OEYE-RED
User Manual
Company Address : 1406 14th Floor Block D Building 3
Phase I Tianan yungu Longgang district Shenzhen
Guangdong China
Factory Address : No.2nd Floor Building A Jingjiang Industrial
Park NO.101 Shangwei Road Longhua District Shenzhen
Guangdong China
Website : www.portkeys.shop
SHENZHEN PORTKEYS ELECTRONIC TECHNOLOGY CO.,LTD
Email : sales@pkscorp.com
Advertisement
Table of Contents
Related Manuals for PortKeys OEYE-RED
Summary of Contents for PortKeys OEYE-RED
- Page 1 Company Address : 1406 14th Floor Block D Building 3 Phase I Tianan yungu Longgang district Shenzhen Guangdong China Factory Address : No.2nd Floor Building A Jingjiang Industrial Park NO.101 Shangwei Road Longhua District Shenzhen Guangdong China Website : www.portkeys.shop SHENZHEN PORTKEYS ELECTRONIC TECHNOLOGY CO.,LTD Email : sales@pkscorp.com...
- Page 2 OEYE-RED OEYE-RED Before OEYE controls RED camera ,please set the Control protocol of RED camera to : REDLINK Command Protocol Product Appearance Size Set path ： Menu->Setting->Setup->Communication->Serial->Ctrl Protocol-> REDLINK Command Protocol Menu>Settings>Setup>Communication>Serial Search... Back Close OLED Silica Camera Serial Ethemet...
-
Page 3: Standard Accessories
OEYE-RED OEYE-RED Silicone Eye Mask Standard Accessories Installation Instruction OEYE-RED *1 Safety Plastic Box *1 Power Cord(3pin Aviation SDI Cable *1 Connector - D-TAP) *1 Pipe Clamp *1 Power Cord(5pin Aviation Warm Prompt *1 Connector - 5pin Aviation U Disk(Manual，3D LUTs，... - Page 4 OEYE-RED OEYE-RED Supported input/output resolution and frame rate In put Sourc e HDMI signal HDMI 4096×2160p@24Hz 3840×2160p@23.97Hz,24Hz,25Hz,29.97Hz,30Hz HD/SDI 1920×1080p@23.97Hz,24Hz,25Hz,29.97Hz,30Hz,50Hz,59.94Hz,60Hz Back 1920×1080psf@23.97Hz,24Hz,25Hz,29.97Hz,30Hz 1920×1080i@50Hz,59.94Hz,60Hz 1280×720p@50Hz,59.94Hz,60Hz 720×576p&720×576i@50Hz 720×480p&720×480i@50Hz,59.94Hz,60Hz Supported input/output resolution and frame rate SDI signal 1920×1080p@50fps,59.94fps,60fps 1920×1080p@50Hz,59.94Hz,60Hz YUV422 function selection Scroll direction key and menu Kay can adjust the function 1920×1080p@23.98Hz,24Hz,25Hz,29.94Hz,30Hz YUV444/YUV422/RGB444...
-
Page 5: Video Config
OEYE-RED OEYE-RED Video Config Flip Control Display Flip Mode On/Off Brightness ～ H Flip On/Off Contrast ～ On/Off V Flip Chroma ～ Osd Flip Mode On/Off 0/10/20/30/40/50/60/70/80/90/100 Sharpness On/Off H Flip Tint ～ On/Off V Flip Color Temperature 5600K/6500K/7500K/9300K/Manual Back Backlight ～... -
Page 6: Function Setup
*The parameters can be adjusted in the +/ - button of the function. Firmware （Press menu key and middle key of direction key） Version Information Firmware Ver OEYE-RED-V1.01.24 Apply 3D LUT mode and it will E XI T （Click MENU as Confirm）... - Page 7 OEYE-RED OEYE-RED UnderScan Setting Fast to Set the Funtion Parameter Factor 50～100 Long press 3 seconds will be allowed to enter into the Exit "Function Set" to set the factor the function Peaking Setting 1/2/3/4/5/6/7/8/9/10 Factor Color Red/Green/Blue/White Histogram Setting...
- Page 8 OEYE-RED OEYE-RED Audio Meters Grids Setting Audio Meters On/Off Grids Off/1/2/3/4/5/6/7/8/9/10 Position Top/Left/Division/Right/Bottom Color White/Red/Green/Blue/Black Blending Exit 0～100 Exit Pixel To Pixel Setting Universal Software Upgrade Tutorial Position User/Middle/L+T/R+T/R+B/L+B X Offset -240 ～ +240 Attention: Y Offset -270 ～ +270 1、...
- Page 9 OEYE-RED OEYE-RED Click and confrim Supply power to the upgrade. monitor,insert the U disk Are You Sure？ USB Upgrade Port with upgrade file into the USB interface of the body. Disk MAIN > Boot up the monitor,click Input Source Upgrading is in >...
