be defective during this warranty period, AutoPatch’s liability and Buyer’s reme- dies under this warranty shall be limited solely to repair, replacement, or credit, at AutoPatch’s op-...

  • Page 4: Table Of Contents

    Table Of Contents Introduction How to Use This Manual ············································································ii Typographical Conventions ·····································································iii Definition of Terms Used in This Manual················································iii Technical Support ·····················································································iv Chapter 1—Installing the Distribution Matrix Unpacking the half- ···············································································1-2 Installing the ··················································································1-2 half- Connecting Inputs and Outputs ····························································1-3 Connecting the Vertical Interval Sync Signal·······································1-4 Connecting and Applying Power···························································1-4 Startup Sequence····················································································1-5...
  • Page 5 Power Connector······································································································3-4 Appendix A — AutoPatch Service / Returns Policy Service·····································································································A-1 Return Authorizations············································································A-1 Claims for Shipping Damages·······························································A-1 Replacement Policies and Procedures ················································A-2 Special Notice ·························································································A-3 Appendix B—Troubleshooting the half- Appendix C—DB9 Port Serial External Controllers Installing Serial Controllers···································································C-2 Operating Serial Controllers··································································C-3 Entering BCS Commands ·······················································································C-3...
  • Page 6 Introduction The AutoPatch half- Distribution Matrix ( half- ) is a signal switching device that can route audio, video, and data signals. uses upper and lower Input/Output (I/O) boards as half- the switching path for up to twelve signals. The...

  • Page 7: Introduction

    Appendix A – AutoPatch Service/Returns Policy Appendix A presents the AutoPatch Service/Returns Policy. Please note that if you need to return an enclosure, it should be returned in its original shipping box.

  • Page 8: Typographical Conventions

    Introduction Typographical Conventions In this manual, text conventions are used to designate particular meanings, such as key specifications and particular matrix operations. The convention for X/Y Control Panel keys is initial caps. For example, “press the second Input key,” specifies the second white key from the left on the control panel.

  • Page 9: Technical Support

    System - Must have one or more controllers and one matrix. Technical Support AutoPatch provides technical support from 6 a.m. to 5 p.m. PST Monday-Friday. Before calling with a question, please consult this manual first. If the manual cannot fully answer...

  • Page 10: Chapter 1-Installing The Distribution Matrix

    Chapter 1—Installing the Distribution Matrix half- distribution matrix is a signal switching device that has the ability to route any of its inputs to one or more of its outputs. Depending on configuration, your matrix can route audio, video, and data signals. The enclosure contains a power supply, CPU board, and Input/Output (I/O) boards.

  • Page 11: Unpacking The Half

    Keep your shipping carton in case you need to return the product or ship it to other sites. Note: AutoPatch will not be responsible for damage to returned products incurred during shipping due to insufficient packaging. If requested, AutoPatch will supply a new shipping carton at cost.

  • Page 12: Connecting Inputs And Outputs

    Getting Started figure 1.3 Attach ears with provided screws 1.3 Connecting Inputs and Outputs Output Connectors Input Connectors figure 1.4 Input and Output connectors Note: Input and output connectors may vary. Figure 1.4 displays the input and output connectors for a 12x4 with BNC video connectors on the upper level, half- and pluggable 3-position terminal block connectors for...

  • Page 13: Connecting The Vertical Interval Sync Signal

    Chapter 1 Single-Ended Stereo Input Single-Ended Stereo Output Left GND Right Left GND Right Direction Signal Signal Output Output Signal Signal Signal Input Input Direction Single-Ended Mono Input Single-Ended Mono Output Input Output Direction Signal Output Signal Signal Input Direction figure 1.5 Single-ended stereo and mono connections 1.4 Connecting the Vertical Interval Sync Signal The sync processor allows switching to occur during the...

  • Page 14: Startup Sequence

    Getting Started the specified range. If you did not receive a power cord with your matrix, contact your authorized AutoPatch dealer. To apply power, toggle the power switch up. To turn power off, toggle the power switch down. After applying power, test the I/O connections by making a switch.

  • Page 15: Chapter 2-Operating The Distribution Matrix

    Please note that unless otherwise specified, all the procedures in this chapter are written for an AutoPatch X/Y Control Panel. For instructions on operating your matrix from an external serial controller, refer to Appendix C in this manual.

  • Page 16: Making And Disconnecting Switches

    Chapter 2 2.1 Making and Disconnecting Switches Level LEDs Input keys Output keys Level 2 key Level 1 key Crosspoint LEDs Power LED figure 2.1 Local X/Y Control Panel, 12x4 Switches can occur on one or both I/O levels. By activating one level and not the other, your matrix can perform breakaway switches in a composite signal set that utilizes both levels.

  • Page 17: Checking Status

    Operating the Distribution Matrix 2.2 Checking Status Status is constantly displayed in the crosspoint LEDs for the active level. If your levels have different I/O configurations, check the status of one level at a time. To check status for one level, activate it by selecting its Level key.

  • Page 18: Chapter 3-The Enclosure And Its Parts

    Chapter 3—The Enclosure and Its Parts The appearance of the enclosure is dependent on several factors, including control method, signal type, and I/O configuration. This chapter describes the physical features of a typical half- enclosure. This chapter covers: Front of an Enclosure Rear of an Enclosure...

  • Page 19: Front Of An Enclosure

    Power LED figure 3.1 Blank Front Panel The Blank Front Panel has the Power LED to indicate when the matrix is powered up and the AutoPatch logo. See figure 3.1. Use an external controlling device in conjunction with this front panel.

  • Page 20: Input Keys

    3.2.2 DB-9 Port The half-Y can be ordered with zero to two DB-9 ports or other type of external controller interface. Use the DB-9 ports for controlling the matrix with an external controlling device that uses RS-232 or RS-422.

  • Page 21: Power Switch

    Chapter 3 3.2.4 Power Switch Power Switch DB-9 Port Power Connector Vertical Interval Sync Connector figure 3.5 Enclosure CPU The power switch is on the left side of the enclosure, between the power connector and the vertical interval sync connector. Toggle the switch up to turn the enclosure on, and down to turn the enclosure off.

  • Page 22: Appendix A - Autopatch Service / Returns Policy

    RMA number clearly stated on the outside of each carton and, if possible, in original packing container(s). Note: AutoPatch will not be responsible for damage incurred in shipping due to insufficient packaging. If requested, AutoPatch will supply a new shipping carton at cost.

  • Page 23: Replacement Policies And Procedures

    Following is a list of steps to take in the event of a problem with your Auto- Patch half- During the warranty period: 1. Describe the problem to an AutoPatch dealer, regional representative, or the AutoPatch customer service department. 2. Upon verification of a problem that requires factory...

  • Page 24: Special Notice

    (30) days following invoice date. Special Notice AutoPatch reserves the right to modify or discontinue designs, specifications, warranties, and policies without notice. All data with regard to model num- bers, series, specifications, and prices in our literature have been thoroughly reviewed and edited.

  • Page 25: Appendix B-Troubleshooting The Half

    Appendix B—Troubleshooting the half- half- has no field-serviceable parts. This chapter presents some quick fixes to common problems. If you experience the following problems... Unable to make switches from the front panel The front panel may be locked. Make sure the LED for the level you want to make a switch on is illuminated.

  • Page 26: Appendix C-Db9 Port Serial External Controllers

    Appendix C – DB-9 Port Serial External Controllers External control of the half- can be effected via the DB-9 port. The DB-9 port accepts BCS commands which are ASCII characters. External controllers include PCs, Macintosh computers, and third party serial devices. This appendix covers: Installing Serial Controllers Operating Serial Controllers...
  • Page 27 Serial communication protocol is set at the factory when your matrix is ordered. Use serial cable that corresponds to the factory set communication protocol. If uncertain about the communication protocol, contact an authorized AutoPatch dealer. AutoPatch: DB-9 IBM PC: DB-25 IBM PC: DB-25 AutoPatch: DB- TD #2........

  • Page 28: Operating Serial Controllers

    C.2.1 Entering BCS Commands AutoPatch Distribution matrices are programmed using a set of ASCII characters called Basic Control Structure (BCS). BCS command syntax is designed to parallel the operations of the control panel. So instead of pressing the keys on the control panel, press the keys on the external serial controller keypad.
  • Page 29 Appendix C serial protocol is as follows: half- 9600 baud 8 data bits 1 stop bit No parity All BCS entries must be complete commands. Terminate any incomplete or erroneous commands with an ‘X’ (Cancel) and then re-type the command. Typing a space or a backspace does not cancel a previous command.

  • Page 30: Bcs Software Handshaking

    C.2.2 BCS Software Handshaking All AutoPatch software provides software handshaking. However, other software may not. If you are using something other than AutoPatch software, make sure it implements the following handshaking requirements. Each character received by the distribution matrix CPU is echoed through the DB-9 port.

  • Page 31: Autoroute Event Scheduler

    Appendix C C.3.2 AutoRoute Event Scheduler AutoRoute Event Scheduler is a DOS-based control program that schedules events for matrix processing. Enter command lines in the string file, which is scheduled in the event file. The event file is processed by AutoRoute Event Scheduler. Processing the event file allows the software to change the distribution matrix configuration according to user defined parameters, including command and event timing.

  • Page 32: Appendix D-Product Specifications

    Appendix D – Product Specifications D.1Physical Features Height 1 ru Width 17 inches (43.18 cm) Depth 6.75 inches (17.14 cm) Weight 3.5 lb (1.6 kg) Mounting options Standard 19 in. EIA rack Desktop Connectors BNC for video 3-position terminal block for audio RCA for audio and video Control options Local X/Y Control Panel...

  • Page 33: Glossary

    Glossary Basic Control Structure (BCS) - A string of alphanumeric ASCII characters used to serially control the matrix from a PC keyboard. BCS commands can be used to execute any command that can be keyed-in from the con- trol panel. half- BAUD rate - The speed that communications travel through the DB-9 port.
  • Page 34 Inputs and Outputs - inputs and outputs are the physical connector locations on the rear of an enclosure. Each enclo- sure holds a maximum of 12 inputs and 4 outputs. Level - The half-Y uses the term level to refer to either the upper or lower I/O board. Levels are used for signal breakaway.

  • Page 35: Index

    1-2 Deleting Keys Erroneous BCS Commands, C-5 Level (Breakaway), 3-2 Switches, 2-2 Input, 3-3 DB-9, 3-3 Output, 3-3 Distribution Matrix Defined, iii half-Y, 1-1 checking status, 2-2 Level, see Breakaway Local X/Y Control Panel Definition, iii Locking, 2-3...
  • Page 36 Status, 2-3 Operating Switches External controller, C-3 Locking Out, 2-3 matrix, 2-2 Making a Switch, 2-2 Disconnecting a Switch, 2-2 Status, 2-3 Sync (Vertical Interval) Pins Connectors, 3-3 Fastening, 1-4 Used to connect controllers, C-2 Using, 2-3 Power Applying, 1-4 Connecting, 1-4 Switch, 3-4 Tables...
  • Page 37 Differential Audio Supplement for the half- User Reference Manual version A0 To handle differential audio signals we offer a half- that has pluggable 5-position block terminal connectors. The figure below displays differential audio input and output connections for both stereo and mono audio signals. Note: To help alleviate low frequency noise problems in audio system twisted pair interconnections, connect the shield at one end only.
