U P
C
®
ASME A112.18.1 / CSA B125.1
ASME A112.18.2 / CSA B125.2
NSF-61
ICC/ANSI A117.1
Model/Modelo/Modèle
65336 & 65338
Series/Series/Seria
Write purchased model number here.
escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
you may need / Usted puede necesitar / articles dont vous pouvez avoir besoin:
for easy installation of your brizo
faucet you will need:
• To Read aLL the instructions completely
before beginning.
• To Read aLL warnings, care, and maintenance
information.
• To purchase the correct water supply hook-up.
Para instalación fácil de su llave
®
brizo
usted necesitará:
• LeeR todaS las instrucciones completamente
antes de empezar.
• LeeR todoS los avisos, cuidados, e
información de mantenimiento.
• Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet brizo
facilement, vous devez:
• LIRe toUteS les instructions avant de
débuter;
• LIRe toUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Acheter le bon nécessaire de raccordement.
11/7/07
Rev. A
®
®
®
US. Pat. 3,645,493, 3,786,995, 4,523,604, 4,562,960, 4,593,430, 4,218,785, 4,577,653, 4,765,365
tWo handLe WIdeSPRead
LaVatoRy faUCetS
LLaVeS de LaVamanoS
eXtendIdaS de doS manIJaS
RobInetS à entRaXe LonG à
deUX PoIGnÉeS PoUR LaVabo
L
1
L
?
Advertisement
Table of Contents
Related Manuals for Brizo 65336 Series
Summary of Contents for Brizo 65336 Series
- Page 1 Inscrivez le numéro de modèle ici. you may need / Usted puede necesitar / articles dont vous pouvez avoir besoin: ® for easy installation of your brizo faucet you will need: • To Read aLL the instructions completely before beginning.
- Page 2 Note proper end valve installation! Longer copper tubes (1) install away from spout. Slide Snap the quick connect hose assembly (1) onto the spout nipple (2) and hot (2) and cold (3) end valves with gaskets (4) through sink. note: hot side end valve end valve nipples (3).
- Page 3 Step 3b metal Pop-Up Apply silicone to underside of flange (1). Insert body Remove stopper (1) and flange (2). Remove pivot nut (1). Install horizontal rod (2) into sink. Screw flange (1) into body (2). (2) and stopper (3) as removable (4) or non- Step 3c removable (5).
- Page 4 1/2" (13 mm) maintenance If faucet leaks from spout outlet: Shut off water supplies – Replace Seats and Springs (1). * If leak persists: Shut off water supplies – Replace Stem Unit Assembly (2). * make Connections to water lines: Remove aerator (1) and turn faucet handles (2) all *Install stems (2) and 1/4 turn stops (3) the way on.
- Page 5 RP38369 RP52398s End Valve Assembly Base / Base / Embase Ensamble de Válvula Final RP23946 Soupape avec Raccord Gasket / Empaque / Joint RP52393s RP28019 Lift Rod Assembly Threaded Adapter Barra de Alzar Adaptador Enroscado Tige de Manoeuvre Adaptateur fileté RP24938 Bonnet Nut Tuerca del Bonete...
- Page 6 This warranty excludes all industrial, commercial & business usage, whose purchasers are parts may be obtained by calling 1-877-345-BRIZO (2749) (in the U.S. and Canada) or by hereby extended a five year limited warranty from the date of purchase, with all other terms of writing to: this warranty applying except the duration of the warranty.
