1. Introduction

The On-Q 3x4 Enhanced Bi-directional Video Amplifier (P/N F7630 as shown below) is designed to distribute
external CATV/Antenna and multiple internal modulated RF signals around the home. Its four high gain
outputs are designed to be used to drive passive splitter modules to provide up to 32 amplified video outputs.

2. Description

The On-Q 3x4 Enhanced Bi-directional Video Amplifier, (see Figure 1) is designed to be mounted in a double
bay bracket with push-pins at each corner of the module.
NOTE: Due to the orientation of the RF connectors and bend radius limitations of coaxial cable, the
3x4 Enhanced Video Amplifier should only be installed in the deeper Titan enclosure, or
Premium/Custom enclosures with enclosure extenders added.
Aux
inputs
3. Installation
The On-Q 3x4 Enhanced Bi-directional Video Amplifier is typically installed during "trim-out" or as an
upgrade for an existing installation.
©Copyright 2005 by On-Q/Legrand All Rights Reserved.
INSTRUCTION/INSTALLATION SHEET
3x4 Enhanced Bi-Directional Video
Amplifier
CATV
input
Figure 1
IS-0317 REV. O
RF outputs for
distribution
CATV input
gain control
Page 1 of 2
