Foss FP60 Installation Manual

fossfibreoptics.com
Panel installation FP60/65
Content
1. General ...................................................................................................... 1
2. Materials .................................................................................................... 1
3.1 Alternative bracket assembly .................................................................... 2
3.2 Closing the fibre guides.............................................................................. 2
4. Installing pre-terminated cable with tight buffered fibre .......................... 3
5. Splicing cable with tight buffered fibre ...................................................... 4
6. Splicing cable with loose tube
A. Fibre tubes, up to 48 fibres .................................................................. 5
B. Fibre tubes, over 48 fibres (High Density) ........................................... 6
C. Fibre tubes, in corrugated tubes ......................................................... 6
7. Installing direct terminated cable
A. Cable with tight buffered fibre ............................................................ 7
B. Cable with loose tube .......................................................................... 7

1. General

This manual describes installation of pre-terminated cable, termination of cable using splicing and direct termination* of cable in panel
FP60 PRO or FP65 PRO. Some parts of the shown installations may already be finished before delivery. If installing less fibres and/or other
adapter types than shown, the manual is followed to the extent possible. When terminating less fibres than the adapter plate can hold, the
rest of the holes are fitted with blind plugs.
All installation is described with the cable from the left side. If the cable should be from the right, the installation has to be mirrored
accordingly.
It is recommended to read the whole manual once before starting the installation.
Colour codes for cables delivered by Foss may be found under the icons to the right.
* Direct terminated cable means that the cable is prepared and the connectors assembled in the field. The connectors may be prepolished and
without glue or meant for glue and polishing in the field. It may also be connectors intended for direct splicing to the fibre. Glue-free
connectors may be e.g. FAST or UniCam. Connectors for direct splicing to the fibre may be e.g. FuseConnect.

2. Materials

Tools:
- Socket wrench 12 mm or 13 mm
- Torx 25 screwdriver
- PZ2 screwdriver
- Heat gun
Additional equipment:
Depending on the application the following may be necessary:
PS-3A-X Heat shrink tube, 60 mm, 100 pkn
PS-3A-X/45 Heat shrink tube, 45 mm, 100 pkn
4415 Cleaning kit, cables, grease
MANUAL IV5016-E Issue J Page 1 of 7
For use with FC or ST adapters
For splicing
Alternative to 60 mm
For cables with loose tube
Colour codes
