- Page 1 8274-4 PLANETARY GRINDER OPERATING MANUAL Read Manual Before Operating Machine 402902 Rev B...
-
Page 3: Table Of Contents
Table of Contents Contents Table of Contents ........................................3 Features and Specifications ....................................4 Safety ............................................6 Components and Assembly ....................................7 Loading and Unloading ....................................7 Handle Assembly ......................................7 Vacuum Port ........................................ 7 Rubber Dust Guard....................................... 7 Magnetic Tooling Holder Installation ................................8 Pre-Production Safety Checks.................................. -
Page 4: Features And Specifications
Features and Specifications Adjustable Handle Control Box 15A/20A Switch Dust Collector Port Flip Style Weights T-Bolts (for head removal) 90° Rotating Grinder Adjustable Rubber Deck Dust Guard FEATURES Adjustable Handle - Adjusts in three separate locations for operator Control Box - Self-diagnoses and minimizes blown circuit breakers comfort. - Page 5 Read the manual carefully to learn equipment applications and limitations, as well as potential hazards associated with this type of equipment. Keep manual near machine at all times. If your manual is lost or damaged, contact National Flooring Equipment (NFE) for a replacement. Personal Maintenance &...
-
Page 6: Safety
Safety Safety Safety Safety GRINDER SAFETY GUIDELINES Before use, anyone operating this equipment must read and understand these safety instructions. Grinding Dust Collection Beware of hidden obtrusions. Use with appropriate dust collecting system. Watch out for hidden dangers and protrusions in flooring. Do not Do not operate machine designed for use with a dust collector use on largely uneven surfaces. -
Page 7: Components And Assembly
Components and Assembly LOADING AND UNLOADING • Always disconnect from power source before transporting. • Ensure blanks are installed in magnetic tooling pockets during transport. • Loosen handle securing bolt to slide handle down for loading/unloading. Re-tighten the bolts when handle is at the desired height. CAUTION: HANDLE MUST BE SECURED WITH BOTH BOLTS;... -
Page 8: Magnetic Tooling Holder Installation
Components and Assembly Positioning Unplug machine from power source. With machine sitting in the operating position, remove rubber dust guard held on by Velcro. Starting at one end of the shroud, place guard to rest on floor surface. Firmly press rubber guard into securing Velcro on shroud. Wrap rubber guard all the way around the shroud, making sure the guard rests on the floor surface and is secure (Figure 3). -
Page 9: Operation
Operation START-UP PROCEDURE Plug the controller into a properly sized extention cord (see Safety). Plug the extension cord into an adequate power supply. Attach the control box safety tether to the operator’s wrist. Move the FWD/REV toggle switch to the desired “forward” or “reverse” position. (Figure 5A) The operator should apply a light amount of pressure to the grinder handle to re- lieve the initial torque created when starting the machine. -
Page 10: Accessory Attachment
Operation ACCESSORY ATTACHMENT Tilt motor back to expose the underside of the machine. Clean foreign material from magnet prior to tooling installation. Place the individual tooling segments into two or four of the magnetic pockets. Be careful around pinch points, as the tooling segments will snap into place as the magnetic connection is made (Figure 8). -
Page 11: Troubleshooting Guide
Troubleshooting Guide Fault Code Status Light Fault Description Problem Solution SOLID ON Check safety tether Safety tether is disconnected Attach safety tether to control box. If from controller or faulty con- necessary, check connections inside nection internally with tether controller. Ensure control box is discon- switch. -
Page 13: Warranty
Warranty National Flooring Equipment Inc. (referred to as “the Company”) warrants that each new unit manufactured by The Company, to be free from defects in material and workmanship in normal use and service for a period of twelve (12) months from date of shipment from the Company. For administrative ease, will honor warranty for a period of fifteen (15) months from date of shipment from the company. - Page 14 9250 Xylon Avenue N • Minneapolis, MN 55445 • U.S.A. Toll-free 800-245-0267 • Phone 763-315-5300 • Fax 800-648-7124 • Fax 763-535-8255 Web Site: www.nationalequipment.com • E-Mail: info@nationalequipment.com...
