20PMTAAP
Read this manual carefully before installing, operating or servicing this equipment. It's the responsi-
bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
This document is issued with Product Serial No
Operation and Maintenance Guide
20 P M
Descriptions
HUB Model with Lube / Lube-Free, Aluminum BSPP Variants
Advertisement
Table of Contents
Related Manuals for Teryair 20PMTAAP
Summary of Contents for Teryair 20PMTAAP
- Page 1 Descriptions HUB Model with Lube / Lube-Free, Aluminum BSPP Variants 20PMTAAP Read this manual carefully before installing, operating or servicing this equipment. It’s the responsi- bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
-
Page 2: Table Of Contents
Operation and Maintenance Guide Piston Air Motor Series Page 2 Table of Contents Nomenclature Technical Data Safety Instructions Installation Instructions Operating instructions Suggested Lubricants Troubleshooting Exploded View for 20 PM Air Motor Bill of Materials for 20 PM Dimensional Data Repair Kits for 20 PM Paint Stirrer Accesories Test Certificate Of Materials, Performance... -
Page 3: Nomenclature
D- IEC O - Lube Free S - SS N - NEMA For example, 20PMTAAP is a size 20, Piston type, Hub Mounted, Lubricated, Aluminum MOC with BSPP threading Technical Data upto 0.07 kW (0.10HP) Power 10.2 to 30.5 m3/hr (6 to 18 cfm) -
Page 4: Safety Instructions
Ensure that job site is clear of by- standers. Do Not dis-assemble in explosive atmosphere. Caution Use only genuine Teryair or Teryair ap- proved accessories. FF-MM-406-REV - 00... -
Page 5: Installation Instructions
Connect lines to motor in the proper • Use genuine Teryair spares and if possible direction mention the serial number of the piston motor when ordering spares. -
Page 6: Suggested Lubricants
Operation and Maintenance Guide Piston Air Motor Series Page 6 Mounting • Lubricate motor with a small amount of oil into the intake port. Rotate shaft by This product can be installed in any orientation. hand several times to distribute oil. Mount the motor to a solid metal base plate that is mounted to a stable, rigid operating surface. -
Page 7: Exploded View For 20 Pm Air Motor
Operation and Maintenance Guide Piston Air Motor Series Page 7 Exploded View for 20 PM Air Motor 8 20 FF-MM-406-REV - 00... -
Page 8: Bill Of Materials For 20 Pm
Operation and Maintenance Guide Piston Air Motor Series Page 8 Bill of Materials for 20 PM Illustration Description Part Number 10 PM Number MAIN HOUSING 812 10 01 SLEEVE 812 21 02 END COVER 812 10 03 SIDE CAP 812 10 02 PISTON CHAMBER 812 21 04 BEARING... -
Page 9: Dimensional Data
Operation and Maintenance Guide Piston Air Motor Series Page 9 Dimensional Data Piston Air Motor 20 PM AIR EXHAUST 67.00 45.20 33.20 27.00 6.00 16.00 62.50 93.00 116.00 AIR INLET 1/2" 156.50 Repair Kits for 20 PM Repair KIT Ordering No Suitable for 2129701 Suitable for 20PM all variants... -
Page 10: Paint Stirrer Accesories
Operation and Maintenance Guide Piston Air Motor Series Page 10 Paint Stirrer Accesories Bill of Materials Paint Stirrer Accessories Illustration Description Part Number Number RADIAL PISTON AIR MOTOR 20PMTAAP SHAFT HOUSING 270582PS1 STIRRING ROD ASSEMBLY 270582PS2 3 3 BLADE IMPELLER 270582PS5 HOLLOW IMPELLER 270582PS6 FF-MM-406-REV - 00... -
Page 11: Test Certificate Of Materials, Performance
Operation and Maintenance Guide Piston Air Motor Series Page 11 TEST CERTIFICATE OF MATERIALS, PERFORMANCE DATE MODEL NUMBER PART DESCRIPTION & S.NO. We hereby certify that the above referenced product has tested and inspected in accordance with our standard test proce- dures and meets the specifications for material and performance values as published in our literature. -
Page 12: Warranty Certificate
Teryair; (vii) the issue with a Product is directly or indirectly attributable to, or directly or indirectly results from or arises out of, compliance with any design, specification or other specific requirement of Dealer/End User;... - Page 13 Operation and Maintenance Guide Piston Air Motor Series Page 13 This page is intentionally Left blank. FF-MM-406-REV - 00...
