To use, begin with your Pallet Fork Frame installed on your loader at a comfortable height, and fork
tines removed, if applicable.
On the Front-Hoe Bucket, pass the Lock Keys through the cutouts to the front of the adapter plate.
They can then be slung over the edge and into the bucket for easy access.
Then, install the Front-Hoe Bucket on the Fork Frame as follows:
Once the Attachment is centered on the fork frame, install the two Lock Keys as shown on next
page.
© Artillian, LLC 2016
Front Hoe Bucket Installation Manual
p/n: 5-FPS-916 (9" wide x 16" deep)
p/n: 5-FPS-924 (9" wide x 24" deep)
For all Artillian Pallet Fork Frames built after model year 2010
The Artillian Front-Hoe Bucket turns your Artillian pallet
fork frame into a tool for digging, trenching, transplanting,
brush grubbing, trail maintenance, wall building, general
1. (1) Attachment Plate
2. (2) Tethered lock keys
Please review these instructions before using!
1
hauling, and many other tasks.
Parts Included
IM-5-FPS-916
Rev. C, 12/08/2021
