- Page 1 GP700 GRINDER INSTRUCTION MANUAL Read Manual Before Operating Machine 403309 Rev D...
- Page 2 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
-
Page 3: Table Of Contents
Table of Contents Features and Specifications ............................4 Safety ....................................5 Operation ..................................7 Tooling Installation ..............................7 Adjustable Handle ..............................7 Start-Up Procedure ..............................7 Controller ................................8 Maintenance ................................... 9 Lubricating the Machine ............................9 Keeping Machine Clean ............................9 Replacing Worn, Damaged, Missing Parts ...................... -
Page 4: Features And Specifications
Features and Specifications FEATURES Manual foot leveling device - Improved machine control, faster and Lightweight machine - For ease of transportation, yet has sufficient greater range of adjustments (6 leveling adjustments in 1/8” incre- abrasive pressure by use of the removable weights. ments), and simple to operate. -
Page 5: Safety
Read the manual carefully to learn equipment applications and limitations, as well as potential hazards associated with this type of equipment. Keep manual near machine at all times. If your manual is lost or damaged, contact National Flooring Equipment (NFE) for a replacement. Personal Maintenance &... - Page 6 Safety Safety GRINDER SAFETY GUIDELINES Before use, anyone operating this equipment must read and understand these safety instructions. Grinding Dust Collection Beware of hidden obtrusions. Use with appropriate dust collecting system. Watch out for hidden dangers and protrusions in flooring. Do not Do not operate machine designed for use with a dust collector use on largely uneven surfaces.
-
Page 7: Operation
Operation TOOLING INSTALLATION Remove weights. Raise adjustable handle as far forward as possible; lock into position and put one foot on the rubber-tired wheel. Tip the machine back to the floor so that the handle lays on the floor. Clean mounting surface; slide the diamond into the holder (Figure 1) and tap into place. -
Page 8: Controller
Operation excess damage in the event of an emergency. Lanyard must be worn by operator for this safety device to work properly. Pull key out to stop the machine motor. Controller Settings Below is a list of settings that the operator can scroll through on the controller, in order of appearance. -
Page 9: Maintenance
Maintenance LUBRICATING THE MACHINE Main Gear Case • The main gear case contains 6-1/4 pounds of grease. • Gear case level shoud be checked once a year. The level of the grease in the gear case should be up to half the thickness of the helical gears. Wheel Bearings Use grease gun and grease every six months, 1 shot of grease on each wheel. -
Page 10: Tooling Installation And Replacement
Maintenance TOOLING INSTALLATION AND REPLACEMENT Check diamonds for wear periodically, as they may be worn flush with the holder lugs. 1. Move the counterbalancing weights to the upper weight baskets. 2. Using the flop handle, tilt machine back so that the caster wheel rests on the floor. 3. -
Page 11: Parts List And Diagrams
Parts List and Diagrams... - Page 12 Parts List and Diagrams (403628) (403627) (403629)
- Page 13 Parts List and Diagrams (403630) (403633) (403616) LABEL, 208/230V, 3-PHASE ONLY (403715) PLUG, MALE, HUBBELL TWIST LOCK, 3P4W, 50A 3PH 250V AC (403754) PLUG, FEMALE, HUBBELL TWIST LOCK, 3P4W, 50A 3PH 250V AC (403753)
- Page 14 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
-
Page 15: Warranty
NATIONAL FLOORING EQUIPMENT...
