- Page 1 Global TOP 10 in Healthcare SQUVA USER’S MANUAL SQ UV ACTIVATOR DENTIS CO., LTD. 99, Seongseoseo-ro, Dalseo-gu, Daegu, Korea Tel. +82-53-583-2804, FAX. +82-53-583-2806 www.dentis.co.kr / www.dentisimplant.co.kr...
-
Page 2: Table Of Contents
CONTENTS 1. Purpose of Use & Conditions for Use ......................... 3 1.1 Purpose of Use ................................... 3 1.2 Conditions for Use ................................3 2. CE & FCC....................................3 2.1 FCC warning statement ..............................3 2.2 CE statement ..................................4 3. Warnings ....................................5 4. -
Page 3: Purpose Of Use & Conditions For Use
1. Purpose of Use & Conditions for Use 1.1 Purpose of Use The SQ UV ACTIVATOR is a product designed to increase hydrophicility on implant surface. 1.2 Conditions for Use Ÿ Condition of Use Temperature : 0 - 40 ℃ ž... -
Page 4: Ce Statement
- Consult the dealer or an experienced radio/TV technician for help Ÿ FCC Part 15.21 Changes or modifications not expressly approved by the manufacturer (or party responsible) for compliance could void the user’s authority to operate the equipment Ÿ RF Exposure This equipment should be installed and operated with minimum 20 cm between the radiator and your body. -
Page 5: Warnings
3. Warnings Warnings Ÿ Please read the USER manual before using the product. Ÿ Check all components after opening this product. Ÿ Please install this product in a well ventilated place. Ÿ Do not use it in uneven, sloping, or vibrating area. Ÿ... -
Page 6: Warranty
Ÿ Use the FIXTURE support in the correct position on the TRAY. Ÿ Do not place objects on the TRAY. Ÿ Do not place items on top of the product Ÿ When operating the instrument, be careful not to cause external shock Ÿ... -
Page 7: Components And Specifications
5. Components and Specifications 5.1 Components ② ④ ③ ① Description ① SQ UV Activator ② Adapter & Power Plug ③ FIXTURE Driver KIT ④ RFID CARD 5.2 Specifications Category Unit Specification Remark Rated power input AC 100 – 240 V , 50/60 Hz Power consumption DC 24 Adapter Output... -
Page 8: Use
6. Use 6.1 Components MOTION SENSOR SPEAKER 5” TOUCH LCD PANNEL TRAY (FIXTURE INSERTION) RFID CARD SLOT HANDLE Product LABEL DC POWER ON/OFF SWITCH INPUT SOCKET Be sure to read the manual before using this product. -
Page 9: How To Use
6.2 How to use Step Image Description Check the SQUVA components SQUVA Adapter RFID CARD Power Cord FIXTURE Driver KIT USER’S MANUAL Connect the adapter and power cord. Adapter outpt “4Pin Jack” at the back of the body. (Pay attention to direction). - Page 10 Press the “OPEN” button on the LCD. (Make sure the TRAY is downward.) Prepare a FIXTURE to be reformed. Close the sterilized FIXTURE support by rotating it clockwise two to three times. The FIXTURE support must be sterilized before use) Do not allow FIXTURE to touch hands or other parts) Handle the ampoule to prevent...
- Page 11 With the TRAY lowered, press the "START" button on the LCD screen to start the refinement. Ensure that FIXTURE driver is correctly engaged before pressing the "START" button) Does not work when tray is raised) If "Complete" is displayed on the LCD screen, verify that the reforming has been completed.
-
Page 12: Control Part
6.3 Control part Image Explanation Lower the TRAY to where the FIXTURE driver is to be placed. TRAY with FIXTURE driver raised. Reforming starts. Display the number of RFID CARDs available. ※ when there are zero remaining, contact supplier to recharge the CARD . -
Page 13: Sensor Explanation
6.4 Sensor Explanation ※ The "non-contact sensor" at the top of the LCD can detect the user's hand at a distance of 2 cm and perform "START" action. (Prevent infection by non-contact method) Be careful not to touch motion sensors to prevent infection. Image description Operation in the CLOSE state of the... -
Page 14: Cleaning And Sterilization
8. Cleaning and Sterilization 8.1 Cleaning and Sterilizing Fixture Driver The used kits and instruments should be cleaned with distilled or flowing water with a temperature of 30~40℃, using a brush for 20 seconds to wash away any remaining blood and external materials. Tools which have inner parts needs to be cleaned up, such as a torque wrench, should be dismantled to wash away any remaining blood and foreign materials Make 1% TergazymeTM mixture mixed 1L 30~40℃... - Page 15 The adapter is not connected to the Connect the adapter to the main body main body Check the connection between the power If the power cord is cord and the adapter. not properly Connect the power cord to a multi-tap or engaged AC power source.
- Page 16 EQ5QPP-PM020 (V0.9) Date : 2020/10/26 DENTIS Co., LTD. http://www.dentis.co.kr/eng, http://www.dentisimplant.co.kr/eng KOREA +82-2-869-6020 / USA +1-323-677-4363 ⓒ2019 DENTIS CO.,LTD. All Right Reserved. Specifications are subject to change without notice. Trademarks are the property of DENTIS CO., LTD. Or their respective owners.
