Summary of Contents for Yudo TCT-8P
-
Page 2: Table Of Contents
Temperature Controller Version 4.0 用 户 手 册 Thank you for using YUDO production 感谢贵公司使用YUDO产品 Before using the product ,please read this instruction manual carefully to avoid please do not any damage due to improper usage. If you have any questions, hesitate to contact our company technologist. -
Page 3: 1、Environments
Temperature Controller Version 4.0 用 户 手 册 1、Environments 使用环境 1）Main Power Input：AC220V（50-60Hz) 启动电源：AC220V/50-60Hz 2）Signal Input Power：DC24V or AC220V 信号输入电源： DC24V or AC220V 3）Solenoid Valve Output Power：DC24V(Less than 100mA pet GATE）or AC220V(Total less than 1A） 螺旋管针阀输出电源: DC24V(每GATE100mA以下）或者AC220V(1A以下）。 2、Composition of Control Module PCB构成 1）CONTROL PCB: Power unit，MICOM, input/output unit... -
Page 4: 输入因素 5、Display
Temperature Controller Version 4.0 用 户 手 册 ① a. To set parameters 设定参数时使用。 a. Color change mode fast conversion button . To exchange this mode and ② normal mode conveniently. Color Change模式快捷转换按键,此模式和标准模式之间相互快速转换时使用。 ③ a. To open manually a gate or all gate. 各GATE或者全部GATE以手动OPEN（输出）时使用。... -
Page 5: 7、Start To Run
Temperature Controller Version 4.0 用 户 手 册 7、Start to Run 使用说明 Connect cables 1） 输入及输出电源连接 Connect to main input power, signal input from injection machine, output to mold. Make sure the main input voltage (see rear of time case), output voltage to mold. 请按照时间控制器的电源接线图样(参考外壳背面)，连接电源与输入、输出线。... - Page 6 Temperature Controller Version 4.0 用 户 手 册 6） Color Change Function Color Change 功能设定 Output Mode a. ND CNT (constant output mode) 输出模式： ( 恒定输出状态的方式) ND CNT b. ND PWM (pulse output mode) ND PWM (脉冲输出状态的方式） . Gn ( frequency of the pulse output) （脉冲输出频率）...
-
Page 7: 8、 Menu Setting
Temperature Controller Version 4.0 用 户 手 册 7）Set DEL time： DEL时间设置： Move using Direction Key to get gate and its DEL panel, to confirm. 先按 键3秒，进入调试状态，利用 移动到相关GATE的DET显示窗口后按 键。 Right digit in DEL panel blinks 选择的GATE DEL 显示窗口,右边位置的设定值会闪亮。 Set time using 利用... - Page 8 Temperature Controller Version 4.0 用 户 手 册 i) Example 例如： a. In case injection signal =10sec and DEL time =4sec, then after DEL time, it opens (Relay ON) for 6sec. 注塑时间：10秒, DEL 时间: 4秒,按到注塑信号过4秒后, GATE 以OPEN 状态维持6秒钟后 将自动关闭.。 b. For the delay time, it counts down and displays it in DEL display panel, and just after DEL time, it opens (Relay ON).
- Page 9 Temperature Controller Version 4.0 用 户 手 册 b. For the delay time, it count down and displays it in DEL display panel, and just after DEL time, it opens for OPEN time and it counts down from the OPEN set time and displays it in OPEN display panel.
-
Page 10: 9、Mode Specification
Temperature Controller Version 4.0 用 户 手 册 ９、Mode Specification ◆Mode A Selecting mode A: After the injection signal has been received, the gate is continuously closed during the DEL Time(t1),After the DEL time has Gate Open elapsed, the gate Opens and will remain opened 3 sec 10sec until the end of the injection signal. -
Page 11: 10、 System Application
Temperature Controller Version 4.0 用 户 手 册 10、System Applications ◆Application for Mode A Shot Short ①In case that short molding occurs at the extreme of the product. Open the gate A to fill the major portion of the molded Gate A Gate B part, and then open the gate B to fill the short molded... -
Page 12: 11、Wiring Specification
Temperature Controller Version 4.0 用 户 手 册 11、Wiring Specification 外部接线连接图 SEQUENCE INJECTION CONTROLLER Supply Power/Signal Input Input / Output Ratings Connection ex. YELLOW Supply Power: AC220V / 50Hz, 60Hz AC 220v WHITE Signal Input : DC24V, AC220V(Free) AC 220v POWER GREEN EARTH... - Page 13 ABIDO Automation Co., Ltd 地址: 东莞市长安镇乌沙社区民营工业区民一路8号(三四楼) ADD: NO.8 (3-4 floor)Minyi Road Private Industrial Wusha Community Chang'an Town Dongguan Guangdong China TEL: 86-769-82281961/82281967 FAX:86-769-82281969 Http://www.abido.com.cn...
