Wall fixing.
1. Once the ideal anchors have been defined according to the wall material,
proceed to fix the assembly to it.
2. Place 4 1/2" screws and washers (NOT INCLUDED) to the wall coinciding
with the cabinets perforations.
3. Place the screws into the mount ensuring the stability of the cabinet.
4. Tighten all the screws.
KIT DE TORNILLERÍA
ELEMENT
1/4" HEX SCREW
1/4" NUT
CAGE NUT
10-24 HEX NUT
10-32 ANTI-SLIP NUT
10-32 CONE SCREW
BLACK PLASTIC WASHER
PLASTIC PLUG
HINGE FOR MOUNTING
SISTEMAS Y SERVICIOS DE COMUNICACIÓN S.A. DE C.V.
Calle 20 de Noviembre #805, Col. Centro
(614) 415-25-25
C.P. 31000, Chihuahua, Chih, México
NOT INCLUDED
QUANTITY
32
32
14
1
8
22
12
4
2
User Manual GAP-V4 Series
Folding cabinet (with back door) for
wall mounting with 19" Rack.
600 mm
625 mm
Model
SR1906GAPV4
SR1909GAPV4
SR1912GAPV4
SR1916GAPV4
SR1924GAPV4
Read this user manual before using the equipment
and keep it for future reference.
X
Height (X)
352mm
487mm
620mm
795mm
1,150mm
