Lightwave Link Plus Instructions page 2

1
Preparation
What do I need? Range & Positioning
The Lightwave Link Plus requires mains power and a The wireless range of a single Link Plus should cover a
standard wireless router with a permanent internet con- typical large house. To ensure the best performance, try
nection in order to operate. You will also require a WiFi not to position the Link next to radiators, water tanks
enabled smartphone, tablet or PC. or very thick walls. Siting the Link as high up as possible
within your home (e.g. on the first floor) will always
provide the best coverage.
Voice Control
You can use your voice with Siri on compatible Apple
devices, with Google Assistant, and with Amazon Alexa
to issue commands to Lightwave, to control devices e.g.
"Turn the living room lights on". See www.lightwaverf.
com for more information.
Control from anywhere
You can control Lightwave devices whilst away from
home using your app. You can also use automations to
schedule devices to work automatically at times that
you set in the App.
Expand your system
Please Note:
The LP2 variant of the Link Plus is not backward com-
Lightwave is very flexible, and you can add new Light-
patible with Connect Series devices. If you are a Con-
wave devices to your system at any time. Other family
nect Series user, you will require the L2 model which is
members can also download the App and use it to con-
backward compatible.
trol devices on their own smartphone or tablet.
Power (Micro USB)
Main button
Specification
RF Frequency: 868MHz
Output Rating: 3W Approx.
Warranty: 2 year standar
Input Rating: 5V
Ethernet Port
Help video & further guidance
For additional guidance, and to watch a video that will
help guide you through the installation process, please
visit the support section on www.lightwaverf.com
Environmentally friendly disposal
Old electrical appliances must not be disposed of
together with residual waste, but have to be disposed
of separately. The disposal at the communal collecting
point via private persons is for free. The owner of old
appliances is responsible to bring the appliances to these
collecting points or to similar collection points. With this
Indicator LED
little personal effort, you contribute to recycle valuable
raw materials and the treatment of toxic substances.
UK
EU Declaration of Conformity
Product: Link Plus Wireless RF Controller
Model/Type: LP2
Manufacturer: LightwaveRF
Address: The Assay Office, 1 Moreton Street,
Birmingham, B1 3AX
This declaration is issued under the sole responsibility
of the LightwaveRF. The object of the declaration
described above is in conformity with the relevant union
harmonisation legislation.
Directive 2011/65/EU ROHS,
Directive 2014/53/EU: (The Radio Equipment Directive)
Conformity is shown by compliance with the applicable
requirements of the following documents:
Reference and date:
EN301489-3 V1.6.1: (EMC), EN300220-2 V3.1.1
(RF), EN62479:2010 (RF Exposure), EN60950-
1:2006+A2:2013 (Safety)
Signed for and on behalf of:
Place of Issue: Birmingham
Date of Issue: August 2021
Name: John Shermer
Position: CTO
