Summary of Contents for VWR VWR RV2.5+
- Page 1 Instruction manual ® Rotary Vane Pump European Catalogue Number(s): VWR RV2.5+ 181-0571 VWR RV2.5+ with ACC 181-0572 VWR RV3+ 181-0498 VWR RV6+ 181-0499 VWR RV6+ with ACC 181-0504 VWR RV8+ 181-0503 VWR RV8+ with ACC 181-0574 VWR RV18+ 181-0573 P1700021...
-
Page 2: Legal Address Of Manufacturer
Legal Address of Manufacturer Europe VWR International bv Researchpark Haasrode 2020 Geldenaaksebaan 464 B-3001 Leuven + 32 16 385011 http://be.vwr.com Country of origin China VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 3: Table Of Contents
Overview and Description ......................... 19 8.20 Area of Application ..........................20 8.30 Function ............................21 8.31 Working Principle ..........................21 8.32 Gas ballast ............................21 9.0 Operation ............................... 23 9.10 Starting-up ............................23 VWR Rotary Vane Pump ver 1.3 23.11.2020... - Page 4 Oil Mist Filter 10/16 Exhaust ......................37 12.50 Oil – Technical Data ........................37 13.0 Technical service..........................38 14.0 Warranty ............................... 38 15.0 Compliance with local laws and regulations ..................38 16.0 Equipment disposal (WEEE) ......................39 VWR Rotary Vane Pump ver 1.3 23.11.2020...
-
Page 5: Warning
The CE sign is located on the rating plate. Observe the binding national and local regulations when fitting the pump into installations! Note: The English version is the original version of the operation manual. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 6: General Information
CAUTION! Solid particles in the pumping medium impair the pumping action and can lead to damage. Prevent solid particles penetrating into the pump! VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 7: To Prevent Risk Of Electrical Shock
Treat these substances according to the applicable environmental protection regulations. Test the strength and leak-tightness of the connecting lines and the connected apparatus. Prevent environmental poisons, e.g. mercury, getting into the rotary vane pumps. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 8: Product Standards, Safety Regulations
The CE mark is located on the rating plate. Observe the binding national and local regulations when fitting the pump into installations. The rotary vane pumps VWR RV2.5, VWR RV3+, VWR RV6+, VWR RV8+, VWR RV18+ meets the following product standards: Safety of machinery - Electrical equipment of machines –... -
Page 9: Package Contents
Carefully remove the pump from the shipping case. Preserve all paperwork for later use. If damage has occurred from shipment a claim must be filed with the carrier immediately; your VWR dealer or manufacturing firm, be sure to include to order numbers for quick identification. -
Page 10: Installation
The structural elements used on the inlet and outlet sides must be resistant to the media to the pumped. The pressure on the outlet side must not exceed 1 bar! A pressure that is slightly below the air pressure helps to avoid pollution of gases, and reduces corrosion. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 11: Installation, Fill With Oil And Connecting
Initial oil filling has to be done by the user. Connect the rotary vane pump to the electrical supply. Please note the explanations on chapter 2.50 Electrical Connection. How to operate the pump see chapter Operation. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 12: Electrical Connection
To do so, briefly switch on the power and check whether a suitable cover (e.g. a blank flange) is sucked on at the intake port. If not, interchange two phases of the connection. Observe the direction arrow on the motor adapter. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 13: Change The Voltage Setting
Vacuum pump is shipped without oil inside to prevent possible spillage during shipment. Oil must be added prior to use! The vacuum pump is delivered with VWR RV+ Oil and can therefore be used for pumping out neutral gases and vapours. The oil fulfills the following functions in the vacuum pump:... -
Page 14: Storage
Even if a pump is stored for a long period with oil initially in good condition, check the oil when the pump is restarted, and change the oil if necessary. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 15: Intended Use
It is forbidden to use the pump for applications deviating from the technical data stated on the type plate or the conditions stated in the supply contract, or to operate it with missing or defective protective devices. The rotary vane pumps VWR RV2.5+, VWR RV3+, VWR RV6+, VWR RV8+, VWR RV18+ are not suited for pumping liquids. -
Page 16: Symbols And Conventions
Read all instructions pertaining to safety, set-up, operation, and maintenance. Proper operation is the user’s responsibility. 7.0 Technical Specification 7.10 Intake pressure / Pumping speed – Diagram Intake Pressure / Pumping Speed – Diagram VWR RV2.5+/RV3+/RV6+/RV8+/RV18+ Fig. 4: VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 17: Technical Data
3.0 / 1.5 A 2.1 A 4.3 / 2.1 A 4.8 A 4.2 A Motor speed 1440 rpm 1720 rpm 1450 rpm 1740 rpm 1450 rpm 1750 rpm 50/60 Hz Type of IP54 protection VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 18: Dimensions
163.5 88.5 VWR RV6+ 181-0493 35.5 163.5 88.5 VWR RV6+ 181-0504 35.5 163.5 88.5 with ACC VWR RV8+ 181-0494 35.5 163.5 88.5 VWR RV8+ 181-0494 35.5 163.5 88.5 with ACC VWR RV18+ 181-0573 VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 19: Product Specifications
8.0 Product Specifications 8.10 Overview and Description The rotary vane pumps VWR RV2.5+, VWR RV3+, VWR RV6+, VWR RV8+, VWR RV18+, are oil-sealed, two-stage rotary vane vacuum pumps. The drive motor is directly flange-mounted onto the motor cover of the pump holder. The pump shaft and the motor shaft are connected to each other by an elastic coupling. -
Page 20: Area Of Application
WARNING! The rotary vane pumps must not be used for extracting explosive gases or vapours. The rotary vane pumps must not be operated in rooms which might contain explosive gases. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 21: Function
When the gas ballast valve opens (to the left) air flows into the compression space. The air flowing in keeps the partial pressure of the condensable medium so low that the pressure needed to open the outlet valve is reached before the medium condenses. VWR Rotary Vane Pump ver 1.3 23.11.2020... - Page 22 Should condensate form despite actuation of the gas ballast device, the suction port must be closed and the pump operated with gas ballast for a lengthy period (about 2 hours). VWR Rotary Vane Pump ver 1.3 23.11.2020...
-
Page 23: Operation
9.30 Operating temperature The function of the vacuum pump filled with VWR RV+ Oil is guaranteed between ambient temperatures of 10 °C and 40 °C. The lowest starting temperature is 12 °C. The pump must be vented on the suction-side (suction port open). -
Page 24: Use Of The Gas Ballast When Switching On
If the vacuum pump does not regain its former characteristics, this means that the oil is totally contaminated. In this case, the only remedy is complete cleaning followed by rinsing and filling with new oil, 7.40 Oil Change. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 25: Gas Ballast Control
Close connecting ports with a rubber stopper or other suitable cover to protect the pump against contamination. An intake screen is furnished to prevent loose particles from entering. WARNING! Take appropriate safety measures in case of having delivered dangerous media! VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 26: Troubleshooting
User or Service rotary vane spring broken workshop Vacuum pump runs very loudly Vacuum pump oil supply User or Service Check that the oil circulation is Vacuum pump interrupted workshop functioning, measure the oil pressure VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 27: Repair And Maintenance
All other maintenance and service work may only be performed by the manufacturer or a dealer authorized by him. Beware of the pump parts being possibly contaminated by hazardous substances. Wear protective clothing if there is contamination. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 28: Oil Level Control
The oil must be topped up if the oil level falls to the lower mark. We recommend to operate pump with oil filling at upper marking FULL. This minimize the service needs and allows better dilution of contaminants. When additional oil is required, use only VWR RV+ Oil, pump performance is not guaranteed with other brands of oil. -
Page 29: Draining The Oil
If you have established that the old oil, which you have previously drained, was contaminated by condensate (e.g. water) then the gas ballast valve must be open. Drain the flushing oil. If the oil still appears heavily contaminated, the flushing procedure must be repeated. VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 30: Frequency Of Oil Changes
When the oil becomes cloudy, dark or includes particles of solids, it is time to change the oil. Be sure to use only VWR RV+ Oil. The ultimate pressure guarantee applies only if this oil is used! 11.50 Maintenance by the manufacturer... - Page 31 Service kit item list for RV2.5: Item no. Description Qty. Consisting of: Coupling Bush Gas Ballast Valve Head Spring Vane Spring Fore Vane Shaft Coupling Screw Spring Gas Ballast Valve Head Oil Pump Vane Glass VWR Rotary Vane Pump ver 1.3 23.11.2020...
- Page 32 Anti-Suck Back Spring Anti-Suck Back Plate Coupling Element Fore Vane 63, 76 Vane Spring Exhaust Valve Plate Spring Gas Ballast Valve Head Rear Vane Glass SS Screw Flat Washer Exhaust Diaphragm Holder Shaft Coupling VWR Rotary Vane Pump ver 1.3 23.11.2020...
- Page 33 Description Qty. Consisting of: Gasket Anti-Suck Back Spring Anti-Suck Back Plate Coupling Element Fore Vane Vane Spring Exhaust Valve Plate Spring Gas Ballast Valve Head Rear Vane Glass SS Screw Exhaust Diaphragm Holder VWR Rotary Vane Pump ver 1.3 23.11.2020...
-
Page 34: Accessoires
Oil Mist Filter Rotary Vane Pump Replacement FOM 25 VWR RV+ Oil Filter cartridge Exhaust 1 Litre 5 Litre DN 25 KF Order no. Order no. Order no. Order no. 181-0508 181-0514 181-0621 181-0623 VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 35: Condenser Inlet
(B) of Assembly – the rotary vane pump (A). Condenser (connecting elements in DN 16 KF - Inlet at Rotary see data for ordering – 8.30 Oil Mist Vane Pump Separator Exhaust) VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 36: Oil Mist Separator Exhaust
- Oil Mist Separator Exhaust KF Centering Ring Aluminium 181-0546 with FKM-O-Ring DN 16 - Oil Mist Filter 10/16 Exhaust - Condenser Inlet KF Centering Ring with Fine filter Stainless steel 181-0622 with FKM-O-Ring DN 16 VWR Rotary Vane Pump ver 1.3 23.11.2020... -
Page 37: Oil Mist Filter 10/16 Exhaust
Pump 12.50 Oil – Technical Data VWR RV+ Oil is a triple-distilled hydrocarbon oil using severely hydrotreated base stock. The oil is designed to resist breakdown at higher RPMs and operating temperatures of direct-drive vacuum pumps. The hydrotreating virtually eliminates aromatics and sulfur to give good resistance to sludge and varnish formation over time in corrosive environments. -
Page 38: Technical Service
VWR warrants that this product will be free from defects in material and workmanship for a period of two (2) years from date of delivery. If a defect is present, VWR will, at its option and cost, repair, replace, or refund the purchase price of this product to the customer, provided it is returned during the warranty period. -
Page 39: Equipment Disposal (Weee)
By doing so, you will help to conserve natural and environmental resources and you will ensure that your equipment is recycled in a manner that protects human health. Thank you VWR Rotary Vane Pump ver 1.3 23.11.2020... - Page 40 Local VWR offices in Europe and Asia Pacific Hungary Poland VWR International Kft. VWR International Sp. z o.o. Austria Simon László u. 4. Limbowa 5 VWR International GmbH 4034 Debrecen 80-175 Gdansk Graumanngasse 7 Tel.: +36 (52) 521-130 Tel.: +48 058 32 38 210 1150 Vienna Email: info.hu@vwr.com...
