- Page 1 HAnDi-moVe moDel 2800-2815 ceiling motor User gUiDe Read Thoroughly Before Operating Have your system inspected at least yearly. See inside user guide for details. Images may differ from reality. V 1.3 - 30-07-2015 © Handi-Move All rights reserved...
-
Page 2: Table Of Contents
User gUiDe ceiling motor Table of contents Safety instructions ............................3 Scope of application ............................ 5 Product information ............................ 6 3.1. Types of ceiling motors ........................7 Assembly instructions ..........................8 Explanation of the symbols ........................10 5.1. Control ............................10 5.2. -
Page 3: Safety Instructions
Permissible load may vary betWeen the ceiling motor sPreader bar and sling he loWest Permissible load mUst then be regarded as the maximUm Permissible load 2800 2810) he magnets in the handcontrol tyPe can affect the oPeration of Pace... - Page 4 User gUiDe ceiling motor fUrther information Please contact yoUr doctor do not short circUit the battery terminals 88 l / 40 he minimUm Weight for the manUal emergency doWn is Weight Person accessories o not PUsh the eiling otor faster than at normal stePPing sPeed Batteries must be removed and recycled according to the statutory provisions.
-
Page 5: Scope Of Application
User gUiDe ceiling motor 2. Scope of application The ceiling motor is used in hospitals, rehabilitation centres, geriatric centres, care homes, day centres and private homes for transfers to or from a bed, armchair, wheelchair, bath, toilet, the floor, nursing table etc. To transfer handicapped persons or persons with movement disorders. -
Page 6: Product Information
User gUiDe ceiling motor 3. Product information this user guide refers to the following parts on your Handi-move ceiling motor: A Motor band B Swivel Hook c Contact ski’s D Trolley e Driving wheel lateral motor (Model 2810 L and 2815 L IR) Emergency stop cord g Emergency down cord H Control Panel... -
Page 7: Types Of Ceiling Motors
User gUiDe ceiling motor 3.1. Types of ceiling motors There are 4 types of ceiling motors: 2815 The ceiling motor without a lateral motor is for use with an attendant. ■ The ceiling motor is moved laterally by hand. ■ The ceiling motor is operated with an electric handcontrol (2 buttons). -
Page 8: Assembly Instructions
User gUiDe ceiling motor 4. Assembly instructions The ceiling motor is only used with a Handi-Move rail system or a system approved by Handi-Move. The inspection may only be carried out by Handi-Move or a technician approved by Handi-Move. cAUtion! he maximUm Permissible load may vary betWeen the ceiling motor sPreader bar and sling... - Page 9 User gUiDe ceiling motor cAUtion! ake sUre that the cords of the emergency stoP and the emergency doWn are cUt to the correct length in order for this User to each them easily If the red cord of the emergency stop is too long, it may be unintentionally activated: adjust the length of the cords according to the user's needs so he/she can easily handle them.
-
Page 10: Explanation Of The Symbols
User gUiDe ceiling motor 5. Explanation of the symbols 5.1. Control Press this button to lift the user. Press this button to lower the user. Press this button to move the ceiling motor in the direction of the arrow (only models with lateral motor). Emergency switch Emergency down Connection of the handcontrol... -
Page 11: Nameplate And Packaging Label
Client/klant/client/Kunde : Client/klan Order/bestelling/commande/Bestellung : Order/best CEILING HOIST/PLAFONDMOTOR / Contents: Contents: MOTEUR PLAFOND/ DECKENLIFTER MOTEUR Model/model/modèle/Modell : Model/mod 2800 2805 2810 2815 2800 2801 2806 2801 2802 2807 2802... -
Page 12: Operation
User gUiDe ceiling motor 6. Operation 6.1. The electric handcontrol for 2815 and 2810 L The electric handcontrol ( J/K), connected to the Ceiling Motor with the spiral cable and connector, has either two (2815) or four buttons (2815 L), depending on the motor version. UP and DOWN, LEFT and RIGHT are marked with the appropriate arrows. -
Page 13: The Infrared Handcontrol For 2805 Ir And 2815 L Ir
User gUiDe ceiling motor 6.2. The infrared handcontrol for 2805 IR and 2815 L IR The infrared handcontrol (I) has 4 buttons, UP, DOWN, LEFT and RIGHT, which are indicated with the appropriate arrows. LIFTING MOTOR LATERAL MOTOR DOWN LEFT RIGHT The .LEFT. -
Page 14: Functions
User gUiDe ceiling motor 7. Battery LED Ceiling Motor batteries must urgently be charged = LED is blue Ceiling Motor is placed on the charging pins and the batteries are being charged by the charger = LED is orange. If the batteries are fully charged, the LED will switch off after 60 seconds. 6.4. -
Page 15: Charging The Batteries
User gUiDe ceiling motor 6.5. Charging the batteries Place the ceiling motor on the charging pins on a regular basis, at least once every 2 days. Overcharging is not possible. If the Ceiling Motor emits a beep and/or the battery LED on the Con- trol Panel is blue, it needs to be charged immediately. -
Page 16: Maintenance And Storage Space
User gUiDe ceiling motor 7. Maintenance and storage space 7.1. Cleaning the ceiling motor Carefully clean the ceiling motor with mild soap and a damp cloth. ■ Avoid making the electrical parts wet (this can damage the motor). ■ Do not use chemical cleaning agents or excess water. ■... -
Page 17: Inspection
User gUiDe ceiling motor 8. Inspection 8.1. Inspection before each use NEVER use the ceiling motor if the motor band (A) is damaged or faulty. ■ Check if the red safety stitching is undamaged. ■ Check if the emergency down (G) is functioning. (See 6.4 "Functions" - p. ■... -
Page 18: Troubleshooting
• 2805 - 2815 L IR: the 3 1,5 V AAA batteries in the handcontrol could be empty. • 2800 - 2805 L: Check if the spiral cable is correctly attached to the connector. When using the handcontrol, you hear a beeping sound and/or the battery leD on the control panel lits blue: The batteries have to be charged urgently. -
Page 19: Replacing Batteries
User gUiDe ceiling motor Make sure that the metal clip is aligned with the gray cover. ■ Push the cover onto the Ceiling Motor until it is fixed in place. ■ 9.4. Replacing batteries First remove the cover, as described in the above instructions. ■... -
Page 20: Replacing Batteries Of The Ir Handcontrol
User gUiDe ceiling motor Check the polarity when connecting the batteries. ■ Attach the red wire to the plus pin (+) of battery 2 ■ Attach the black wire to the minus (-) of battery 1 ■ Connect the minus (-) of battery 1 and the plus of battery 2 using ■... -
Page 21: Technical Specifications
User gUiDe ceiling motor 10. Technical specifications Length (A) 16.14 inch / 41.00 cm Width 13.78 inch / 35.00 cm Height (B) 7.48 inch / 21.00 cm Height until swivel hook (C) 9.84 inch / 25.00 cm Standard length of motor band 78.74 inch / 200.00 cm Height of the rail depending on type of rail... - Page 22 User gUiDe ceiling motor Battery indication ( IR-hand control) Acoustic Protection class IPX0 (motor), IP67 (handcontrol) 15 years, on the condition of correct use, service (see 7) Expected life span and yearly inspections (see 8). (Batteries have an ap- prox. life span of 2 - 4 years depending on the use). Charger Type Mascot 9940 / 2541 Input: 0.9 A 100 - 240 Vac 50 -60 Hz, Class II...
-
Page 23: Parts List
User gUiDe ceiling motor 11. Parts list art. 1560 0000 ........................infrared remote control art. 2580 0001 ......................electric handcontrol 2 buttons art 2580 0002 ......................electric handcontrol 4 buttons A detailed list is available upon request. Parts list p. 23... -
Page 24: Spare Parts, Maintenance And Yearly Inspection
User gUiDe ceiling motor 12. Spare parts, maintenance and yearly inspection To obtain spare parts and maintenance including yearly inspections, contact your Handi-Move representative. For the USA Distributed Exclusively By: Lift & Care Systems andS 982 County Route 1 Pine Island, NY 10969 Tel: 800-724-5305 Fax: 845-258-6634 e-mail: info @surehands.com... -
Page 25: Limited Warranty
User gUiDe ceiling motor 13. Limited Warranty This equipment is sold under an exclusive warranty of two (2) years from date of purchase. The manufacturer warranties the equipment to be free of defects in material and workmanship. We agree to repair or replace any products, or parts thereof, which have been returned to our factory within the stated warranty period, and which after examination shall disclose that the product is defective. -
Page 26: Ec Declaration Of Conformity
......................Ref. Electrical handcontrol handcontrol normal 2800 2805 lateral motor 2810 2815 Konform richtlijn: Conforme la directive: .
