- Page 1 CMU 100 RS485 to 2x RS232 fallback switch User Manual CMU 100 / 2.5.1.1 - 17 CMU 100 / 4.5.1.1 - 17 CMU 100 / 8.5.1.1 - 17 CMU 100 / x.5.1.1 - 17 Device: Document: Code: Date: CMU 100 / x.5.1.1 - 17 User manual CMUMU511 13.02.2021...
-
Page 2: Table Of Contents
CMU 100 - RS485 to 2x RS232 fallback switch Content PREFACE.......................3 CMU 100 SYSTEM..................5 2.1 DESCRIPTION........................5 2.1.1 SOFTWARE........................5 2.1.2 HARDWARE........................5 RS485 TO 2x RS232 FALLBACK SWITCH..........7 3.1 DESCRIPTION........................7 3.2 TYPICAL APPLICATION..................... 7 3.3 APPEARANCE........................8 3.4 HARDWARE DESCRIPTION....................8 3.4.1 MAIN BOARD........................ -
Page 3: Preface
Tel: 00 386 51 643 411, 051 643 411 Email: grega.flander@ediseja21.com www.ediseja21.com Copyright Copyright © Ediseja 21, 2019. All rights reserved. Explanation of the symbols Read the instructions! Device was tested with 2,5 kV or 500 V AC voltage to check the device insulation. - Page 4 CMU 100 - RS485 to 2x RS232 fallback switch Caution indicates that minor personal injury or property damage can result if proper precautions are not taken. This particularly applies to damage on or in the device itself. General information These paper contain the information that is necessary for the proper and safe operation of the described devices.
-
Page 5: Cmu 100 System
CMU 100 - RS485 to 2x RS232 fallback switch CMU 100 SYSTEM DESCRIPTION Communication unit (CMU 100) is modular system of communication devices that can be used for various of tasks such as: communication converter (for example RS232 to RS485) ... - Page 6 CMU 100 - RS485 to 2x RS232 fallback switch Picture 1: CMU 100 system general diagram Page: Device: Document: Code: Date: CMU 100 / x.5.1.1 - 17 User manual CMUMU511 13.02.2021...
-
Page 7: Rs485 To 2X Rs232 Fallback Switch
CMU 100 - RS485 to 2x RS232 fallback switch RS485 TO 2x RS232 FALLBACK SWITCH DESCRIPTION Fallback switch is communication device that switches data between two master ports and one slave port. It is intended to connect one device (RTU) to two master devices (PC). This device contains one RS485 interface (master) and two RS232 interfaces two (slave) ports. -
Page 8: Appearance
CMU 100 - RS485 to 2x RS232 fallback switch APPEARANCE Picture 3: CMU 100 / x.5.1.1 - 17 front view (left) & bottom view (right) HARDWARE DESCRIPTION This configuration of device is made from main board (power supply, LEDs, switches and logic witch), one RS485, and two RS232 interface boards. -
Page 9: Rs485 Interface Board
CMU 100 - RS485 to 2x RS232 fallback switch Switch 0,2 s 0,3 s 0,4 s 0,5 s 1,2 s 1,5 s 2,5 s Default position (1 s) Ports Configuration Port Interface RS485 RS232 RS232 3.4.2 RS485 INTERFACE BOARD Description Single, galvanically isolated, half duplex, RS485 port with Phoenix 3 pin screw connector, with automatic switch to receive after end of transmission and with additional terminating and stabilizating resistors. - Page 10 CMU 100 - RS485 to 2x RS232 fallback switch On this port board so called „true fail-safe“ RS485 chip is used so board works correctly without stabilisation at invalid RS485 bus state. But still switches for stabilisation are provided on port board.
-
Page 11: Rs232 Interface Board
CMU 100 - RS485 to 2x RS232 fallback switch Picture 5: RS485 interface board appearance with switch settings Picture 6: Standard data rate vs cable lenght 3.4.3 RS232 INTERFACE BOARD Description Single, nonisolated, full duplex, RS232 port with DB9 female connector. Supported Rx, Tx and GND pins. - Page 12 CMU 100 - RS485 to 2x RS232 fallback switch Picture 7: DB9 Female connector Cable for connection to PC CMU 100 Direction DB9 M pin Signal Signal DB9 F pin <------- -------> <-------> Page: Device: Document: Code: Date: CMU 100 / x.5.1.1 - 17 User manual CMUMU511 13.02.2021...
-
Page 13: Schematic
CMU 100 - RS485 to 2x RS232 fallback switch SCHEMATIC Picture 8: CMU 100 / x.5.1.1 - 17 schematic Device: Document: Code: Date: Page: CMU 100 / x.5.1.1 - 17 User manual CMUMU511 13.02.2021... -
Page 14: Installation
CMU 100 - RS485 to 2x RS232 fallback switch INSTALLATION INSTALLATION Warning! Hazardous voltage is present inside the device during operation. Disregarding of safety rules can result in severe personal injury or property damage. Only qualified personnel may work with described devices after being familiar with warnings and safety notices in this paper and other safety regulations. -
Page 15: Commissioning & Maintenace
CMU 100 - RS485 to 2x RS232 fallback switch COMMISSIONING & MAINTENACE COMMISSIONING Warning! Hazardous voltage is present inside the device during operation. Disregarding of safety rules can result in severe personal injury or property damage. Only qualified personnel may work with described device after being familiar with warnings and safety notices in this paper and other safety regulations. -
Page 16: Technical Data
CMU 100 - RS485 to 2x RS232 fallback switch TECHNICAL DATA Power supply CMU 100 / 2... CMU 100 / 8... CMU 100 / 4... 110 - 250 V 48 - 60 V 24 V Rated voltage 230 V 48 V 88 - 350 V 38 - 72 V 18 - 36 V... - Page 17 CMU 100 - RS485 to 2x RS232 fallback switch Communication port RS232 (interface type 1) Type RS232 full duplex Direction up to 230 kbit/s Speed* up to 15 m Distance Isolation none; (GND earthed) DB9 female Connector type 1 (Rx) Lines in 1 (Tx) Lines out...
-
Page 18: Dimensions
CMU 100 - RS485 to 2x RS232 fallback switch DIMENSIONS Picture 10: CMU 100 / x.5.1.1 - 17 dimensions Page: Device: Document: Code: Date: CMU 100 / x.5.1.1 - 17 User manual CMUMU511 13.02.2021... -
Page 19: Ordering
CMU 100 - RS485 to 2x RS232 fallback switch ORDERING ORDERING NUMBER: CMU 100 / Mother Board + Enclosure + : Power supply: DC 110 - 250 V or AC 230 V 2 ports converters (no echo possible, mark Function as 0) ..........1 2 to 8 ports converters, star couplers, ... - Page 20 CMU 100 - RS485 to 2x RS232 fallback switch Additional accessories (order if needed): - power supply cable with „schuko“ plug, 2 m - RS232 cable to PC (state the lenght up to 15 m) - fiber optic cables (state the lenght) List of the most common devices: 2 ports converters Port 1...
- Page 21 CMU 100 - RS485 to 2x RS232 fallback switch 10/100 Mbit/s, virtual com port, high voltage RS232 RS232 CMU 100 / 2.9.1.1 - 12 power supply 10/100 Mbit/s, virtual com port, 19200-115200 RS232 RS485 CMU 100 / 2.9.1.5 - 12 bit/s, high voltage power supply 10/100 Mbit/s, virtual com port, 19200-115200 RS485...
- Page 22 CMU 100 / 2.6.6.6.6.1.1.1.1 - 7 4 xFO MM 4x RS232 to RS232, high voltage power supply Contact: Ediseja 21, razvoj elektronskih naprav, d.o.o. Stegne 21C 1000 Ljubljana Slovenia – EU Tel: 00 386 51 643 411, 051 643 411 grega.flander@ediseja21.com...
