President George

User manual

1) Power

a) One quick press on this key turns your CB on and off

b) A longer depression (about three seconds) activates the protection by code procedure The code must

be re-entered to put the set on

NOTE As soon as your set goes off. The last configuration is memorised ready for the next time

a) Set turned off (but with power supply connected): by pressing the DIMMER key the message codE

flashes indicating clearly and permanently the code protection in your absence. You should not leave

this function on for more than three days without starting your vehicle`s engine(risk of flat battery)

b) With the set turned on: This key allows you to adjust the luminosity of the display.

With this key you can change the colour ofthe digital display to either amber or green,so that your set

is in harmony with the interior of your vehicle.

To increase the volume, turn this knob ciockwise.

Table of Contents

Do you have a question about the George and is the answer not in the manual?

Page 1 President George User manual 1) Power a) One quick press on this key turns your CB on and off b) A longer depression (about three seconds) activates the protection by code procedure The code must be re-entered to put the set on NOTE As soon as your set goes off.
Page 2 10) MIC GAIN: a) Is for regulating microphone sensitivity, when using a microphone other than the one supplied with your PRESIDENT GEORGE (pre-amplified). b) Also adjusts the sound volume of Public Address mode (see point 17) The normal setting of this knob is fully clockwise.
Page 3 VOLUME knob. 17) PA (Public Address): An external loudspeaker can be connected to your PRESIDENT GEORGE by the jack plug situated on the back panel PA.SP (E). By pressing the PA key, the message transmitted into the microphone will be directed towards the external speaker and be amplified.
Page 4 By pressing this key once, a line appears under the 10 digit to show the channel and under the 100 digit of the kHz for the frequency. To cancel the underlinings, re-press the same key. 20) CH 19 (Channel 19 AM): Channel 19 AM is automaticaily selected when you depress this key.
Page 5 CB is blocked and it is necessary to enter the correct access code. The access code, established by PRESIDENT in the factory or after being returned to the After Sales Service department is: 4 shorf depressions of the PROGRAM key.
