Evo VT1 Instruction Manual

VT1 E-SCOOTER
INSTRUCTION MANUAL
Please read and understand this entire manual before assembly or use
IMPORTANT
Age:
1. WARNING! Not to be used in traffic.
6 Years+
2. WARNING! It is dangerous to use this electric scooter in areas other than
private grounds.
Maximum
3. Adult assembly required.
user weight:
4. WARNING! Protective equipment should be worn.
50 kg
IMPORTANT:
Please contact our customer service number if any enquiries:
www.htigroup.co.uk
evo-support@htigroup.co.uk
0300 303 5544
Save all packaging material until assembly is completed.
HTI Group, Eastham House,
Copse Road, Fleetwood,
FY7 7NY, UK
WARNING!
HTI EU Authorised Representative
The Merrion Buildings -
Iconic Offices, 18-20 Merrion Street,
Dublin 2, D02 XH98, Ireland
6
+
TABLE OF CONTENTS
P . 1 ABOUT YOUR NEW ELECTRIC SCOOTER / PARTS LIST
P . 2 PARTS DIAGRAM / GENERAL WARNINGS
P . 3 GENERAL WARNINGS / ASSEMBLY AND SET UP
P . 4 ASSEMBLY AND SET UP / FOLDING INSTRUCTION
P . 5 CHARGING YOUR ELECTRIC SCOOTER
P . 6 HOW TO OPERATE YOUR ELECTRIC SCOOTER
P . 7 MAINTAINING YOUR ELECTRIC SCOOTER/ TROUBLESHOOTING GUIDE
ABOUT YOUR NEW ELECTRIC SCOOTER
Thank you for purchasing our product. Keep these points in mind as you read this guide:
Material: Steel & Alu.
Materials
Folded Size(mm):
665*295*133mm
&
Unfolded Size(mm):
Size:
830*350*730mm
Net Weight: 4.5kg
Weight:
Max Load: 50kg
Max Speed(km/h): 8km/h
Max Range(km): 4-6km
Max Incline:3-4°
Scooter:
Using Temperature:
0°C - 45°C
IP Grade: IPX4
PART PART
NO. NAME
1
Body
3 Handlebar
Clamp
5
Charger
Rated power(W): 100W
Motor: Front Wheel Size: 145mm
Rear Wheel Size: 130mm
Rated voltage: 21.6V
Battery:
Capacity(Ah): 2.0Ah
Rated input (V/A): 100-240VAC
50/60Hz 0.8A Max.
Rated output voltage: 25.2V
Current: 0.7A
Charger:
Charging time(H):
2-3Hours
Model No.: FY0182520700B
Type: Type G
PARTS LIST
PART PART
QTY
REMARKS PICTURE
NO. NAME
(pcs)
2
1 Handlebars
Pre-asembled
on top of 4
1
Hex Key
Steering
column
6
1 Instruction
Manual
QTY
REMARKS
(pcs)
1
5mm
1
1
P . 1
