- Page 1 Aston Technologies Inc. www.astontechusa.com Wheel Balancer User’s Manual Model # ADP-2000A - 1 -...
-
Page 2: Table Of Contents
Aston Technologies Inc. www.astontechusa.com INDEX 1. INTRODUCTION ................... 3 1.1 F ..........................3 UNCTION 1.2 P ................... 3 ERFORMANCE AND EATURES 1.3 T ........................3 ECHNICAL DATA 2. TRANSPORTATION AND INSTALLATION ............. 4 2.1 W ..........4 HEEL BALANCER TRANSPORTATION AND NSTALLATION 2.2 M ....................4... -
Page 3: Introduction
Aston Technologies Inc. www.astontechusa.com 1. INTRODUCTION Thank you for your purchasing the computer wheel balancer. 1.1 Function Unbalance wheel results in steering wheel joggling, reduces adhesion force of vehicle, makes the wheels jump and damages tires, shock-absorbers and steering parts. This influences riding comfort and controlling stability and increases oil wear, so that directly influences on vehicle’s economical efficiency index. -
Page 4: Transportation And Installation
Aston Technologies Inc. www.astontechusa.com Net weight 618 lbs. (280kg) -The Max. Weight of wheel can’t exceed 95kg when using 220v motor. -If exceed 95kg,the motor will damage or burn. 2. Transportation and Installation 2.1 Wheel balancer transportation and Installation -Only lift the balancer’s chassis, under any circumstances, do not lift balancer by the main shaft. -
Page 5: Control Panel Graphics
Aston Technologies Inc. www.astontechusa.com -Working environment: temperature 0-50℃, in a dry and well airiness area. 3. CONTROL PANEL GRAPHICS: Ⅰ Display unbalancing value inside the wheel edge Ⅱ Display unbalancing value outside the wheel edge Ⅲ Display unbalancing position inside the wheel edge Ⅳ... -
Page 6: Wheel Balancing Operation Process
Aston Technologies Inc. www.astontechusa.com large sized tire balance A—Function key for manual input the distance between wheel and balancer B (L)—Function key for manual input of rim width D—Function key for manual input of rim diameter Select small sized and large sized tire balance RESET and ADJUSTMENT key STOP key Selected key of balancing mode... -
Page 7: Tire Mounting
Aston Technologies Inc. www.astontechusa.com 4.2.1 Tire mounting ① Fix the screw mandrel on the main shaft. ② Install the tire tested on the main shaft beside the adapter. ③ Select the proper cone to fit over on the main shaft. ④... -
Page 8: Balancing Modes
Aston Technologies Inc. www.astontechusa.com Ⅰ First input dimension “A” ● Measure the distance value “A” from on the inside of rim to the machine body with the distance finding ruler of machine itself. Press 〖△〗, the value increases. Press 〖▽〗, the value reduces. Until display the value “A”... -
Page 9: Balancing Wheels
Aston Technologies Inc. www.astontechusa.com Continuously press the key F, select balancing modes based on the state of balancing mode indicator LEDs. When the machine is switched on every time, the system can enter automatically dynamic balancing mode, and need not select. -
Page 10: Maintenance
Aston Technologies Inc. www.astontechusa.com all the inner indicator LEDs light, shown in Fig.2, place 40g lead block at twelve o’clock position on the inside of rim. Continue to rotate the tire until a zero (0) appears in the inner LEDs window, as Fig.3 shown. -
Page 11: Self-Calibrating With A Tire Balanced
Aston Technologies Inc. www.astontechusa.com or 14 inches), install it on the main shaft, input the value A, L, D of this tire. Caution: Select the better tire to self-calibrate, input the correct dimension, or else result in calibrating inaccurately. 5.1.1 Self-calibrating with a tire balanced 1. -
Page 12: Self-Calibration Trouble Shooting
Aston Technologies Inc. www.astontechusa.com succeeds. 5.1.3 Self-calibration trouble shooting Troubles Reasons Solutions Display Err, -8- 1. Do not place 100g 1. Place 100g lead block. lead block. 2. Check and connect. 2. Lead wire of pressure 3. Replace main board. sensor breaks. -
Page 13: Trouble Shooting
Aston Technologies Inc. www.astontechusa.com display board displays “CAL”--“CAL”. Indicator LEDs of phase position blink, release the keys after indicator LEDs go out. Left Window Right Window Fig.1 2. Continuously press the keys ▽, △ and F of distance dimension A, shown in Fig.2, if the value displayed is not correct, press the keys △... - Page 14 Aston Technologies Inc. www.astontechusa.com Display after starting but do Capacitor of motor did Replace 20UF/400V not work and buzz, display not work. capacitor. Err1. 1. Display Err1 and do not 1. Starting delay is 1. Replace delay or power panel. rotate.
-
Page 15: Structure Of Pressure Sensor And Steps Of Adjustment
Aston Technologies Inc. www.astontechusa.com and electric welding machine. The value of changed range 1. There are sundries in 1. Replace tire. every rotation is more than the tire. 2. Replace it. dozens of grams. 2. Main board or power Check sensors panel goes wrong. -
Page 16: Accessories
Aston Technologies Inc. www.astontechusa.com Steps: 1. Loosen nuts ①, ②, ③, ④. 2. Drying sensors ⑤, ⑥. 3. First tighten nut ①, and then tighten nut ②. 4. First tighten nut ③, and then tighten nut ④. Caution: The screw mandrel cannot touch the whole edge in the board. 7. - Page 17 Aston Technologies Inc. www.astontechusa.com TD01 Lock washer bolt TD02 Calipers TD03 Balancing pliers TD04 Screw mandrel TD05 Flange 1# TD06 Flange 2# TD07 Cone 1# TD08 Cone 2# TD09 Cone 3# TD10 Cone 4# TD11 Cone 5# Accessories figure as follows: WHEEL BALANCER - 17 -...
- Page 18 Aston Technologies Inc. www.astontechusa.com Name Qty. Name Qty. Bearing Hexangular screw M8×30 Phase disc Elastic ring 8 Circircle Flat washer 8 Driven pulley Screw M4×10 Belt Screw M3×10 Mainshaft Screw with flat washer M3 ×10 Shaft disc Nut M12 Big adapter Flat washer 12 Small adapter Belleville washer 12...
- Page 19 Aston Technologies Inc. www.astontechusa.com washer 10 Panel connection board Bearing 6006 13×30× Panel back cover Block ring（for shaft）30 Computer board Bearing 6005 12×25× Insulation mat 3 Block ring（for shaft）25 Panel scaleboard WHEEL BALANCER） panel Connection line filter Hexangular bolt M6×20 Aerodynamic control valve...
- Page 20 Aston Technologies Inc. www.astontechusa.com Power main board Washer Belleville washer Aluminium spacer Plastic support Screw Aluminium alloy plate Transformer Relay - 20 -...
- Page 21 Aston Technologies Inc. www.astontechusa.com - 21 -...
- Page 22 Aston Technologies Inc. www.astontechusa.com - 22 -...
- Page 23 Aston Technologies Inc. www.astontechusa.com - 23 -...
- Page 24 Aston Technologies Inc. www.astontechusa.com - 24 -...
