- Page 1 FULL-MOTION TV WALL MOUNT EV2001SD customerservice@everviewmount.com...
-
Page 2: Maximum Weight Capacity
WARNING! WARNING! SEVERE PERSONAL INJURY AND PROPERTY DAMAGE CAN RESULT FROM IMPROPER INSTALLATION OR ASSEMBLY. READ THE FOLLOWING WARNINGS BEFORE BEGINNING. If you do not understand the instructions or have any concerns or questions, please contact a qualified installer. Do not install or assemble if the product or hardware is damaged or missing. Not all parts and hardware included must be used. -
Page 3: Supplied Hardware
Supplied Hardware Lag Bolts Washers ø8mm 5/16x2 in Washers Spacers bubble level Spacers Philips Screws Philips Screws Philips Screws ø6mm L15mm L5mm M6 x 12mm M8 x 25mm M4 x 12mm M6 x 30mm M8 x 50mm M4 x 30mm 2PCS... - Page 4 Step 1 Before TV bracket installation 75 mm ≈ 2 7/8 in 100 mm ≈ 4 in 200 mm ≈ 7 7/8 in 300 mm ≈ 11 3/4 in 400 mm ≈ 15 3/4 in Measure the distance between the holes located at the back of your TV(these measures may form the shape of a square , or a rectangle) and check that these taken measures are within the VESA(*)
- Page 5 Step 2 Install TV bracket Manual Only! M6 x 12mm M8 x 25mm M4 x 12mm for your reference Manual Only! M6 x 30mm M8 x 50mm M4 x 30mm for your reference...
- Page 6 Step 3 Ensure the wall plate is securely fastened to the wall before continuing on to the next step. These anchors are for concrete or brick walls ONLY. DO NOT use them in drywall or wood studs. Use a stud finder (not included) to locate wood stud.
- Page 7 Drill 4 pilot holes using a 7/32 in. (5.5mm) diameter drill bit. Make sure the depth is not less than 2 3/8" (60mm).er locations. LEVEL Mount wall plate using 4 sets of 2 3/8 in lag bolts washers with a 1/2 in. socket wrench (not included).
- Page 8 Step 4 Mounting your TV to the Brackets and lock it. locking...
- Page 9 Step 5 Post Installation Level If needed, the TV can be leveled +/-3 degrees. 25/64 in. (10 mm) Metric Wrench...
-
Page 10: Tilt Adjustment
Step 6 Tilt adjustment If mount can not tilt freely, pls adjust the hardness of nut in both sides. Tilt adjustment... - Page 12 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us. Email：customerservice@everviewmount.com...
