Page 1
LG Floor Standing Type Air Conditioner OWNER'S MANUAL Prior to installation, this air- MODELS: LP-H602ME0 conditioning unit must be submitted for approval by the utility service LP-C602ME0 which provides electricity (EN 61000-2, EN 61000-3 Norm). IMPORTANT • Please read this owner's manual carefully and thoroughly before installing and operating your air conditioner.
Floor Standing Type Air Conditioner Owner’s Manual TABLE OF CONTENTS FOR YOUR RECORDS Write the model and serial numbers here: Safety Precautions....3 Model # Serial # Preparation before operation...9 You can find them on a label on the side of each unit. Dealer's Name Date Purchased Air conditioner operation ..12...
Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury.
Page 4
Safety Precautions Do not modify or extend the Do not install, remove, or re- Be cautious when unpacking power cable. install the unit by yourself and installing the product. (customer). • There is risk of fire or electric • There is risk of fire, electric •...
Page 5
Safety Precautions Do not allow water to run Do not store or use flammable Do not use the product in a into electric parts. gas or combustibles near the tightly closed space for a product. long time. • It may cause There is risk of fire, •...
Page 6
Safety Precautions When the product is not be used for a long Take care to ensure that nobody could step time, disconnect the power supply plug or on or fall onto the outdoor unit. turn off the breaker. • There is risk of product damage or failure, or •...
Page 7
Safety Precautions Do not block the inlet or Use a soft cloth to clean. Do Do not touch the metal parts of outlet of air flow. not use harsh detergents, the product when removing the solvents, etc. air filter. They are very sharp! •...
Page 8
Prior to Operation Prior to Operation Preparing for Operation 1. Contact an installation specialist for installation. 2. Plug in the power plug properly. 3. Use a dedicated circuit. 4. Do not use an extension cord. 5. Do not start/stop operation by plugging/unplugging the power cord. 6.
Preparation before operation Preparation before operation Features 1. Design for cooling and heating. 5. 2 Cooling/Heating speeds 2. Super energy efficiency 6. Removable air filter 3. Micom control 7. Anti-Bacteria filter 4. Whisper quiet operation 8. 3 minutes delay circuit Specifications Air Outlet Vent Air Intake Vent...
Page 10
Preparation before operation Display (Heating pump models) Fan Operation Button and Lamp Cooling ON Button and Lamp Temperature/Time Display Window Outdoor Unit Operation Lamp OUTDOOR ROOM TEMP SET TEMP U NIT DOWN Temperature Setting Buttons Heating ON Button and Lamp Indoor Fan Speed Selector (To select the desired fan speed in two steps [Low, High])
Page 11
Preparation before operation Display (Cooling only model) Auto Airflow Direction Control Button and Lamp Timer Setting Button and Lamps (Operation stops at ON) Temperature/Time Display Window Outdoor Unit Operation Lamp OUTDOOR ROOM TEMP SET TEMP U NIT DOWN Temperature Setting Buttons Indoor Fan Speed Selector (To select the desired fan speed in two steps [Low, High])
Air conditioner operation Air conditioner operation Operation Procedure 1. Cooling and Heating Operation Mode (Operation Procedure) Press the POWER ON/OFF Button Select the Cooling or Heating operation mode by pressing the mode button. For Cooling For Heating Set the temperature The temperature can be set within a range of 16°...
Page 13
Air conditioner operation Air flow Direction Procedure 1. Vertical Airflow Direction Control (Cooling only models). Press the POWER ON/OFF Button. (Display Lamp ON) Press the AUTO SWING Button AUTO • The vertical louvers swing left and right. 2. Horizontal Airflow Direction Control •...
Page 14
Air conditioner operation Timer Setting Procedure 1. OFF TIMER Setting or CANCEL Press the POWER ON/OFF Button. (Display Lamp ON) SELECT Funciton ( Heat pump model only • Press the SELECT Function Button. Press the TIMER Button. • You press the button, the selected off TIMER is displayed as follows; 1:00 2:00 3:00...
Care and Maintenance Care and Maintenance Caution: Before performing any maintenance, turn off the main power to the system. During the season Cleaning of the air filters. Recommended about once every two weeks Remove the Air Filter. Take hold of the tab and pull slightly forward to remove the filter.
Page 16
Care and Maintenance When the air conditioner is not going to be used for a long time At the end of the season At the start of the season Clean the air filters, re-insert, then Operate the air conditioner at the operate the air conditioner.
Care and Maintenance Before you call for service... Troubleshooting Tips! Save time and money! Check the following points before requesting repairs or service..If the fault persists, please contact your dealer or service center. Case Explanation See page Does not operate. •...
Page 18
Care and Maintenance Service Centers Details of LG serial No. 9 10 Code Detail Code of Model Meaning Year The last digit of year (Digit) ex) 1997 7, 2000 Month 01~12 Month (Digit) ex) March 03, August Nation Where manufactured...
Page 19
P/No.: 3828A30142K Printed in Korea After reading this manual, keep it in a place easily accessible to the user for future reference.
