Wall fixing.
Tool:
- Wrench and / or ratch with 9/16 "socket
1. Once the ideal anchorage has been defined according to the wall material,
proceed to fix the assembly to it.
2. Screw 4 screws and 3/8 "washers (NOT INCLUDED) to the matching wall
to the mounting wrench eyes.
3. Place the screws into the mount ensuring the stability of the cabinet.
4. Tighten all the screws.
HARDWARE KIT
ELEMENT
1/4 TOOTHED NUT
1/4X1/2" HEXAGONAL SCREW
5/16" LOCKNUT
FLOOR LEVELER
10-32 SCREW
CAGED NUT
PLASTIC WASHER
QUANTITY
48
48
4
4
24
24
24
User Manual LPRPP1914
4-post open rack wall or floor installation of
14 units, ¡ideal for audio equipment!
Please read this user manual before using the
equipment and retain it for future reference.
Advertisement
Table of Contents
Related Manuals for Linkedpro LPRPP1914
Summary of Contents for Linkedpro LPRPP1914
- Page 1 User Manual LPRPP1914 4-post open rack wall or floor installation of 14 units, ¡ideal for audio equipment! Wall fixing. Tool: - Wrench and / or ratch with 9/16 "socket 1. Once the ideal anchorage has been defined according to the wall material, proceed to fix the assembly to it.
- Page 2 Thank you for purchasing this LPRPP1914 ASSEMBLY AND SCREW rack. The information in this manual will assist you in assembling the product. ORIENTATION Recommendations Start installing the equipment(s) only until you • have finished installing the rack. Tie the components and tighten the pieces until •...
