BLUETOOTH
Date:
May 21, 2015
Models Affected:
XT1, XT2 Enduro Series or RZT L/S Models Without Factory Installed Bluetooth
maintenance meter.
Serial Number
Range Affected:
Model Years 2015 and After Production Only.
PURPOSE:
To offer those customers who did not purchase a model that had the Bluetooth
the factory, the option to install a Bluetooth
NOTE: These materials are prepared for use by trained technicians who are experienced in the service and repair of
equipment of the kind described in this publication, and are not intended for use by untrained or inexperienced
individuals. Such individuals should seek the assistance of an authorized service technician or dealer.
NOTE: Always wear eye protection while servicing equipment. Wear hearing protection when appropriate. Always work
in a well ventilated area and follow all safety precautions when dealing with combustible materials.
NOTE: Left (LH) and Right (RH) sides are determined from the operator's position and facing in the forward direction.
1
725-06221
NOTE: For RZT installation follow instructions on Pages 2-3. Estimated installation time 15 - 20 minutes.
NOTE: For XT1 or XT2 installation follow instructions on Pages 4-8. Estimated installation time 15 - 20 minutes.
NOTE: Installation time does not include steps (page 9) to activate / set-up CUB CONNECT
Optional Kit 490-900-C066
ENABLED MAINTENANCE METER
®
®
enabled maintenance meter that works with CUB CONNECT
490-900-C066 Kit Contents
ITEM
PART
QTY
NO.
NUMBER
1
725-06221
1
METER-SVC MNDR/HOUR BLUE TOOTH
2
777I25270
1
LBL-SVC MNDR/HR MTR BLUE TOOTH
3
777I25406
1
LBL-SVC MNDR/HR MTR BTE RZT-S/L
Instruction sheet included with kit.
OPTIONAL KIT
Subject:
Bluetooth
®
DESCRIPTION
2
777I25270
Rider Label
FIGURE 1
1 of 9
490-900-C066
Enabled Maintenance Meter Option
®
®
enabled maintenance meter installed at
777I25406
RZT Label
™
Mobile App.
Form No. 769-10822 /00
enabled
.
™
3
Advertisement
Related Manuals for Cub Cadet 490-900-C066
Summary of Contents for Cub Cadet 490-900-C066
- Page 1 NOTE: Always wear eye protection while servicing equipment. Wear hearing protection when appropriate. Always work in a well ventilated area and follow all safety precautions when dealing with combustible materials. NOTE: Left (LH) and Right (RH) sides are determined from the operator’s position and facing in the forward direction. 490-900-C066 Kit Contents ITEM PART...
- Page 2 11. Remove the black rectangular section from the center of Item #3 (777I25406) RZT Bluetooth ® enabled mainte- nance meter label as shown in Figure 6 and discard. FIGURE 3 Optional Kit 490-900-C066 2 of 9 Form No. 769-10822 /00...
- Page 3 Connect App for your Bluetooth capable Android ® ™ the throttle /choke control slot. See Figure 7. or iOS device. See Page 9 for instructions. Item #3 (777I25406) FIGURE 7 Optional Kit 490-900-C066 3 of 9 Form No. 769-10822 /00...
- Page 4 25. Remove the dash cap shown in Figure 10 by squeez- 27. Remove the steering shaft bearing by lifting up and ing the two (2) tabs together, then pushing the dash cap off the steering shaft. towards the seat. Optional Kit 490-900-C066 4 of 9 Form No. 769-10822 /00...
- Page 5 LCD display and parallel with the edge above and below the Bluetooth ® enabled maintenance meter label. See Figure 17. FIGURE 14 Optional Kit 490-900-C066 5 of 9 Form No. 769-10822 /00...
- Page 6 Locked Into Upper Dash in Figure 19. Tabs On Dash Cap Upper Dash Holes In Upper Dash FIGURE 21 FIGURE 19 Optional Kit 490-900-C066 6 of 9 Form No. 769-10822 /00...
- Page 7 ® meter to your smartphone by downloading the Cub Connect App for your Bluetooth capable Android ® ™ FIGURE 23 or iOS device. See Page 9 for instructions Optional Kit 490-900-C066 7 of 9 Form No. 769-10822 /00...
- Page 8 THIS AREA LEFT INTENTIONALLY BLANK Optional Kit 490-900-C066 8 of 9 Form No. 769-10822 /00...
- Page 9 To finish the setup, you must enter the model and serial number of your unit. You will need to manually enter the 11 digit factory number from the ID tag and you can scan the bar code from the ID tag for the serial number. Once this is done just click on the continue button. Navigation Menu There are 6 navigation options that you can choose from in the navigation menu: ∙ Dashboard – Lists numerous maintenance items you can check ∙ Maintenance Records – Lists all maintenance that has been done to the unit. ∙ Operator’s Manual ∙ Service Centers ∙ Product Registration ∙ Customer Service Operator’s Manual When you pull up the Operator’s Manual, you must accept the disclaimer as you would when you pull it up online and you only have to accept it once. The manual does open up in a PDF format. Find a Service Center Finding a Service Center is the same as using the Dealer locator. Enter your zip code and the mileage range you want and the results will show in a map view or you can select a list view. You can also get directions and the phone number for the dealer. Product Registration You can register your unit right from the Cub Connect app. Product registration is listed as an option in the Naviga‐ ™ tion Menu. You must fill out the required information and click on the complete process button. It will return to the dashboard and the Product Registration should no longer be visible. Optional Kit 490-900-C066 9 of 9 Form No. 769-10822 /00...
