- Page 1 DHW CIRCULATION PUMPS FOR POTABLE WATER SYSTEMS INSTALLATION AND OPERATING INSTRUCTIONS CONTACT AND FURTHER INFORMATION TACONOVA.COM Taconova Group AG | Neunbrunnenstrasse 40 | CH-8050 Zurich | T +41 44 735 55 55 | F +41 44 735 55 02 | group@taconova.com...
-
Page 2: Table Of Contents
11 Wartung und Service ���������������������������������������������������������������15 12 Faults, Causes and Remedies ..........32 12 Störungen, Ursachen und Beseitigungen ��������������������������������16 13 Entsorgung �����������������������������������������������������������������������������16 13 Disposal ................... 32 V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 2... -
Page 3: Konformitätserklärung
TACOFLOW2 PURE PLUS KONFORMITÄTSERKLÄRUNG DECLARATION OF CONFORMITY DECLARATION DE CONFORMITE Taconova Group AG Nous (Name des Anbieters) (supplier's name) (nom du fournisseur) __________________________________________________________________________ erklären in alleiniger Verantwortung, dass das Produkt declare under our sole responsibility that the product declarons sous notre seule responsabilite que le produit... -
Page 4: Safety Instructions
Prevent hazards arising from electrical energy. Observe the instructions in local or general regulations (e.g. IEC, VDE, etc.), and those of the local energy supplier. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 4... -
Page 5: Personnel Qualification
Children may not play with the device. Cleaning and maintenance operations may not be carried out by children without supervision. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 5... -
Page 6: Danger Of Not Observing Safety Instructions
• In the event of a fluid leak, any fluids must be collected or diverted in a way that prevents hazards to persons and the environment from arising. • Prevent hazards arising from electrical energy. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 6... -
Page 7: Safety Instructions For Installation And Maintenance Work
Only use accessories that have been approved by the manufacturer. The manufacturer shall bear no liability for any consequences resulting from the use of other parts. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 7... -
Page 8: Unpermitted Operation
4 Intended Use The service water pump is used for circulation in single and two family houses with a pipe length of up to 50 m. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 8... -
Page 9: Angaben Über Das Erzeugnis
5 Information About the Product 5.1 Technische Daten TacoFlow2 PURE PLUS 1514/80 5.1 Technische Daten TacoFlow2 PURE PLUS 1514/80 5.1 Technische Daten TacoFlow2 PURE PLUS 1514/80 5.1 Technische Daten TacoFlow2 PURE PLUS 1514/80 5.1 Technical data TacoFlow2 PURE PLUS 15-14/80 Kennlinie Kennlinie Kennlinie Kennlinie Curve characteristic Maximale Förderhöhe... -
Page 10: Scope Of Delivery
The TacoFlow2 PURE PLUS pump can reduce energy consumption by up to 80% compared to a standard circulation pump, whilst maintaining the same level of hydraulic power. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 10... -
Page 11: Pump Settings And Output
When the temperature of the water in the pipeline is lower than the set start temperature, the pump is switched on until the temperature of the water in the pipeline has reached the set stop temperature. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 11... - Page 12 OK. The minutes are now flashing and can be changed. Confirm with OK. Now the hours for the switch-off time flash. After setting, confirm again with „OK“. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 12...
- Page 13 OK. Now the lights are flashing minutes and can be ch- anged. Confirm with OK. The hours for the switch-off time will now flash. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 13...
- Page 14 After a waiting time of approx. 7 seconds, the pump switches to normal operation and the Pump works in the set temperature range. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 14...
- Page 15 „+“ „-“ button for the level setting. Finally press the OK button. „Speed“ flashes and switches after approx. 10 seconds the pump to normal operation. The desired level is now set. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 15...
-
Page 16: Installation
(Fig. 1). When performing insulation work, ensure that the pump motor and the electronics housing are not covered in insulation. Observe the permissible mounting positions: V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 16... -
Page 17: Electrical Connection
• Hazards such as sharp edges and burrs arise during installation. • When transporting the pump, never hold it by the power cable. • The pump could cause an injury if it falls. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 17... -
Page 18: Assembling The Power Plug
Observe the required protective measures, national body regulations and local provisions at all times. The cable cross-section may no smaller than 0.75 mm Use ferrules if using fine-wire cables. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 18... -
Page 19: Filling And Venting The System
There is a risk of scalds! V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 19... -
Page 20: Faults, Causes And Remedies
There is a risk of scalds! Please contact a specialist technician should it not be possible to eliminate the fault. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 20... - Page 21 10 s. electronic error Perform reset * If the error persists, the pump must be replaced. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 21...
-
Page 22: Disposal
To do this, please contact a public or private disposal organi- sation. A list of the materials used in our products is provided in the download area of our website. V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 22... - Page 23 TACOFLOW2 PURE PLUS V1 12/2021 | Art. Nr. 216221 | EA-Nr. 1374 Installation and operating instructions taconova.com | 23...
