ARTILLIAN ROPS MOUNTED TOOL RACK
For use on the Artillian ROPS Mounted Tool Bar (P/N: 1RMTB) (sold separately)
The Artillian ROPS Mounted Tool Rack is rated for 40 LBs and is capable
of holding up to (4) long handle tools at a time. The mounting plate is made
from powder coated 10 gauge steel and incorporates (8) rubber clamps.
These clamps hold tools firmly, while providing for fast installation or
removal.
Integrated Cam Lever Latches securely lock onto the Artillian ROPS
Mounted Tool Bar (sold separately) in seconds without the use of tools.
These latches can be repositioned to the long sides of the rack, allowing
the user to orient the rack vertically, if desired.
Approximate Installation Time
Experienced Dealer Technician – 2 Minutes
Average Dealer Technician – 2 Minutes
Do-It-Yourself – 2 Minutes
CAUTION
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
P/N: 1RMTRK
Approximate Product Specifications
Overall dimensions: 14.05" high x 26.50" wide
Weight: 11.26 lbs. (not including mounting bar)
Capacity: 40 lbs.
Do not exceed the rated capacity for the Tool Rack. Doing so may result
in damage to the Tool Rack and/or the Tool Bar and will void the warranty.
Rev. A, 04/30/2020
p/n: IM-1RMTRK
1 of 3
