SERVICE MANUAL
DVD DIGITAL CINEMA SYSTEM
7
2006
MB541
TH-P3A,TH-P3US,TH-P3UB,
TH-P3UW,TH-P3UX,TH-P3UY,
TH-P3UJ,TH-P3UG,TH-P3UN
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
SP-THP3F
SP-THP3S
SP-THP3C
TABLE OF CONTENTS
COPYRIGHT © 2006 Victor Company of Japan, Limited
SP-WP5
SP-THP3F
SP-THP3S
XV-THP3
No.MB541
2006/7

Advertisement

Table of Contents
loading

Related Manuals for JVC TH-P3A

Summary of Contents for JVC TH-P3A

  • Page 1 SERVICE MANUAL DVD DIGITAL CINEMA SYSTEM MB541 2006 TH-P3A,TH-P3US,TH-P3UB, TH-P3UW,TH-P3UX,TH-P3UY, TH-P3UJ,TH-P3UG,TH-P3UN SP-WP5 SP-THP3F SP-THP3F SP-THP3S SP-THP3C SP-THP3S XV-THP3 Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) TABLE OF CONTENTS PRECAUTION............... . . 1-4 SPECIFIC SERVICE INSTRUCTIONS .
  • Page 2 SPECIFICATION Center unit (XV-THP3) 40 W per channel, RMS at 3 Ω at 1 kHz, with 10 % total harmonic Audio section Front/Surround distortion. 100 W, RMS at 4 Ω at 1 kHz, with 10 % total harmonic distortion. Center 100 W, RMS at 4 Ω...
  • Page 3 Speakers Subwoofer (SP-WP5) Type Bass-Reflex Type 16 cm cone × 1 Speaker Power Handling Capacity 100 W 4 Ω Impedance Frequency Range 35 Hz to 200 Hz Sound Pressure Level 75 dB/W·m Dimensions (W × H × D) 129 mm × 284 mm × 337 mm Mass 3.1 kg Front speakers (SP-THP3F)
  • Page 4 SECTION 1 PRECAUTION Safety Precautions (1) This design of this product contains special hardware and voltmeter. many circuits and components specially for safety purpos- Move the resistor connection to each exposed metal es. For continued protection, no changes should be made part, particularly any exposed metal part having a return to the original design unless authorized in writing by the path to the chassis, and measure the AC voltage across...
  • Page 5 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.5.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
  • Page 6 Important for laser products 1.CLASS 1 LASER PRODUCT 5.CAUTION : If safety switches malfunction, the laser is able to function. 2.CAUTION : (For U.S.A.) Visible and/or invisible class II laser radiation 6.CAUTION : Use of controls, adjustments or performance of when open.
  • Page 7 SECTION 2 SPECIFIC SERVICE INSTRUCTIONS CAUTION: Symbol C905(in power supply board) is noted not to touch because the voltage collects in the capacitor. B9196 R9001 C905 D901 D9024 B9204 C904 CP952 D9034 D9035 R901 R902 B9304 B9504 D902 C901 B9404 D903 B9203 B9307...
  • Page 8 SECTION 3 DISASSEMBLY Main body CN601 3.1.1 Removing the video board (See Fig.1 to 3) CN652 CN651 (1) Remove the metal cover. (2) Disconnect the card wire from CN652 of the video board, and then remove the two screws A attaching the tuner pack.
  • Page 9 SECTION 4 ADJUSTMENT Please refer to "TH-P3 (No.MB512)" about this section. SECTION 5 TROUBLESHOOTING Please refer to "TH-P3 (No.MB512)" about this section. (No.MB541)1-9...

  • Page 10: Table Of Contents

    SERVICE MANUAL DVD DIGITAL CINEMA SYSTEM MB512 2006 TH-P5B,TH-P5E,TH-P5EN, TH-P5EV,TH-P3B,TH-P3E, TH-P3EN,TH-P3EV SP-WP5 SP-WP5 SP-THP5F SP-THP5S SP-THP3C SP-THP3F SP-THP3S SP-THP5C XV-THP5 XV-THP3 (Only for TH-P5) Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) TABLE OF CONTENTS PRECAUTION.
  • Page 11 SPECIFICATION Center unit (XV-THP5/XV-THP3) Ω Audio section Front/Surround 40 W per channel, RMS at 3 at 1 kHz, with 10 % total harmonic distortion. Ω Center 100 W, RMS at 4 at 1 kHz, with 10 % total harmonic distortion. Ω...
  • Page 12 Satellite speakers (For TH-P5) Front speakers (SP-THP5F) Type 3-Way Bass-Reflex Type (Magnetically-shielded Type) × Speaker 11.5 cm cone × 4 cm cone × 1.5 cm cone Power Handling Capacity 40 W Ω Impedance Frequency Range 60 Hz to 20 000 Hz Sound Pressure Level 82 dB/W·m ×...

  • Page 13: Precaution

    SECTION 1 PRECAUTION Safety Precautions (1) This design of this product contains special hardware and voltmeter. many circuits and components specially for safety purpos- Move the resistor connection to each exposed metal es. For continued protection, no changes should be made part, particularly any exposed metal part having a return to the original design unless authorized in writing by the path to the chassis, and measure the AC voltage across...
  • Page 14 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.5.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
  • Page 15 Important for laser products Important for laser products 5.CAUTION : If safety switches malfunction, the laser is able 1.CLASS 1 LASER PRODUCT to function. 2.DANGER : Invisible laser radiation when open and inter 6.CAUTION : Use of controls, adjustments or performance of lock failed or defeated.

  • Page 16: Specific Service Instructions

    SECTION 2 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. (No.MB512)1-7...

  • Page 17: Disassembly

    SECTION 3 DISASSEMBLY Main body 3.1.1 Removing the top cover (See Fig.1 and 2) (1) Remove the two screws A attaching the top cover of both side. (See Fig.1) (2) Remove the five screws B attaching the top cover of rear side.
  • Page 18 3.1.2 Removing the front panel assembly (See fig.3 to 5) (1) Remove the three screws C attaching the front panel as- sembly from bottom side. (See Fig.3) (2) Remove the screw D attaching the wire to power supply board. (See Fig.5) (3) Release the hook a of bottom side and hook b of both side of front panel assembly.
  • Page 19 3.1.3 Removing the power supply board (See Fig.6) CAUTION: When remove the power supply board, do not touch the CN901 capacitor (C905) because it keep voltage. fastener (1) Disconnect the parallel wires from connectors CN101, CN422 on the main board. CN421 (2) Disconnect the power cord connector CN901...
  • Page 20 3.1.4 Removing the DVD mechanism assembly (See Fig.7 and 8) (1) Disconnect the card wires from connector CN405, CN411, CN412, CN413 CN414 of main board. (See Fig.7) (2) Remove the two screws F attaching the DVD mechanism assembly from bottom cover. (See Fig.8) (3) Press the hook c and slide out the DVD mechanism for di- rection the arrow.
  • Page 21 3.1.5 Removing the fan (See Fig.9) (1) Disconnect the connector CN416 of main board. (2) Remove the two screws C attaching the fan to bottom cov- CN416 Fig.9 3.1.6 Removing the tuner pack (See Fig.10 and 11) (1) Disconnect the card wire from connector CN652 of video board.
  • Page 22 3.1.7 Removing the video board (See Fig.12 and 13) (1) Disconnect the card wire from connector CN601 CN651. (See Fig.12) (2) Remove the two screws J attaching the video board. (See Fig.12) (3) Remove the three screws K attaching the video board from rear panel.
  • Page 23 3.1.8 Removing the main board (See Fig.14 and 15) (1) Remove the four screws L attaching the main board. (See Fig.14) (2) Remove the two screws M attaching the main board from rear panel. (See Fig.15) Fig.14 Fig.15 1-14 (No.MB512)
  • Page 24 3.1.9 Removing the switch board (See Fig.16) (1) Remove the three screws N attaching the switch board. 3.1.10 Removing the headphone board (See Fig.16) (1) Remove the screw P attaching the headphone board. Fig.16 3.1.11 Removing the FL board (See Fig.17) (1) Remove the three screws Q attaching the FL board.
  • Page 25 DVD mechanism 3.2.1 Removing the traverse mechanism (See Fig.1 to 7) (1) Remove the two screws A attaching the tramecha holder from top side of DVD mechanism assembly. (See Fig.1) DVD mechanism assembly (2) Remove the two screws B attaching the DVD module board.
  • Page 26 DVD module board Solder short Fig.6 DVD module board Tramecha holder CN101 CN201 DVD mechansim assembly Fig.4 DVD mechanism assembly Fig.7 Traverse mechanism assembly Fig.5 (No.MB512)1-17...
  • Page 27 3.2.2 Removing the pickup assembly (See Fig.8 to 12) (1) Remove the two rod springs pressing the guide shaft. (See Fig.8) (SHAFT) (2) Remove the screw E and F attaching the spring holder. (See Fig.9) (3) Remove the read screw from traverse mechanism assem- (T.TABLE) bly.
  • Page 28 3.2.3 Removing the feed motor assembly (See Fig.13) (1) Remove the one screw G attaching the feed motor assem- bly. Splder part (2) Remove the feed motor wires from solder part of spindle motor board. Middle gear Lead screw Fig.13 3.2.4 Removing the spindle motor assembly (See Fig.14) (1) Remove the two screws H attaching the spindle motor from...
  • Page 29 3.2.5 Removing the tray assembly (See Fig.15 and 16) (1) Remove the two screws J attaching the clamper base. (See Fig.15) (2) Remove the one screw K attaching the shaft guide from bottom side. (See Fig.15) (3) Remove the two screws L attaching the shaft guide from top side.

  • Page 30: Adjustment

    SECTION 4 ADJUSTMENT ATTENTION IN SERVICE OF DVD SECTION (1) When pickup, Flash ROM ,DVD module board were changed, initialize EEPROM by all means. (2) When full initialization was excuted, excute learning with a DVD test disc by all means. Test disc : VT-501, VT-502 Learning method : It is adjusted automatically by normal playback of a DVD disc.
  • Page 31 4.2.3 PROCESS Below, FL (LCD) display to operation and communication with a DVD back end micon are shown. * Since the number of beams changes with sets about FL (LCD) display, also set differing from the contents of specification to O.K. * Since there are arrangement and a relation of existence with a set also about a key, also set differing from the contents of specifica- tion to O.K.
  • Page 32 FL (LCD) indication STEP OPERATION MOVEMENT 1 2 3 4 5 6 7 8 9 Press +10 at 10 key of remocon. BCA READ CHECK 0 : During BCA READ 1 : BCA READ OK 2 : BCA SEEK ERROR 3 : BCA READ ERROR 4 : SPINUP adjustment ERROR Press STOP key of main unit/remocon.

  • Page 33: Troubleshooting

    SECTION 5 TROUBLESHOOTING This service manual does not describe TROUBLESHOOTING. 1-24 (No.MB512)
  • Page 34 (No.MB512)1-25...
  • Page 35 Victor Company of Japan, Limited Audio/Video Systems Category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan (No.MB512) Printed in Japan...
  • Page 36 SCHEMATIC DIAGRAMS DVD DIGITAL CINEMA SYSTEM TH-P3A,TH-P3US,TH-P3UB TH-P3UW,TH-P3UX,TH-P3UY TH-P3UJ,TH-P3UG,TH-P3UN CD-ROM No.SML200607 SP-WP5 SP-THP3F SP-THP3F SP-THP3S SP-THP3C SP-THP3S XV-THP3 Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Contents Block diagram Standard schematic diagrams Printed circuit boards 2-10 to 12 No.MB541SCH...
  • Page 37 In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " " mark nearby are critical for safety.
  • Page 38 Block diagram Micom / Audio section DVD servo contro section Video Output, AUX Input section C, Y1, Y2-G, CB-B, CR-R-C A, B, C, D, E, F C(DAC5OUT), Y1(DAC4OUT), Y2-G(DAC1OUT) VIDEO OUT S2UDT, U2SDT, UCLK, SCS, UCS V_LPF, V_RGB, V_YCMIX RF+ , LPC1, LPC2 CB-B(DAC2OUT), CR-R-C(DAC3OUT) IC601 DVD pickup...
  • Page 39 Standard schematic diagrams Power supply section QNZ0136-001Z EP901 LVA10644-A1 T901 C9004 100P/50 QQS0374-001 Q9036 POWER PWB CP951 FL SW TH901 KTC3265/Y/-X ICP-N10-T QAD0141-8R0 B9196 D901 -14.6V -14.5V D3SBA60 R9002 D9002 FR104S-T5 -13.9V L901 L902 QQR1723-001 QQR1723-001 -VDISP MAINS C905 C9006 Q9038 PLUG 100P/1000...
  • Page 40 Micon section (1/2) TO VIDEO PWB TO DVD TO DVD LVA10643-A1 (1/2) MAIN PWB Q4601 KRC110S-X 3.1V IC461 IC494 KIA78S09P-T R4091 D4836 AK5358ET-X 11.2V 8.9V MA152WA-X C4610 10/50 1/4W A5V REG SAFETY1 AINR CKS0 0.5V DETECT C4609 IC491 D4840 D4838 A9V REG KIA7805API AINL...
  • Page 41 Micon section (2/2) LVA10643-A1 (1/2) MAIN PWB SAFETY3 +33V TO Micom BLOCK POWER AMP. PGND EP101 EP101 QNZ0136-001Z IC103 TAS5142DDV-X 11.5V R1602 R1601 11.5V GVDD_B GVDD_A C1621 4.3V /OTW BST_A 270P/50 C1615 R1606 33.2V C1611 C1614 16.5V C1608 R1604 1/10W PVDD_A C1607 L1602...
  • Page 42 Video section LVA10644-A3 J6403 C6472 C6491 0.01/50 QNZ0625-001 Ver.E R6472 C6471 C6476 AUDIO R OUT R6474 AUDIO R IN R6471 4.7/50 AUDIO L OUT AUDIO AGND R6481 C6443 1/4W C6475 R6473 AUDIO L IN R6442 R6482 4.7/50 FUNCTION 10.6V R6432 10.6V C6433 (SCART...
  • Page 43 Front section LVA10644-A2 FL PWB 3254 DI501 QLF0168-001 FL DISPLAY C515 0.01/50 -19.1V -19.1V -21V -21.1V R505 -20.8V -16.9V -VDISP R501 FL DRIVER -20.8V DI-DT TO MAIN PWB R502 2.6V -18.9V DI-CK FLGND R503 2.6V -20.8V DI-CS DGND -20.8V DI-CK DI-CK -17V DI-DT...
  • Page 44 DVD section (1/3) D1.2V REG. P3.3V C328 0.01 3.9V Cont C302 47/4 1.2V IC302 MM1701CH-X EEPROM DGND C564 EXADR18 DQM1 65 EXADR18 DQM1 EXADR17 DQM0 66 EXADR17 DQM0 EXADT7 MDQ7 67 EXADT7 MDQ7 EXADT6 MDQ8 68 EXADT6 MDQ8 EXADT5 MDQ6 69 EXADT5 MDQ6 EXADT4...
  • Page 45 DVD section (2/3) SDRAM FLASH ROM IC505 IC509 SG32M90TFIR3 K4S641632H-UC75 EXADT15 0.4V 0.5V EXADR16 C560 3.3V EXADT14 0.7V 3.3V 2.8V 2.7V MDQ15 MDQ0 */BYTE DQ15 EXADT13 0.5V C551 3.3V VDDQ VSSQ EXADT12 0.7V 0.8V EXDT15 MDQ1 2.8V 2.7V MDQ14 DQ14 EXADT11 0.7V 1.5V...
  • Page 46 DVD section (3/3) Loader section P3.3V QSW1074-001 DGND R859 QGF1016F3-05 R860 Q801 UN2113X IC801 MM1565AF-X KRA104S-X R891 Vout CN801 QGF1016F2-05W IC891 Cont USB TRANCEIVER C811 IC811 ISP1106DH-X 3.3V 3.3V SOFTCON Vreg R851 3.3V R823 C819 3.3V CN811 QGA2001F6-05X R819 R821 R811 1/2W K811...
  • Page 47 Printed circuit boards Main board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) forward side reverse side C4003 CN422 CN421 CN406 J1001 C1034 C1114 C1414 C1620 C1621 C1214 C1113 K4702 C1514 CP471 C1213 C1513 C1413 C1215...
  • Page 48 Power supply board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) (Power supply board) HS953 EP951 (Key board) C9082 C9084 R9034 D9014 D9015 R9036 C9025 D9013 C9022 D9041 R9082 IC952 L9002 R9081 L9005 R511 R9042 D511...
  • Page 49 DVD board Loader board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) forward side CN201 Q101 TP324 TP291 TP467 TP814 TP292...
  • Page 50 < M E M O >...
  • Page 51 Victor Company of Japan, Limited Audio/Video Systems Category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan (No.MB541SCH)
  • Page 52 PARTS LIST TH-P3A,TH-P3US,TH-P3UB,TH-P3UW,TH-P3UX TH-P3UY,TH-P3UJ,TH-P3UG,TH-P3UN * All printed circuit boards and its assemblies are not available as service parts. - Contents - 3- 2 Exploded view of general assembly and parts list (Block No.M1) 3- 6 Speaker assembly and parts list(Subwoofer) (Block No.M2) 3- 7 DVD mechanism assembly and parts list (Block No.MJ)
  • Page 53 Exploded view of general assembly and parts list Block No. Key board USB Jack board FL board Headphone board...
  • Page 54 19 20 Video board Main board board Power supply board...
  • Page 55 General Assembly Block No. [M][1][M][M]  Symbol No. Part No. Part Name Description Local LV11230-005A FRONT PANEL GV40313-002A FELT SPACER (x2) LV11231-005A FRONT LENS A,US,UB,UW,UX,UY,UG,UN LV11231-006A FRONT LENS LV44574-001A FL SCREEN QYSDSF2608ZA TAP SCREW M2.6 x 8mm(x3) QYSDSF2608ZA TAP SCREW M2.6 x 8mm LV30225-011A SPACER...
  • Page 56  Symbol No. Part No. Part Name Description Local QJJ063-031503-E SIN CR C-C WIRE GV40642-001A CAUTION LABEL LV42255-001A C.LABEL(UY)

  • Page 57: Speaker Assembly And Parts List(Subwoofer) (Block No.m2)

    Speaker assembly and parts list Block No. (Subwoofer) The parts without symbol number are not service. Speaker(Subwoofer) Block No. [M][2][M][M] Symbol No. Part No. Part Name Description Local  LE10016-066A CONE SPK 7001541605 SCREW (x4) LV11248-001A SIDE PANEL ASSY 5600006901 FOOT (x4)

  • Page 58: Dvd Mechanism Assembly And Parts List (Block No.mj)

    DVD mechanism assembly and parts list Block No. Grease FXL-D10-1M =JVG-31N =JVS-1003 =1401C < Back side > 7.0mm 0.2mm The parts without symbol number are not service.
  • Page 59 DVD mechanism Block No. [M][J][M][M]  Symbol No. Part No. Part Name Description Local LV22234-001A TM.CHASSIS LV22235-001A SPINDLE BASE QYSDST2005ZA TAP SCREW M2 x 5mm(x2) LV36555-001A G.S.HOLDER QYSDST2005ZA TAP SCREW M2 x 5mm LV44041-002A GUIDE SHAFT LV44479-001A BAR SPRING LV22236-001A FEED HOLDER QAR0165-001 FEED MOTOR...

  • Page 60: Dvd Loading Base Assembly And Parts List (Block No.mn)

    DVD loading base assembly and parts list Block No. FMU-MB1-21M Grease JVS-1003 JVG-450 < Back side > Backside DVD module board DVD loading switch board The parts without symbol number are not service.
  • Page 61 DVD loading base Block No. [M][N][M][M]  Symbol No. Part No. Part Name Description Local LV11065-007A LOADER SUB ASSY E407140-001SS C.D ROLLER E407149-001SS RUBBER TUBE LV10979-002A TRAY LV35499-001A SHAFT GUIDE LV44022-001A SHAFT QYSSSF2008ZA TAP SCREW M2 x 8mm QYSDSF2008ZA TAP SCREW M2 x 8mm(x2) LV41741-004A SPECIAL SCREW...

  • Page 62: Electrical Parts List (Block No.01~04)

    Electrical parts list Main board  Symbol No. Part No. Part Name Description Local Block No. [0][1] C1012 NCB31CK-104X C CAPACITOR 0.1uF 16V K  Symbol No. Part No. Part Name Description Local C1013 QETN1HM-226Z E CAPACITOR 22uF 50V M C1014 NCB31HK-104X C CAPACITOR...
  • Page 63  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C1303 NCB31HK-333X C CAPACITOR 0.033uF 50V K C1612 NCB31HK-472X C CAPACITOR 4700pF 50V K C1304 NCB31HK-333X C CAPACITOR 0.033uF 50V K C1613 NCB31HK-472X C CAPACITOR 4700pF 50V K...
  • Page 64  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R1009 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J R1305 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R1010 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R1306 NRSA02J-3R3X MG RESISTOR 3.3Ω...
  • Page 65  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R4606 NRSA63J-101X MG RESISTOR 100Ω 1/16W J L1301 QQR1699-001 CHOKE COIL R4607 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J L1302 QQR1699-001 CHOKE COIL R4608 NRSA63J-103X MG RESISTOR...
  • Page 66  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local D902 SARS01-T2 FR DIODE C6412 NDC31HJ-470X C CAPACITOR 47pF 50V J D903 SARS01-T2 FR DIODE C6421 QETN1AM-477Z E CAPACITOR 470uF 10V M D904 1SS244-T2 SI DIODE IM...
  • Page 67  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R534 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R6751 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J  R901 QRZ9037-335 COMP RESISTOR 3.3MΩ 1/2W K R6752 NRSA63J-682X MG RESISTOR...
  • Page 68  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local FW511 QUM215-08DGZ4-E PARA RIBON WIRE C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K FW591 QUM214-22DGZ4-E PARA RIBON WIRE C217 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z FW901 QUM216-07DGZ4-E PARA RIBON WIRE C251...
  • Page 69  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C559 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z R371 NRSA63D-203X MG RESISTOR 20kΩ 1/16W D C560 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z R372 NRSA63J-103X MG RESISTOR 10kΩ...
  • Page 70  Symbol No. Part No. Part Name Description Local X302 NAX0376-002X CRYSTAL DVD loading switch board Block No. [0][4]  Symbol No. Part No. Part Name Description Local QGF1016F9-05 CONNECTOR FFC/FPC (1-5) QSW1074-001 DETECT SWITCH 3-19...

  • Page 71: Packing Materials And Accessories Parts List (Except Th-P3Uj) (Block No.m3)

    Packing materials and accessories parts list Block No. (Except TH-P3UJ) No additional / supplemental order of WARRANTY CARDs are available. A1,A2,A3,A4, Only UB ver. A5,A6,A7,A9, A10, A11 A,US,UW,UX,UY,UG,UN ver. A20 A20 P15 A16 3-20...
  • Page 72 Packing and Accessories (Except TH-P3UJ) Block No. [M][3][M][M]  Symbol No. Part No. Part Name Description Local LVT1523-008A INST BOOK A,US,UB,UW,UX,UG,UN LVT1523-011A INST BOOK SPA POR LVT1523-009A INST BOOK CHI(PEKIN) US,UB,UN LVT1523-011A INST BOOK SPA POR LVT1523-010A INST BOOK ARA PER UX,UG QAM0112-002 PLUG ADAPTOR...

  • Page 73: Packing Materials And Accessories Parts List (Only Th-P3Uj) (Block No.m4)

    Packing materials and accessories parts list Block No. (Only TH-P3UJ) A1,A3,A4, A5,A6, A7 A20 A20 P15 A16 3-22...
  • Page 74 Packing and Accessories (Only TH-P3UJ) Block No. [M][4][M][M]  Symbol No. Part No. Part Name Description Local LVT1523-014A INST BOOK QAM0112-002 PLUG ADAPTOR  QAM0216-001 SIGNAL CORD QAL0457-001 ANT.WIRE QAL0476-002 AM LOOP ANT RM-STHP7U REMOTE CONTROL UNIT ---------------- BATTERY 1.5V(x2) A 14 QAS0411-001 SPEAKER BOX...
