- Page 1 â Apollo Model SL10 Series Audio Selector Panel User’s Guide December 2001 560-0973-00a...
- Page 2 No part of this document may be reproduced in any form or by any means without the express written consent of UPS Aviation Technologies, Inc. UPS Aviation Technologies, Inc., II Morrow, and Apollo are trademarks of UPS Aviation Technologies, Inc. ©...
-
Page 3: Table Of Contents
Marker Beacon (SL10M, SL10M-S... 8 1.6.1 Middle Marker Sense ... 8 1.6.2 External Marker Lights (SL10, SL10S)... 8 1.6.3 Receiver Sensitivity... 9 Section II- Warranty and Service ... 10 Warranty ... 10 Factory Service ... 10 User’s Guide Table of Contents... - Page 4 UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System User’s Guide...
-
Page 5: Section I - General Information
UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System Section I - General Information SCOPE This section provides detailed operating instructions for the UPS Aviation Technologies SL10, SL10S, SL10M, SL10M-S, SL10C, SL10S-C, SL10M-C, and SL10M-S-C Audio Selector Panel/Intercom Systems. -
Page 6: Speaker Amplifier
UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System 1.2.1 Speaker Amplifier The "S" in the push-button section stands for speaker. This switch will place all selected audio on the cockpit speaker when this switch is selected. NOTE: with the exception of unswitched unmuted inputs (Altimeter warning), the speaker amplifier is not active in the "Split Mode."... -
Page 7: Swap Mode (Switch From Com 1 To Com 2 Remotely)
UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System 1.3.1 Swap Mode (Switch from Com 1 to Com 2 remotely) With a yoke mounted, momentary switch, the pilot can change from the current Com transceiver to the other by depressing this switch. When "Swap Mode"... -
Page 8: Volume Control, Stereo, (Sl10S, Sl10Ms)
UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System accessed by the avionics technician. Most general aviation headsets have a built-in volume control, so volume can be adjusted “locally.” 1.5.2 Volume Control, Stereo, (SL10S, SL10MS) The volume control knob adjusts the loudness of the intercom and music for the pilot and copilot only. -
Page 9: Adjusting The Vox- Squelch Control, Stereo (Sl10S, Sl10Ms)
UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System 1.5.4 Adjusting the VOX- Squelch control, Stereo (SL10S, SL10MS) The stereo versions of the SL10 incorporate a single VOX Squelch control for all positions. Like all UPS Aviation Technologies intercoms, since the number of microphones active at any one time is reduced, the unwanted background noise in the headphones is diminished. - Page 10 UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System User’s Guide 1.5.5.1 Soft Mute (Mono) Soft Mute must be enabled during installation by jumpering top connector pins 12 and N. A SPST switch can be installed between these pins for a pilot selectable mute mode.
-
Page 11: Push To Talk Intercom Mode
UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System Table 1 Intercom Modes Pilot Copilot Hears Hears Isola A/C Radio Copilot and Pilot passenger Sidetone intercom (during Entertainment #1 radio transmissi Pilot Copilot Copilot Pilot A/C Radio A/C Radio Passenger Passengers Entertainment #1... -
Page 12: Marker Beacon
Upon first application of power to the unit, the Marker enters a self test mode. The flickering blue marker light indicates a test in process. If the test continues for more than 10 seconds, or the lamps do not extinguish, return the unit for service. -
Page 13: Receiver Sensitivity
UPS Aviation Technologies SL10 Series Audio Selector Panel and Intercom System User’s Guide If using an external marker receiver, the audio input is lower connector, pin 11 (Aux. input). 1.6.3 Receiver Sensitivity Although the SL10M meets FAA TSO-C35d sensitivity specifications, the sensitivity of the receiver has been adjusted to meet real world requirements (150mV and 1400mV Soft). -
Page 14: Section Ii- Warranty And Service
After discussing the problem with the technician and you obtain a Return Authorization Number, ship the product to: UPS Aviation Technologies, Inc. 2345 Turner Road, S.E. Salem, OR 97302 User’s Guide U.S.A. Toll Free 800.525.6726 Page 10... - Page 16 560-0973-00a December 2001...
