LIGHTWEIGHT KEYKEG Quick Start Manual

Instructions for manual filling of KeyKeg

STEP 1: EVACUATE ALL OXYGEN FROM THE INNER BAG

•
Remove the blue dust cap.
•
Spray some alcohol or other disinfectant on the valve.
•
Connect a clean disinfected coupler to KeyKeg and purge
out residual air from the inner bag (entrapped during
manufacturing) by opening the ball valve for at least
6 seconds.
•
Disconnect the coupler.

STEP 2: CONNECT FILLING HEAD TO THE BEVERAGE TANK

•
Rinse the beverage hose and filling head with alcohol, other disinfectant or sterilize
by steam or in an oven to ensure good microbiological conditions.
•
Disinfect all connections.
•
Connect the beverage supply to the beverage valve connection.
•
Fill the beverage hose completely with beverage by flushing some beverage.

STEP 3: CONNECT FILLING HEAD TO KEYKEG

•
Close the air valve of the filling head and once again disinfect the filling head.
•
Position KeyKeg on a support in an upside down position.
•
Hold the filling head in an inverted position.
•
Fill the probe by gently opening the ball valve until beverage foam reaches the
top of the probe to ensure oxygen free filling conditions.

STEP 4: FILLING THE KEYKEG

•
Connect the filling head to the container in the inverted position by turning it clock wise until it
stops moving.
•
Unlock the handle and push it down until it locks.
•
Open the ball valve of the beverage line.
•
Gently open the air valve and adjust it to set counter pressure to a level well over the CO
saturation pressure of the beverage at the given temperature to avoid foaming.
© Lightweight Containers, May 2015.
Disclaimer: The information contained herein is offered for use at your own discretion and risk. All statements, technical information and
recommendations contained herein are based on tests and data that Lightweight Containers believes to be reliable, but the accuracy or
completeness has not been verified and is not guaranteed. No warranty of any kind is made with respect to any of the above representations.
CO /Air Connection
2
Purge beverage bag
Step 1
2
