Aston Technologies Inc.
www.astontechusa.com
Wheel Balancer User's Manual
Model # ADP-2000L
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADP-2000L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aston Global ADP-2000L

  • Page 1 Aston Technologies Inc. www.astontechusa.com Wheel Balancer User’s Manual Model # ADP-2000L - 1 -...
  • Page 2: Table Of Contents

    Aston Technologies Inc. www.astontechusa.com INDEX 1. INTRODUCTION ................... 3 1.1 F ..........................3 UNCTION 1.2 P ................... 3 ERFORMANCE AND EATURES 1.3 T ........................3 ECHNICAL DATA 2. TRANSPORTATION AND INSTALLATION ............. 3 2.1 W ..........3 HEEL BALANCER TRANSPORTATION AND NSTALLATION 2.2 M ....................4...
  • Page 3: Introduction

    Aston Technologies Inc. www.astontechusa.com 1. INTRODUCTION Thank you for your purchasing the computer wheel balancer. 1.1 Function Unbalance wheel results in steering wheel joggling, reduces adhesion force of vehicle, makes the wheels jump and damages tires, shock-absorbers and steering parts. This influences riding comfort and controlling stability and increases oil wear, so that directly influences on vehicle’s economical efficiency index.
  • Page 4: Main Shaft Installation

    Aston Technologies Inc. www.astontechusa.com enough space around (not less than 500mm). There are screw holes on the chassis of the machine, fix the machine into the concrete floor with expansion bolts. And fixing it unstably will produce measurement error. 2.2 Main shaft installation Before installing, clean up the centre hole of main shaft and connecting piece using alcohol or gasoline, tighten the screw mandrel tightly on the main shaft with spanner.
  • Page 5: Control Panel Graphics

    Aston Technologies Inc. www.astontechusa.com 3. CONTROL PANEL GRAPHICS: Ⅰ Display unbalancing value inside the wheel edge Ⅱ Display unbalancing value outside the wheel edge Ⅲ Display unbalancing position inside the wheel edge Ⅳ Display unbalancing position outside the wheel edge Ⅴ...
  • Page 6: Wheel Balancing Operation Process

    Aston Technologies Inc. www.astontechusa.com D—Function key for manual input of rim diameter Select small sized and large sized tire balance RESET and ADJUSTMENT key STOP key Selected key of balancing mode START key <5g high accuracy balancing key (car) <5g high accuracy balancing key (truck) Caution: Only press the keys with hands, and do not press the keys using clamp and any other sharp things.
  • Page 7: Tire Mounting With Special Flange

    Aston Technologies Inc. www.astontechusa.com over on the main shaft. ④ Tighten with lock washer nut. 4.2.2 Tire mounting with special flange ① Install the flange on the adapter, tighten it with bolt. ② Fix the screw mandrel on the main shaft. ③...
  • Page 8: Balancing Modes

    Aston Technologies Inc. www.astontechusa.com machine itself. Press 〖△〗, the value increases. Press 〖▽〗, the value reduces. Until display the value “A” that is measured. Ⅱ Then input dimension “L” (B) ● Measure the width value “L” (B) of rim with width calipers.
  • Page 9: Balancing Wheels

    Aston Technologies Inc. www.astontechusa.com Static balancing—STATIC correction is required for motorcycle wheels or when it is impossible to place the weights on both sides of the rim. The adhesive position of wheel weights as shown in left Figure. ALU1—Balance alloy rim by placing the adhesive weights onto the rim shoulders.
  • Page 10: Maintenance

    Aston Technologies Inc. www.astontechusa.com 3. Rotate the tire slowly, when all the outer indicator LEDs light, shown in Fig.4, place 10g lead block at twelve o’clock position on the outside of rim. 4. Continue to rotate the tire again until a zero (0) appears in the outer LEDs window.
  • Page 11: Self-Calibrating With A Tire Balanced

    Aston Technologies Inc. www.astontechusa.com 5.1.1 Self-calibrating with a tire balanced 1. First press the keys R & START, the display board displays “CAL”--“CAL”. Indicator LEDs blink, release the keys after indicator LEDs go out. 2. Then press the key START, the wheel rotates and automatically brakes, the display board displays “ADD”--“100”, place 100g balancing weight at any position on the outside...
  • Page 12 Aston Technologies Inc. www.astontechusa.com 2. Lead wire of pressure 3. Replace main board. sensor breaks. Main board goes wrong. Error is much greater 1. May be error of tire 1. Replace a balanced after self-calibrating. itself is much greater. standard tire. Three memory 2.
  • Page 13: Trouble Shooting

    Aston Technologies Inc. www.astontechusa.com Fig.1 2. Continuously press the keys ▽, △ and F of distance dimension A, shown in Fig.2, if the value displayed is not correct, press the keys △ and ▽ of width dimension L to adjust. Fig.2 Standard Memory Correcting the degree of accuracy of value 3.
  • Page 14 Aston Technologies Inc. www.astontechusa.com 1. Display Err1 and do not 1. Starting delay is 1. Replace delay or power panel. rotate. damaged. 2. Adjust photoelectric tube 2. Display Err1 and rotate. 2. Phase position shelf, replace main board. generator goes wrong 3.
  • Page 15: Structure Of Pressure Sensor And Steps Of Adjustment

    Aston Technologies Inc. www.astontechusa.com every rotation is more than the tire. 2. Replace it. dozens of grams. 2. Main board or power Check sensors panel goes wrong. connecting line. 3. Sensor is placed 4. Examine and repair or install unsteadily. the manostat.
  • Page 16: Accessories

    Aston Technologies Inc. www.astontechusa.com Steps: 1. Loosen nuts ①, ②, ③, ④. 2. Drying sensors ⑤, ⑥. 3. First tighten nut ①, and then tighten nut ②. 4. First tighten nut ③, and then tighten nut ④. Caution: The screw mandrel cannot touch the whole edge in the board. 7.
  • Page 17 Aston Technologies Inc. www.astontechusa.com TD02 Calipers TD03 Balancing pliers TD04 Screw mandrel TD05 Flange 1# TD06 Flange 2# TD07 Cone 1# TD08 Cone 2# TD09 Cone 3# TD10 Cone 4# TD11 Cone 5# Accessories figure as follows: WHEEL BALANCER Name Qty.
  • Page 18 Aston Technologies Inc. www.astontechusa.com Bearing Hexangular screw M8×30 Phase disc Elastic ring 8 Circircle Flat washer 8 Driven pulley Screw M4×10 Belt Screw M3×10 Mainshaft Screw with flat washer M3 ×10 Shaft disc Nut M12 Big adapter Flat washer 12 Small adapter Belleville washer 12 Terminal...
  • Page 19 Aston Technologies Inc. www.astontechusa.com Panel connection board Bearing 6006 13×30× Panel back cover Block ring(for shaft)30 Computer board Bearing 6005 12×25× Insulation mat 3 Block ring(for shaft)25 Panel scaleboard WHEEL BALANCER) panel Connection line filter Hexangular bolt M6×20 Aerodynamic control valve Nut M6 Relay base...
  • Page 20 Aston Technologies Inc. www.astontechusa.com Power main board Washer Belleville washer Aluminium spacer Plastic support Screw Aluminium alloy plate Transformer Relay - 20 -...
  • Page 21 Aston Technologies Inc. www.astontechusa.com - 21 -...
  • Page 22 Aston Technologies Inc. www.astontechusa.com - 22 -...
  • Page 23 Aston Technologies Inc. www.astontechusa.com - 23 -...
  • Page 24 Aston Technologies Inc. www.astontechusa.com - 24 -...
