JRDAB-04
DAB/DAB+ module for CAR
1. INTRODUCTION ...............................................................................
2. RECOMMENDATIONS .....................................................................
3. DAB MODULE CONNECTION DIAGRAM .....................................
4. LOCATION OF KIT COMPONENTS ..............................................
5. LOCATION AND CONNECTION OF THE MODULE ....................
6. ANTENNA CONNECTION ...............................................................
7. BASIC TECHNICAL PARAMETERS ...............................................
8. SET OF COMPONENTS ..................................................................
JuNa
PPHU
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
INSTALLATION MANUAL
Table of Contents
Manufacturer
Model:
JRDAB-04 CAN MIB/MIB2
1 1 1 1
2
2
4
5
5
6
7
7
Advertisement
Table of Contents
Related Manuals for Juna JRDAB-04
Summary of Contents for Juna JRDAB-04
- Page 1 JRDAB-04 Model: JRDAB-04 CAN MIB/MIB2 DAB/DAB+ module for CAR INSTALLATION MANUAL 1 1 1 1 Table of Contents 1. INTRODUCTION ................2. RECOMMENDATIONS ..............3. DAB MODULE CONNECTION DIAGRAM ........4. LOCATION OF KIT COMPONENTS ..........5. LOCATION AND CONNECTION OF THE MODULE ....
- Page 2 1. Introduction Digital radio tuner DAB/DAB+ for factory car radio VW/SKODA/SEAT/AUDI. Module JRDAB-04 allow to receive and play digital radio stations on factory sound system. Device has function which allow to follow selected station while riding. Full integrated with CAN bus system.
- Page 3 In the interest of high quality and development of our products, JUNA Electronics reserves the right to make technical changes. In the case of a warranty claim, the device should be sent back to the seller in original packaging with a detailed description of the problem with attached purchase invoice.
- Page 4 4. Connect the factory ISO connector to the W-JRDAB-04-101 ISO harness socket 5. Disconnect the LVDS cable from the radio unit 6. Connect the LVDS cable from the set to the radio unit and the JRDAB-04 module 7. Connect the factory LVDS cable of the screen to the JRDAB-04 module 8.
- Page 5 4. Location of kit components 1. JRDAB-04 module installation place behind the car glove box 2. DAB/DAB+ antenna installation location 5. Location and connection of the module Factory LVDS cable Factory plug ISO QUADLOCK Antenna K-LVDS-104 cable from JRDAB-04 set...
- Page 6 The amplifier is powered from the JRDAB-04 module with 8,2V or 12V max 150mA. Important: During installation antenna cable along the pistol it is necessary to pay attention for side airbags.
- Page 7 - Metal 6. Housing - 107,2mm x 92,6mm x 25,2mm 7. Dimensions - 280g 8. Weight 10. Elements set Cable - W-JRDAB-04-101 Cable - K-LVDS-104 (LVDS) JRDAB-04 module Antenna DAB/DAB+ JuNa PPHU Manufacturer ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND...
