TEXTRON AVIATION INC.
AIRCRAFT DIVISION
WICHITA, KANSAS 67277
MODEL 525B AVIONICS STANDBY SYSTEM UPDATE
ICA Supplement
MODEL NO: 525B
SUPPLEMENT NO: ICA-525B-34-00004
SUPPLEMENT DATE: 2/23/2022
© TEXTRON AVIATION INC.
Form 2261 Rev 1
