BGE BGO1402-20 Instruction Manual

Diesel radiant heater

Advertisement

Quick Links

This heater is designed for outdoor use.
▲DANGER:GENERAL HAZARD WARNING:
READ AND UNDERSTAND ALL OF THE INSTRCUTIONS IN THIS MANUAL
BEFORE ASSEMBLING, STARTING, OR SERVICING THE HEATER. Be sure to
comply with the instructions and warnings provided with this heater. Failure to
comply can result in fire and explosion that can cause property loss, bodily injury, or
loss of life.
▲DANGER:
1.. Never use the heater where flammable vapors may be present, there is danger
of explosion, fire and burning
2. Always provide adequate ventilation during the use. Only use the appliance in
well ventilated area, the air must be regular exchanged during the use (two
times/one hour) , inadequate burning caused by oxygen shortage can cause carbon
monoxide poisoning
3. Don't expose the appliance to rain or snow, never use it in humidity places either.
Pull out the plug before the routine maintenance and examination.
HITCHON INTERNAITONAL LTD, 32 HAMMERSMITH DRIVE, WIGRAM, CHRISTCHURCH,
NEW ZEALAND
DIESEL RADIANT HEATER
INSTRUCTION MANUAL
Model No.: BGO1402-20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BGO1402-20 and is the answer not in the manual?

Questions and answers

Summary of Contents for BGE BGO1402-20

  • Page 1 DIESEL RADIANT HEATER INSTRUCTION MANUAL Model No.: BGO1402-20 This heater is designed for outdoor use. ▲DANGER:GENERAL HAZARD WARNING: READ AND UNDERSTAND ALL OF THE INSTRCUTIONS IN THIS MANUAL BEFORE ASSEMBLING, STARTING, OR SERVICING THE HEATER. Be sure to comply with the instructions and warnings provided with this heater. Failure to comply can result in fire and explosion that can cause property loss, bodily injury, or loss of life.
  • Page 2 【TECHNICAL】 MODEL BGO1402-20 20 kW Power kg/h Fuel consumption AUTOMOTIVE DIESEL ONLY Kind of fuel 10.5L Fuel tank 220-240V ~ 50Hz 110W Electrical supply 18.2 kg N.W. 0.4 GpH 60°S DANFOSS Nozzle type...
  • Page 3 【FIGURES】 NO.1 NO.3 NO.2...
  • Page 4: Safety Information(Warnings)

    IMPORTANT:READ AND UNDERSTAND THIS OPERATIONAL MANUAL BEFORE PERFORMING ASSEMBLY,COMMISSIONING OR MAINTENANCE ON THIS GENERATOR.INCORRECT USE OF THE GENERATOR CAN CAUSES SERIOUS INJUIRY. KEEP THIS MANUAL FOR FUTHER REFERENCE. 【1.SAFETY INFORMATION(WARNINGS)】 ▲ IMPORTANT NOTICE: -This appliance cannot be used by any persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 5 AND GO OUTSIDE, next, notify the technical service center that the generator needs to be repaired. 1.1. SUPPLY: 1.1.1 Personnel in charge of supply must be fully qualified, must be familiar with  the manufacturer’s manual as well as the effective regulations for safe supply of generators.
  • Page 6: Operating Principle

    1.2.9. Animals are to be kept at a safe distance away from the generator.  1.2.10. Unplug the generator at all times during downtime.  1.2.11. Thermostat control allows the generator to be turned on at any time.  1.2.12. The generator must not be used in frequently visited rooms and in ...
  • Page 7: Running The Generator

    ▲ WARNING: Read the section “SAFETY CONSIDERATIONS” carefully before turning the generator on. 【4.1 RUNNING THE GENERATOR】 4.1.1. Observe all safety instruction at all times.  4.1.2. Check the fuel is present in the tank.  4.1.3. Close the fuel tank filler plug. ...
  • Page 8: Maintenance And Transportation

    【6.MAINTENANCE AND TRANSPORTATION】 TO ENSURE THE BEST MAINTENANCE AND/OR TRANSPORTATION PROCEDURE, PLEASE OBSERVE THE FOLLOWING PROCEDURE: 6.1. Empty the fuel tank.  6.2. If remainders are still present, pour in clean fuel and empty it again  6.3. Close the tank filler plug, dispose of the fuel as per the applicable ...
  • Page 9: Display Errors

    【7.DISPLAY ERRORS】 See B Fig.3 ERROR CAUSE SOLUTION OPERATION ERROR After disconnecting 1. The “| ( ON) /O (OFF)” switch generator, see that the switch is turned “| (ON)” when the is in the “O(OFF)” position, generator is plugged plug the generator in and turn the switch “(|) ON”...
  • Page 10: Preventive Maintenance Schedule

    【8. PREVENTIVE MAINTENANCE SCHEDULE】 WARNING: BEFORE INITIATING REPAIR MAINTENANCE PROCEDURE UNPLUG THE FEEDER CABLE AND MAKE SURE THAT THE GENERATOR IS COOLED DOWN. COMPONENT MAINTENANCE MAINTENANCE FREQUENCY PROCEDURE Clean every 150-200 hours of Empty and rinse with fresh fuel Fuel tank operation when when...
  • Page 11 Wrong thermostat setting 6. Calibrate the thermostat by setting higher than ambient temperature Temperature sensor 7. 1)Wait at least ten minutes override then try to run ignition again 2)Contact technical service center Fuse damaged 8. Contact the technical service center Motor/Pump No fuel Turn off the generator,...
  • Page 12: Installation

    【10.Installation】 1.Open the two screws on the fixed rings 2.Put the protection panel on the designated spot to meet the screw holes. 3.Set the screws with the protection panel 1. Front grill installation 2. Handle installation Stand installation...
