TECHNICAL SPECIFICATIONS
Standards
Radio Technology
Data Transfer Rate
Receiver Sensitivity
Frequency Range
Modulation Schemes
Channels
Media Access Protocol
Security
Driver Support
Continuous Current
Consumption
Temperature
Humidity
Dimensions
Certifications
IEEE 802.11N
IEEE 802.11b Direct Sequence Spread Spectrum (DSSS) IEEE 802.11g Orthogonal
Frequency Division Multiplexing (OFDM)
802.11g: Up to 54Mbps (6/9/12/18/24/36/48/54)
802.11b: Up to 11Mbps (1/2/5.5/11)
802.11n: Up to 300 Mbps (HT40:30/60/90/120/180/240/270/300)
Sensitivity for 802.11b
11 Mbps (CCK): -87dBm
5.5 Mbps (CCK): -88dBm
2 Mbps (DQPSK): -89dBm
1 Mbps (DBPSK): -91dBm
(typically @PER < 8% packet size 1024 and @25ºC + 5ºC)
Sensitivity for 802.11g
54 Mbps (OFDM): -72dbm
48 Mbps (OFDM): - 75dbm
36 Mbps (OFDM): -77dbm
24 Mbps (OFDM): -80dbm
12 Mbps (OFDM): -85dbm
6 Mbps (OFDM): -88dbm
(typically @PER <10% packet size 1024 and @25ºC + 5ºC)
Sensitivity for 802.11n
300 Mbps (OFDM): -63dbm
(typically @PER <10% packet size 1024 and @25ºC + 5ºC)
2412 ~ 2462 MHz (North America)
2412 ~ 2472 MHz (General Europe)
2412 ~ 2484 MHz (Japan)
DBPSK, DQPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM)
1 ~ 11 channels (FCC) 1 ~ 13 channels (ETSI) 1 ~ 14 channels (Japan)
CSMA/CA with ACK
64/128-bits WEP Encryption; WPA
Physical and Environmental
Windows 98se, Windows 2000, Windows ME, Windows XP
802.11n:
2TX: 610mA, 3RX: 570mA
Operating Temp：0ºC ~ 55ºC
Storage：-20ºC ~ 65ºC
5% ~ 95% RH, no condensation
60 x 44.60 x 3.5 mm (W x H x D)
FCC Part 15.247 for US, ETS 300 328 for Europe,
20
