- Page 1 AIR IMPACT WRENCH Rev.0 112019 FGA 316/L The reproduction of this document (even in partial form) is prohibited without the Fasangas S.r.l. authorization...
- Page 2 CONTENT GENERAL WARNINGS TECHNICAL FEATURES IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS FOR THE USE OF THE TOOL MAINTENANCE TROUBLESHOOTING DISPOSAL INFORMATIONS EU DECLARATION OF CONFORMITY WARRANTY...
- Page 3 2. TECHNICAL FEATURES Model: FGA 316/L Type: impact wrench with long shaft Lenght of shaft: Weight:...
- Page 4 3. IMPORTANT SAFETY INSTRUCTIONS When using this air tool, the following basic safety precautions should always be followed to reduce the risk to personal injury: Always wear safety glasses with side shields in accordance with applicable regulations. Air powered equipment are capable of propelling materials such as metal chips, saw dust and other debris at high speed, which could result in serious eye injury.
- Page 5 4. INSTRUCTIONS FOR USE OF THE TOOL Before each use: ATTENTION Before proceeding with the operation of lubrication, detachment / attachment, adjustment or installation of accessories, disconnect the air supply hose from the tool, having first taken care to close the tap of compressed air supply. ATTENTION Always use clean, dry air at 90 PSI (6.2 bars) maximum air pressure.
- Page 6 To switch rotation, push the switch (2). WARNING Do not change the tool direction/speed of rotation while it is running. To adjust output power, turn the regulator (3) the medium torque that correspond at 2/3 of the max. torque approximately To start the machine, simply pull the trigger (1).
- Page 7 7. DISPOSAL INFORMATIONS When the tool is not usable and not repairable, dispose it according to regulations of the place in order to safeguard the environment. 8. EU DECLARATION OF CONFORMITY This product complies with the dispositions of the following European directives and harmonized standards: EN ISO 12100:2010 EN ISO 11148-6:2012 2006/42/EU...
