Adjusting and Securing the Transducer and Mount

After you connect the transducer to the mount and connect the mount to the transom, you must adjust the
angle and depth.
1 Adjust the angle of the transducer so the element
2 Using an M5 hex wrench, tighten the screw
3 Adjust the height of the transducer bracket
boat is in the water.
4 Using a #2 Philips screwdriver, tighten the five screws that secure the bracket to the transom.
5 Test the angle and depth of the transducer, and make any adjustments as needed.
© 2022 Garmin Ltd. or its subsidiaries
Garmin ® and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. LiveScope
Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin.
© 2022 Garmin Ltd. or its subsidiaries
is parallel with the waterline
that secures the transducer to the mount.
on the transom so that the transducer is submerged when the
.
™ and GLS ™ are trademarks of
