Parker IQAN-LSL Quick Start Manual

Wiring diagrams

Pin # Signal/Function C1
1 GND
2 VS (+5V)
3 VOUT-A (primary)
4 VOUT-B (secondary)
Mating connector kit: 5031097
Pin # Signal/Function C2
1 DOUT, MAX 200 mA
2 +BAT
(+12V, +24V)
Mating connector kit: 5031098 with switch
Pin # Signal/Function C1
4 VOUT-B (secondary)
3 VOUT-A (primary)
Mating connector kit: 5031113
Pin # Signal/Function C1
6 +BAT (+12V, +24V)
5 DOUT, MAX 200 mA
4 VOUT-B (secondary)
Mating connector kit: 5035014
Pin # Signal/Function C1
6 +BAT (+24V only)
5 GND (detent magnet)
4 VOUT-B (secondary)
Mating connector kit: 5035014
Pin # Signal/Function C1
8 +BAT (+24V only)
7 GND (detent magnet)
6 +BAT (+12V, +24V)
5 DOUT, MAX 200 mA
Mating connector kit: 5035015
-S (AMP/Tyco)
C2 C1
Pin # Signal/Function
1 GND
or
2 +BAT
(+24V only)
Mating connector kit: 5031098 with detent
-D (Deutsch DT)
Pin # Signal/Function
1 GND
2 VS (+5V)
Pin # Signal/Function
1 GND
2 VS (+5V)
3 VOUT-A (primary)
with switch
Pin # Signal/Function
1 GND
2 VS (+5V)
3 VOUT-A (primary)
with detent
Pin # Signal/Function
1 GND
2 VS (+5V)
3 VOUT-A (primary)
4 VOUT-B (secondary)
with switch and detent
IQAN-LSL
C2

Dual sensor output

90% Vs
50% Vs
10% Vs
-100%
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS AND/OR
SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL
INJURY AND PROPERTY DAMAGE.
This document and other information from Parker Hannifin Corporation, its subsidiaries and authorized distributors provide
product and/or system options for further investigation by users having technical expertise. It is important that you analyze
all aspects of your application, including consequences of any failure, and review the information concerning the product or
system in the current product catalogue. Due to the variety of operating conditions and applications for these products or
systems, the user, through its own analysis and testing, is solely responsible for making the final selection of the products
and systems and assuring that all performance, safety and warning requirements of the application are met.
The products described herein, including without limitation, product features, specifications, designs, availability and pricing,
are subject to change by Parker Hannifin Corporation and its subsidiaries at any time without notice.
For further information see:
HY33-8302-IB/UK Instructions IQAN-LSL

Installation IQAN-LSL

VDC out
80
60
40
20
0
-20
-40
-60
-80
Deflection
Neutral 100%
position
WARNING
Publ.no: HY33-8302-IS/UK
Ed. 05/2011
task oriented control
or expansion module
-40 - +70 °C
(2004/108/EC)
Eng. no: M5010029A
Rev. E
