- Page 1 6x6 Hunting Blind Manual Tools Needed: -Cordless Drill (12V or higher) -#2 Square Drive Bit -Hammer -Tape Measure -Speed Square ® Little Cottage Co. PO Box 455 Berlin, OH 44610 330-893-4212 www.cottagekits.com © 2008-2009 Little Cottage Co.
- Page 2 6x6 Hunting Blind Manual You will have 6 pieces for the rim, which are cut Thank you for purchasing from Little Cottage Co. on an angle at both ends. (4) 2x4 joists and (2) 4x4 runners To begin locate your 2x4’s for the floor frame.
- Page 3 6x6 Hunting Blind Manual Continue with 2 1/2” screws securing 2x4 Floor Next make sure all corners measure the same as into 4x4 shown. runners. Next locate CDX plywood flooring with angles Once all corners measure the same, Fasten the cut on all corners.
- Page 4 6x6 Hunting Blind Manual Secure with 1 1/4” screws. Next Locate Triangle floor pieces. Secure with 2 1/2” screws on each corner. Locate wall panel with door. Continue with each wall section. Make sure wall is pushed against the floor before fastening.
- Page 5 6x6 Hunting Blind Manual Continue with wall and fasten as shown. To secure top plates fasten with 2 1/2” screws into 2x6 top plate. Remove 2x4 from door on the inside as shown. There are 6 walls total. Before installing 6th panel follow instructions on the next picture.
- Page 6 6x6 Hunting Blind Manual Next install Aluminum corners and fasten with Next install small wood strip on top of aluminum white finish nails. trim with 1 1/4” screws. Locate roof rafters. The rafters are marked top and bottom. Make sure top is up and secure with 1 1/2” screw as shown.
- Page 7 6x6 Hunting Blind Manual Use angle square and make sure rafter is flush Next lift rafters on top plate as shown. with outside edge of 2x6 top plate as shown. Continue with roof. Next install triangle roof pieces. Secure with 1 1/4”...
- Page 8 6x6 Hunting Blind Manual Next locate metal cap for peak and put on a bead You will find a cut in the cap. Insert a bead of of caulk. caulk before installing. Place metal cap on the peak and fasten with white Continue with trim nails.
- Page 9 6x6 Hunting Blind Manual Next locate door handle. Secure with black head screws. Install D handle on the inside. Your Hunting blind assembly is complete, paint as you desire. Construction Manual © 2008-2009 Little Cottage Co. Page 8...
