QUICK REFERENCE
IMS5
LASER SCANNER
SYSTEM
CONTROLLER
ROTATOR
MAPPING SPACE
1. Create a project
2. Enter wall thickness
3. Create a floor
4. Turn laser scanner ON
5. Create a scan in every space
6. Switch floors when necessary
SURVEY
SYSTEM BATTERY
CHARGING PORT
STILL PICTURE
SHOOT
CREATING SCANS
1. Place the camera in a suitable location
2. Ensure rotator is clicked into one of three
positions
3. Press Shoot button
4. Rotate clockwise into the next position
5. Press Shoot button
6. Rotate clockwise into the next position
7. Press Shoot button
8. Align data using Pano: Move and Save
INDICATORS
SHRINK MAP
SYSTEM BATTERY
LEVEL
RELOAD
SYSTEM BATTERY
TIME REMAINING
EDITING DATA
1. Copy data from USB drive to your computer
2. Open project folder in Stitch
3. Check scan data alignment
4. Check panorama alignment and color
5. Disable panoramas if desired
6. Export data
7. Upload data to manage.youriguide.com
CAMERA TILT
INDICATOR
DSLR BATTERY
LEVEL
MOVEMENT SPEED
INDICATOR
Advertisement
Table of Contents
Related Manuals for iGUIDE IMS-5
Summary of Contents for iGUIDE IMS-5
- Page 1 QUICK REFERENCE IMS5 SURVEY INDICATORS SHRINK MAP LASER SCANNER CAMERA TILT INDICATOR SYSTEM BATTERY DSLR BATTERY SYSTEM BATTERY LEVEL LEVEL SYSTEM CONTROLLER RELOAD CHARGING PORT STILL PICTURE ROTATOR MOVEMENT SPEED INDICATOR SYSTEM BATTERY TIME REMAINING SHOOT MAPPING SPACE CREATING SCANS EDITING DATA 1.
- Page 2 QUICK START GUIDE Thank you for choosing the iGUIDE IMS-5 Camera System. To get started: CHARGE CONNECT CONTACT CONNECT Sales Plug the AC adapter into the battery holder Place the camera on a tripod attached to the system to charge the main...
