Nautilus Hyosung MONiMAX 7600DA Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Manual
MONiMAX7600DA System
V01.00.02 (2015.05.11)
© 2012 Nautilus Hyosung Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MONiMAX 7600DA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nautilus Hyosung MONiMAX 7600DA

Summary of Contents for Nautilus Hyosung MONiMAX 7600DA

  • Page 1 Installation Manual MONiMAX7600DA System V01.00.02 (2015.05.11) © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 2 Chapter 3 V01.00.02 2015/05/11 Added the approximate weight of MX7600DA Chapter 3 © 2012 Nautilus Hyosung All Rights Reserved. The content of this specification is protected by copyright laws. 2015.05.11. 3rd Release © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 3: Table Of Contents

    Removing the Protective Material from the main body of Cash & Check In Module ........A-1 Removing the locking section from the main body of Cash & Check In Module........A-2 Separating the Cassette Section ....................... A-3 Installing Section.............................. A-4 Notes............................Notes-1 © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 4: Chapter1. Preface

    Nautilus Hyosung. It is the policy of Nautilus Hyosung to improve products as new technology, components, software, and firmware become available. Therefore Nautilus Hyosung reserves the right to change specifications without notice.

  • Page 5: Conventions

    Body Module1 Body Module2 Body Module3 BUNDLE Bulk Note Separation Module Camera Unit CASSETTE Cash & Check Cassette CCIM Cash & Check In Module Contactless Card Reader Cash Dispenser Unit Control Electronics © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 6 Recognition Module REJECT Reject Module RT/A6 Retract & A6 Cassette Switch Separator Control Module Sensor and Indications Unit Service Provider Slip Printer (Receipt Printer) Text Terminal Unit (OPL or SPL) Vacuum Fluorescent Display © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 7: Safety Precautions (English)

    ▪ Do not touch the equipment when it is running. ▪ The equipment can get extremely hot and may cause a burn. ▪ Make sure to close the cover before running the equipment. © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 8 TYPE. DISPOSED OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS 3. FOR PLUGGABLE EQUIPMENT, THE SOCKET-OUTLET SHALL BE INSTALLED NEAR THE EQUIPMENT AN SHALL BE EASILY ACCESSIBLE 4. THE EQUIPMENT IS TO BE SECURED TO THE BUILDING STRUCTURE BEFORE OPERATION © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 9: Précautions Pour La Sécurité (French)

    • Ne pas retirer le couvercle. Seul le technicien d'entretien est autorisé à ouvrir le couvercle. • Ne pas toucher. Vous pouvez avoir un choc électrique. • Assurez-vous d'éteindre l'appareil lors de l'entretien de l'équipement. © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 10 2. RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN TYPE INCORRECT. DISPOSER POUR UTILISATION DES BATTRIES SELON LES INSTRUCTIONS 3. POUR LES APPAREILS RACCORDES, LA PRISE DOIT ETRE INSTALLEE PRES D’EQUIPEMENT POUR ÊTRE FACILEMENT ACCESSIBLE © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 11: Related Documents

    ► Related documents are listed below. If needed, please contact our technical support team or maintenance team for copies. ▪ Operator Manual ▪ Service Manual ► To contact the Nautilus Hyosung maintenance staff, see the email addresses and telephone numbers provided separately. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 12: Chapter2. Introduction

    4. A bank customer and a teller can easily interact on a touch screen, just like talking, through Nautilus Hyosung’s intuitive and easy UI. 5. Supports expanded options as well as basic functions of deposit/withdrawal of cash/check. 6. Allows easy and quick installation and maintenance. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 13: System Identification Label

    Installation Manual Chapter2. Introduction System Identification Label ▶ The System Label sample below shows the layout of the product identification label which is located inside the side box of the ATM. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 14: Chapter3. Installation Information

    4. Space required for servicing the machine should be considered before installation. ► Temperature & Humidity In Storage -5°C ~ 50°C (23°F ~ 122°F) Temperature Operating -10°C ~ 40°C (14°F ~ 104°F) In Storage 10% ~ 90% Humidity Operating 25% ~ 86% © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 15: Packing Dimensions

    In some cases it may be necessary to store the ATM (in its box) before it is installed. See the figure below for information on the dimensions of a boxed Monimax7600DA ATM. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 16: Weight & Dimensions

    Installation Manual Chapter3. Installation Information Weight & Dimensions ► Approximate Weight: 820kg (1,807.79Ibs). ► Dimensions of MX-7600DA ATM © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 17: Fascia Item Locations For Voice Guidance

    Installation Manual Chapter3. Installation Information Fascia Item Locations for Voice Guidance © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 18: Recommended Installation And Service Clearance

    ▶ The following diagram describes the areas required for installing and servicing the MX7600DA ATM. <Note!> Hyosung highly recommends that your service personnel have the maintenance space described below to service this ATM. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 19: Minimum Installation And Service Clearance

    Installation Manual Chapter3. Installation Information Minimum Installation and Service Clearance ► Minimum Installation and Service Clearance Area – Areal View © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 20: Exterior Wall

     The “minimum maintenance space” should be secured in the rear of the TTW.  For all of the measurements shown on the plan, ±5mm (0.2 inch) tolerance should be kept. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 21: Dimensions Depending On The Tilt

    Installation Manual Chapter3. Installation Information Dimensions Depending on the Tilt ► The following diagram shows the dimensions of the MX7600DA depending on the tilt. 1. Default 0° 2. Default 17° © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 22 Installation Manual Chapter3. Installation Information 3. Default 25° © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 23: Chapter4. System Installation

    4. Verify the contents carefully with the packing list to be sure all items are included. Notify your distributor of any shortages. 5. If only the palette needs to be removed, lift the whole machine from the bottom and set it aside. © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 24 ▪ Firmly close the vault door and lock the door by turning the knob completely. ▪ Only experienced staff members should move the machine. ▪ Do not tilt the ATM when moving. Equipment locking bracket © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 25: Bolting Down The Mx7600Da

    5. Place the MX7600DA on the bolt location sheet, matching the mounting holes of the unit with the anchors. 6. Firmly tighten the mounting bolts in the anchors. ► The following diagram is a sample of the Anchor Bolts Location Sheet for the MX7600DA ATM. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 26: System Positing

    Installation Manual Chapter4. System Installation System Positing ▶ Position the equipment through the opening in the wall and adjust its position. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 27: Checking The Location Of The Opening In The Wall To Estimate Whether The Collar Can Be Installed

    12.10mm [0.48inch] 26.70mm [1.05inch] <Note!> In case the wall clearances are less than the above dimensions, just take out the collar locking bracket and put it together again after installing the machine. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 28: Inserting The Collar Wing

    4. Locking the collar stopper back: ▪ Push the collar stop bracket all the way in so that it is firmly in place. ▪ Push in and turn the thumb screw until it stops. © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 29 ▪ Seal both the top and the sides of the collar with waterproof silicone. ▪ Remove excess silicone. ▪ Do apply silicone to the bottom of the collar to all for drainage. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 30: The External Appearance After The Completion Of Installation

    Installation Manual Chapter4. System Installation The external appearance after completion of installation © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 31: Appendix

    ▶ Bundle Section 1. Remove the tape from the Bundle Door. 2. Lift up the door and remove the Bubble Bag inside. ▶ Reject Section Remove a tape from the Reject Section. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 32: Removing The Locking Section From The Main Body Of Cash & Check In Module

    2. Move the location of the Screw “C” fastened on the Body Section. Moving the location of the screw fixing the guide on Escrow Section ▶ Transport Section of BM2 Disassemble the green screw. Removing the screw fixing the transport section of BM2 © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 33: Separating The Cassette Section

    3. Open the door with the key and remove the tape from the fixing section of upper Push Plate and (2 points) and door (1 point). <Procedure to remove the protective material from the cassette section> © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 34: Installing Section

    <Procedure to remove the protective material from the RT/A6 Cassette Section> Installing Section ► Installing the Cash & Check & RT/A6 Cassette Section Insert and push the Cash & Check & RT/A6 cassette in body module completely. Then it is locked automatically. © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 35 1. Pulling the green knob until stopping (①), at the same time rotating right (②) and pulling it completely. 2. After opening the green grip (③), insert the ink cartridge in the cartridge adaptor (④). © 2012 Nautilus Hyosung Inc. All Rights Reserved.
  • Page 36 (Before mounting it, see the ink cartridge installation guide on the packing bag) 4. Push the green knob completely to the left arrow direction (⑤) to sound the click of the latch, and then it is locked automatically. © 2012 Nautilus Hyosung Inc. All Rights Reserved.

  • Page 37: Notes

    Installation Manual Notes Notes Notes-1 © 2012 Nautilus Hyosung Inc. All Rights Reserved.
